ENGINEERING BULLETIN
Sprague-Goodman
®
SG-800H
Supercedes SG-800G
SURFCOIL SMT INDUCTORS
FEATURES
• Lead free, ROHS Compliant
• High Q
• High self-resonant frequency including
nonmagnetic models in microwave range
• Shielded series use ferrite filled encapsulation
to reduce external magnetic coupling
• Low DC resistance
• Carrier and reel packaging is standard
• Ten case sizes
SPECIFICATIONS
Electrical
• Inductance & Q, etc.: See tables
• Temperature range –20°C to +85°C,
except GLY, GLYC, GLZ, GLZB and GLZP
Models are – 40°C to +85°C
- Change of L = ±10% max, except
GLX, GLY, GLYC, GLZ, GLZB and GLZP
Models are ± 5%
- Change of Q = ±20% max, except GLY, GLYC,
GLZ, GLZB and GLZP Models are ±25%
• Rated Current: See tables. Current
rating is determined by either or both
of the following conditions:
1. Self heating raises SURFCOIL
temperature 20°C
2. Inductance value reduced by
10% from saturation effect
Mechanical (Chip Inductors)
• Suitable for wave flow soldering, infrared,
and vapor phase reflow (typically over 90%
coverage)
• Withstands soldering temperatures
without damage
• Fully encapsulated and thermally cycled
for stability and highest reliability
Encapsulation:
Epoxy resin all series;
GLC, GLD and GLW have ferrite
filler for closed magnetic circuit.
Core:
Ferrite (except high
frequency GLA and
GLU series, which
are nonmagnetic)
Coil:
Polyurethane
enameled copper wire
Terminal:
Phosphor-Bronze
tin plated
[View applies to molded bobbin wound types]
Sprague-Goodman Electronics, Inc.
1700 SHAMES DRIVE, WESTBURY, NY 11590
TEL: 516-334-8700 • FAX: 516-334-8771
E-MAIL: info@spraguegoodman.com
SURFCOIL
®
SMT INDUCTORS
SG-800H
GLZ SERIES — LASER CUT 0402 SIZE
Induct-
ance
L (nH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100.0
Standard
Inductance
Tolerance
± 0.3 nH
± 0.3 nH
± 0.3 nH
± 0.3 nH
± 0.3 nH
± 0.3 nH
± 0.3 nH
± 0.3 nH
± 0.3 nH
± 0.3 nH
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
Model
No.
GLZ1N030
GLZ1N225
GLZ1N520
GLZ1N817
GLZ2N214
GLZ2N711
GLZ3N309
GLZ3N908
GLZ4N706
GLZ5N605
GLZ6N805
GLZ8N205
GLZ10N05
GLZ12N05
GLZ15N05
GLZ18N05
GLZ22N05
GLZ27N05
GLZ33N05
GLZ39N05
GLZ47N05
GLZ56N05
GLZ68N05
GLZ82N05
GLZR1005
SRF
(MHz)
min
6000
6000
6000
6000
6000
5500
5500
5200
4800
4600
4000
3500
2800
2800
2500
2200
2000
1800
1800
1800
1800
1500
1500
1400
1200
Q
min
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
Q/L Test Rated DCR
Freq. Current (Ω)
(MHz)
(mA)
max
100
400
0.05
100
400
0.06
100
400
0.07
100
400
0.08
100
400
0.09
100
400
0.10
100
400
0.12
100
360
0.15
100
360
0.17
100
340
0.19
100
320
0.30
100
320
0.35
100
320
0.41
100
320
0.45
100
240
0.60
100
240
0.70
100
200
0.80
100
200
1.20
100
170
1.40
100
150
1.70
100
140
2.10
100
130
2.50
100
120
4.00
100
110
4.50
100
90
5.50
GLZ GLZB and GLZP Series Outline Drawing
0.02
±
0.006
0.5
±
0.15
0.039
±
0.006
1.0
±
0.15
0.008
TYP
0.2
0.02
±
0.006
0.5
±
0.15
0.022
±
0.002
0.55
±
0.05
1
2
3
0.063
±
0.004
1.6
±
0.1
0.022
±
0.002
0.55
±
0.05
PAD LAYOUT
4
MATERIAL
ITEM
1) Encapsulant Epoxy Resin
Tin coat
2) Terminal
over Ni plate
Copper
3) Coil
Alumina
4) Core
All dimensions are in/mm.
GLZB SERIES — HIGH Q LASER CUT 0402 SIZE
Inductance
L
(nH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
Standard
Inductance
Tolerance
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
2%
2%
2%
2%
2%
2%
2%
2%
nH
nH
nH
nH
nH
nH
nH
nH
nH
nH
nH
nH
Inductance
Test Freq.
