Programmable
HCMOS Oscillator
•
•
•
•
•
TTL Compatible (3.3v)
2 Packaging Styles
Ultra Low Jitter
Low Phase Noise
Immediate Delivery
CARDINAL COMPONENTS
Platinum Series
CAM
Part Numbering Example: CAM C 7 L Z - A5 B6 - XXX.XXXX TS
CAM
C
7
L
Z
PACKAGING OPTIONS
Blank = Bulk
T
= Tube
Z
= Tape and Reel
A5
B6
XXX.XXXX
TS
SERIES OUTPUT PACKAGE STYLE VOLTAGE
CAM C=HCMOS 1 = Full Size
L = 3.3 V
4 = Half Size
S = 2.5 V
5 = 5 X 3.2 Ceramic
7 = 5 X 7 Ceramic
OPERATING TEMP.
FREQUENCY TRI-STATE
STABILITY
Blank = 0°C +70°C B6 = ±100 ppm
1.500~200.000
TS = Tri-State
MHz
A5
= -20°C +70°C BP = ±50 ppm
NC = No Connect
BR =
+25 ppm
A7
= -40°C +85°C
Specifications:
Description
Frequency Range:
Programmable to Any Discrete
Frequency
Available Stability Options:
Min
1.500
Typ
Max
200.000
Unit
MHz
-100
-50
-25
2.25
3.0
0
-20
-40
-55
2.5
3.3
100
50
25
2.75
3.6
+70
+70
+85
+125
±5
ppm
ppm
ppm
V
V
°C
°C
°C
°C
Supply Voltage Options:
(1–133 MHz)
(1–200 MHz)
Operating Temperature
Range Options:
Storage Temperature:
Aging (PPM/Year)
Ta=25C, Vdd=3.3V/2.5V
Output Level:
Packaging:
HCMOS
Tape and Reel (1K per Reel)
Tube
Operating Conditions:
Description
Vdd
Vdd
HCMOS
Min
2.25
100
Max
3.6
Unit
V
µ
S
Supply Voltage
Rise Time
Max Capacitive Load on outputs for CMOS levels
Frequency: < 40 MHz
Frequency: 40–200 MHz
30
15
pF
pF
155 Route 46 West
Wayne, NJ 07470
Rev: C-090414-11
Cardinal Components, Inc.
O-10
TEL:
(973)785-1333
E-MAIL: sales@cardinalxtal.com
WEB: http://www.cardinalxtal.com
Programmable
HCMOS Oscillator
•
•
•
•
•
TTL Compatible (3.3v)
2 Packaging Styles
Low Jitter
Low Phase Noise
Immediate Delivery
CARDINAL COMPONENTS
Platinum Series
CAM
Electrical Characteristics
Description
Input Characteristics (Pin 1):
V
IL
, Low–Level Input Voltage
TO DISABLE OUTPUT
T
EST
C
ONDITIONS
Min
Typ
Max Unit
3.0–3.6V Vdd
3.0–3.6V Vdd
V
IN
= 0V
V
IN
=Vdd
3.0V–3.6V Vdd, 8 mA I
OL
2.25V–3.6V Vdd, -8 mA I
OL
Vdd-0.4
0.7VddV
0.2Vdd
V
V
IH
, High–Level Input Voltage
TO ENABLE OUTPUT OR OPEN
I
IL
, Input Low Current
I
IH
, Input High Current
Output Characteristics:
V
OL
, Low–Level Output Voltage
V
OHCMOS
,
High-level HCMOS Voltage
Power Supply Current:
(unloaded)
Tristate Internal Pull-Up Res:
Tri-State Leakage Current:
Output Enable Mode:
80
10
0.4
µA
µA
V
V
V
2.25–3.6 Vdd, O
UTPUT
F
REQ
< 200 MHz
2.25–3.6V Vdd, V
IN
= 0.7V
Output active when high
35
50
70
20
90
mA
KΩ
µA
output active
Vdd
high
3.6V
when
Output is Tri-Stated
"Tristate internal pull up. Output active when high"
Output Clock Switching Characteristics
Description
Duty Cycle:
HCMOS @ Vdd/2
T
EST
C
ONDITIONS
2.25 V – 3.6V Vdd
Min
45
Typ
Max
55
Unit
%
Output Clock Rise/Fall:
0.2–0.8Vdd, 2.25–3.6 Vdd, C
L
= 30
0.2–0.8Vdd, 2.25–3.6 Vdd, C
L
= 15
4.0
2.4
nS
nS
Start Up Time:
RMS Period Jitter:
From power on
3
10
mS
pS
10
RMS Integrated Jitter:
Phase Noise:
12kHz to 20MHz
@ 10kHz
15
-100
pS
dBc/Hz
155 Route 46 West
Wayne, NJ 07470
Rev: C-090414-11
Cardinal Components, Inc.
O-11
TEL:
(973)785-1333
E-MAIL: sales@cardinalxtal.com
WEB: http://www.cardinalxtal.com
HCMOS Oscillator
CARDINAL COMPONENTS
Platinum Series
CAM
•
•
•
•
•
TTL Compatible (3.3v)
2 Packaging Styles
Low Jitter
Low Phase Noise
Immediate Delivery
Style 7 5x7 Ceramic SMD
Style 5 5x3.2 Ceramic SMD
PIN FUNCTION
1 CONTROL
2 GND
3 OUTPUT
4 Vdd
1.2±0.1
PIN FUNCTION
1 CONTROL
2 GND
3 OUTPUT
4 Vdd
Recommended Solder Pad Layout
Recommended Solder Pad Layout
Note:
Bypass Vdd to GND with a 0.01
µ
F capacitor
