CMPZ4690: DescriptionVOLTAGE REGULATOR DIODE; CategoryDiscrete semiconductor diode; File Size403KB，3 Pages; ManufacturerCentral Semiconductor

Download Datasheet Parametric View All

CMPZ4690 Overview

VOLTAGE REGULATOR DIODE

CMPZ4690 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Central Semiconductor
Parts packaging code	SOT-23
package instruction	SOT-23, 3 PIN
Contacts	3
Reach Compliance Code	_compli
ECCN code	EAR99
Other features	LOW LEVEL
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
JESD-30 code	R-PDSO-G3
JESD-609 code	e0
Number of components	1
Number of terminals	3
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.35 W
Certification status	Not Qualified
Nominal reference voltage	5.6 V
surface mount	YES
technology	ZENER
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum voltage tolerance	5%
Working test current	0.05 mA

Preview

Download Datasheet

View All

CMPZ4678 THRU CMPZ4717

SURFACE MOUNT

LOW LEVEL

SILICON ZENER DIODE

350mW, 5% TOLERANCE

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR CMPZ4678 Series

silicon zener diode is a high quality voltage regulator

designed for applications requiring an extremely low

operating current and low leakage.

MARKING CODE: CONSULT FACTORY

SOT-23 CASE

MAXIMUM RATINGS:

(TA=25°C unless otherwise noted)

Power Dissipation

Operating and Storage Temperature

SYMBOL

TJ, Tstg

UNITS

°C

350

-65 to +150

ELECTRICAL CHARACTERISTICS:

(TA=25°C) VF=1.5V MAX @ IF=100mA (for all types)

NOMINAL

ZENER

VOLTAGE

VZ @ IZT

CMPZ4678

CMPZ4679

CMPZ4680

CMPZ4681

CMPZ4682

CMPZ4683

CMPZ4684

CMPZ4685

CMPZ4686

CMPZ4687

CMPZ4688

CMPZ4689

CMPZ4690

CMPZ4691

CMPZ4692

CMPZ4693

CMPZ4694

CMPZ4695

CMPZ4696

CMPZ4697

CMPZ4698

1.8

2.0

2.2

2.4

2.7

3.0

3.3

3.6

3.9

4.3

4.7

5.1

5.6

6.2

6.8

7.5

8.2

8.7

9.1

TEST

CURRENT

IZT

μA

MAXIMUM REVERSE

LEAKAGE CURRENT

μA

7.5

5.0

4.0

2.0

1.0

0.8

7.5

5.0

4.0

1.0

0.05

TYPE

1.0

1.5

2.0

3.0

4.0

5.0

5.1

5.7

6.2

6.6

6.9

7.6

8.4

MAXIMUM

VOLTAGE

CHANGE*

ΔVZ

0.70

0.75

0.80

0.85

0.90

0.95

0.97

0.99

0.97

0.96

0.95

0.90

0.75

0.50

0.10

0.08

0.10

0.11

MAXIMUM

ZENER

CURRENT

IZM

120.0

110.0

100.0

95.0

90.0

85.0

80.0

75.0

70.0

65.0

60.0

55.0

50.0

45.0

35.0

31.8

29.0

27.4

26.2

24.8

21.6

ΔV

Z=VZ@ 100µA MINUS VZ @ 10µA.

R8 (3-February 2010)