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
Model
No.
GLZB1N020
GLZB1N217
GLZB1N513
GLZB1N811
GLZB2N209
GLZB2N707
GLZB3N306
GLZB3N905
GLZB4N704
GLZB5N604
GLZB6N803
GLZB8N202
GLZB10002
GLZB12002
GLZB15002
GLZB18002
GLZB22002
GLZB27002
GLZB33002
GLZB39002
SRF
(MHz)
min
6000
6000
6000
6000
6000
5500
5500
5200
4800
4600
4000
3500
2800
2800
2500
2200
2200
1800
1800
1800
Q Typ
(800 MHz)
41
41
40
40
40
40
39
39
39
39
39
39
39
38
36
36
36
36
35
35
Q min
(100 MHz)
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
Rated
Current
(mA)
400
400
400
400
400
400
400
360
360
340
320
320
320
320
240
240
200
200
170
170
DCR
(Ω)
max
0.05
0.06
0.07
0.08
0.09
0.10
0.12
0.15
0.17
0.19
0.30
0.35
0.41
0.45
0.60
0.70
0.80
1.20
1.40
1.70
GLZP SERIES — HIGH CURRENT LOW DCR LASER CUT 0402 SIZE
Inductance
L
(nH)
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
Standard
Inductance
Tolerance
± 0.3 nH
± 0.3 nH
± 0.3 nH
± 0.3 nH
± 0.3 nH
± 0.3 nH
± 5%
± 5%
± 5%
Model
No.
GLZP2N214
GLZP2N711
GLZP3N309
GLZP3N908
GLZP4N706
GLZP5N605
GLZP6N805
GLZP8N205
GLZP10N05
SRF
(GHz)
min
5.3
5.3
5.0
4.8
4.6
4.2
4.0
3.7
3.2
Q
min
7
7
7
7
7
7
7
7
7
Q/L Test
Frequency
(MHz)
100
100
100
100
100
100
100
100
100
Rated
Current
(A)
1.9
1.8
1.5
1.4
1.3
1.2
1.1
0.90
0.75
DCR
(Ω)
max
0.04
0.05
0.07
0.08
0.10
0.12
0.16
0.21
0.26
Carrier and reel specifications on page 12.
2
SPRAGUE-GOODMAN ELECTRONICS, INC., 1700 SHAMES DRIVE, WESTBURY, NY 11590 • TEL: 516-334-8700 • FAX: 516-334-8771 • E-MAIL: info@ spraguegoodman.com
SURFCOIL
®
SMT INDUCTORS
SG-800H
GLY SERIES — LASER CUT 0603 SIZE
Inductance
L (nH)
(100 MHz)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100.0
120.0
150.0
180.0
220.0
Standard
Inductance
Tolerance*
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
0.3
0.3
0.3
0.3
0.3
0.3
0.3
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
nH
nH
nH
nH
nH
nH
nH
Model
No.
GLY1N030
GLY1N225
GLY1N520
GLY1N817
GLY2N214
GLY2N711
GLY3N309
GLY3N905
GLY4N705
GLY5N605
GLY6N805
GLY8N205
GLY10N05
GLY12N05
GLY15N05
GLY18N05
GLY22N05
GLY27N05
GLY33N05
GLY39N05
GLY47N05
GLY56N05
GLY68N05
GLY82N05
GLYR1005
GLYR1205
GLYR1505
GLYR1805
GLYR2205
SRF
(GHz)
min
6.0
6.0
6.0
6.0
6.0
6.0
5.5
5.5
4.8
4.6
3.5
3.5
2.8
2.8
2.5
2.3
2.0
2.0
1.8
1.8
1.8
1.8
1.5
1.5
1.3
1.2
1.1
1.0
0.9
Q Typ
(800 MHz)
47
47
47
45
35
35
35
36
36
36
36
36
37
37
38
39
40
41
40
39
38
35
35
33
30
25
22
20
17
Q min
(100 MHz)
7
7
8
8
8
8
9
9
9
9
9
9
10
10
10
10
10
10
10
11
11
12
12
12
12
5
5
4
4
Rated
Current
(mA)
500
500
500
500
500
500
500
450
450
430
430
400
400
400
350
350
300
300
300
300
250
250
250
250
200
130
100
80
70
DCR
(Ω)
max
0.05
0.06
0.07
0.08
0.09
0.10
0.12
0.15
0.17
0.18
0.20
0.28
0.32
0.35
0.41
0.45
0.50
0.55
0.60
0.80
0.95
1.2
1.3
1.5
1.8
3.0
4.5
6.5
7.5
* ± 0.2 nH inductance tolerance is available for inductance values from 1.0 to 8.2 nH. ± 2% inductance tolerance is
available for inductance values of 10.0 nH and up. Consult factory regarding these special units.
