UNISONIC TECHNOLOGIES CO., LTD
BAV99
HIGH CONDUCTANCE ULTRA
FAST DIODE
EQUIVALENT
DIODE
For 3 Pin Package
For 6 Pin Package
ORDERING INFORMATION
Ordering Number
Lead Free
Halogen Free
BAV99L-AE3-R
BAV99G-AE3-R
BAV99L-AL3-R
BAV99G-AL3-R
BAV99L-AN3-R
BAV99G-AN3-R
BAV99L-AL6-R
BAV99G-AL6-R
Note: Pin Assignment: A: Anode K: Cathode
BAV99L-AE3-R
(1)Packing Type
(2)Package Type
(3)Lead Plating
Package
SOT-23
SOT-323
SOT-523
SOT-363
1
K1
K1
K1
A1
Pin Assignment
2
3
4
5
A2
A2
A2
K1
K2A1
K2A1
K2A1
A2K2
-
-
-
A2
-
6
-
Packing
Tape Reel
-
-
Tape Reel
-
-
Tape Reel
K2 A1K1
Tape Reel
(1) R: Tape Reel
(2) AE3: SOT-23, AL3: SOT-523, AN3: SOT-523,
(2)
AL6: SOT-363
(3) G: Halogen Free, L: Lead Free
MARKING
SOT-23/SOT-323/SOT-523
SOT-363
V99
L: Lead Free
G: Halogen Free
www.unisonic.com.tw
Copyright © 2009 Unisonic Technologies Co., Ltd
1 of 4
QW-R601-005,E
BAV99
ABSOLUTE MAXIMUM RATINGS*
(Ta = 25°C,
unless otherwise specified.)
PARAMETER
Working Inverse Voltage
Average Rectified Current
DC Forward Current
Recurrent Peak Forward Current
Non-repetitive Peak
Pulse width = 1.0 second
Forward Surge Current Pulse width = 1.0 microsecond
SOT-23
SOT-523
Power Dissipation
SOT-323/SOT-363
SYMBOL
W
IV
I
F(AV)
I
FM
I
FRM
I
FSM
P
D
RATINGS
70
200
600
700
1.0
2.0
350
150
DIODE
UNIT
V
mA
mA
mA
A
A
mW
mW
200
mW
Junction Temperature
T
J
+150
°C
Storage Temperature
T
STG
-65 ~ +150
°C
Note: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
2. These are steady state limits. The factory should be consulted on applications involving pulsed or low duty
cycle operations.
THERMAL DATA
PARAMETER
Junction to Ambient
SOT-23
SOT-523
SOT-323/SOT-363
SYMBOL
θ
JA
RATINGS
357
833
625
UNIT
°C
/W
°C
/W
°C
/W
ELECTRICAL CHARACTERISTICS
(Ta = 25°C,
unless otherwise specified.)
PARAMETER
Breakdown Voltage
Maximum Instantaneous Forward
Voltage
Peak Forward Voltage
Maximum Instantaneous Reverse
Current
Diode Capacitance
Reverse Recovery Time
SYMBOL
TEST CONDITIONS
V
R
I
R
= 100μA
I
F
= 1.0mA
I
F
= 10mA
V
FM
I
F
= 50mA
I
F
= 150mA
V
SM
I
F
= 10mA, t
R
= 20nS
V
R
= 70V
I
RM
V
R
= 25V, Ta = 150°C
V
R
= 70V, Ta = 150°C
C
O
V
R
= 0, f = 1.0MHz
I
F
= I
R
= 10mA, I
RR
= 1.0mA
t
RR
R
L
= 100Ω
MIN
70
TYP
MAX
775
855
1.0
1.25
1.75
2.5
30
50
1.5
6.0
UNIT
V
mV
mV
V
V
V
μA
pF
ns
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
2 of 4
QW-R601-005,E
BAV99
TYPICAL CHARACTERISTICS
Reverse Voltage vs. Reverse Current
BV - 1.0 ~ 100 uA
150
Reverse Voltage, V
R
(V)
Ta = 25℃
Reverse Current, I
R
(nA)
DIODE
Reverse Current vs. Reverse Voltage
I
R
- 10 ~ 100 V
300 Ta = 25℃
250
200
150
100
50
0
10
2
3 20
30
50
70
100
150
150
150
150
1
2
3
5
10
20 30
50
100
Reverse Voltage, V
R
(V)
GENERAL RULE: The Reverse Current of a diode will approximately
double for every ten (10) Degree C increase in Temperature
Reverse Current, I
R
(uA)
Forward Voltage vs. Forward Current
V
F
- 1.0 ~ 100 uA
485
450
Forward Voltage, V
F
(mV)
400
350
300
250
225
1
2
3
5
10
20 30
50
100
450
0.1
Ta = 25℃
Forward Voltge, V
F
(mV)
725
700
650
600
550
500
Forward Voltage vs. Forward Current
V
F
–
0.1 ~ 10 mA
Ta = 25℃
0.2 0.3 0.5
1
2
3
5
10
Forward Current, I
F
(uA)
Forward Current, I
F
(mA)
Forward Voltage, V
F
(V)
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
Capacitance (pF)
3 of 4
QW-R601-005,E
BAV99
TYPICAL CHARACTERISTICS(
Cont.)
DIODE
Power Derating Curve
500
Power Dissipation, P
D
(mW)
400
300
SOT-23
200
100
0
0
SOT-363
50
100
150
200
Average Temperature, Ta (℃)
UTC assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or
other parameters) listed in products specifications of any and all UTC products described or contained
herein. UTC products are not designed for use in life support appliances, devices or systems where
malfunction of these products can be reasonably expected to result in personal injury. Reproduction in
whole or in part is prohibited without the prior written consent of the copyright owner. The information
presented in this document does not form part of any quotation or contract, is believed to be accurate
and reliable and may be changed without notice.
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
Power Dissipation, P
D
(mW)
Reverse Recovery (nS)
4 of 4
QW-R601-005,E