GLYC SERIES — HIGH CURRENT LOW DCR LASER CUT 0603 SIZE
Inductance
L (nH)
(100 MHz)
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
Standard
Inductance
Tolerance
±
±
±
±
±
±
±
±
±
±
±
±
±
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
Model
No.
GLYC2N210
GLYC2N710
GLYC3N310
GLYC3N910
GLYC4N710
GLYC5N610
GLYC6N810
GLYC8N210
GLYC10N10
GLYC12N10
GLYC15N10
GLYC18N10
GLYC22N10
SRF
(GHz)
min
6.0
5.0
5.0
5.2
4.8
4.6
4.0
3.5
2.8
2.5
2.2
2.0
1.8
Q min
(100 MHz)
8
8
8
9
9
9
9
9
9
9
9
9
9
Rated
Current
(A)
2.1
2.1
2.1
2.1
2.1
2.1
1.9
1.7
1.4
1.3
0.9
0.8
0.7
DCR
(m
Ω)
max
30
30
40
40
50
55
55
60
65
80
100
120
150
Carrier and reel specifications on page 12.
GLY and GLYC Series Outline Drawing
0.031
±
0.006
0.8
±
0.15
0.031
±
0.006
0.8
±
0.15
0.02
±
0.008
TYP
0.4
±
0.2
3
2
1
TYPICAL Q VERSUS FREQUENCY—GLY AND GLYC Series
80
60
10 nH GLYC
4
0.063
±
0.006
1.6
±
0.15
0.035
±
0.004
0.9
±
0.1
0.035
±
0.004
0.9
±
0.1
0.091
±
0.01
2.3
±
0.3
PAD LAYOUT
ITEM
1) Encapsulant
2) Terminal
3) Coil
4) Core
MATERIAL
Epoxy Resin
Tin coat
over Ni plate
Copper
Alumina
40
Q
20
47 nH GLY
0
10
100
FREQUENCY (MHz)
1000
10000
4.7 nH GLY
All dimensions are in/mm.
SPRAGUE-GOODMAN ELECTRONICS, INC., 1700 SHAMES DRIVE, WESTBURY, NY 11590 • TEL: 516-334-8700 • FAX: 516-334-8771 • E-MAIL: info@ spraguegoodman.com
3
SURFCOIL
®
SMT INDUCTORS
SG-800H
GLX SERIES — HIGH FREQUENCY NONMAGNETIC WIREWOUND 0805 SIZE
Inductance
L
(µH)
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.00
Standard
Inductance
Tolerance*
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
Model
No.
GLX10N10
GLX12N10
GLX15N10
GLX18N10
GLX22N10
GLX27N10
GLX33N10
GLX39N10
GLX47N10
GLX56N10
GLX68N10
GLX82N10
GLXR1010
GLXR1210
GLXR1510
GLXR1810
GLXR2210
GLXR2710
GLXR3310
GLXR3910
GLXR4710
GLXR5610
GLXR6810
GLXR8210
GLX1R010
SRF
(MHz)
min
2500
2500
2500
2000
2000
1800
1500
1500
1000
1000
800
800
800
600
600
600
500
300
200
150
150
100
100
80
80
Q
min
10
10
12
12
15
15
15
15
15
15
15
15
8
8
10
10
10
10
10
10
10
10
10
10
8
Q/L Test
Frequency
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
Rated
Current
(mA)
540
535
520
480
465
455
395
390
385
360
340
330
285
275
230
195
170
165
160
150
145
140
130
125
120
DCR
(Ω)
max
0.18
0.23
0.23
0.29
0.29
0.34
0.39
0.40
0.46
0.51
0.57
0.62
0.86
0.99
1.47
1.61
1.83
1.95
2.16
2.37
2.56
2.69
3.02
3.38
3.87
*±5% Inductance tolerance is available for inductance values of 0.033 µH and up.
TYPICAL Q VERSUS FREQUENCY— Non Magnetic GLX Series
100
39 nH
0.1
µH
50
40
Q
Q
30
20
15 nH
0.22
µH
0.049
±
0.008
1.25
±
0.2
0.039 TO 0.047
1.0 TO 1.2
0.049
±
0.01
1.25
±
0.3
0.039
±
0.004
1.0
±
0.1
GLX Series Outline Drawing
0.47
µH
0.047
±
0.008
1.2
±
0.2
0.016
±
0.008
0.40
±
0.2
0.035 TO 0.051
0.9 TO 1.3
0.20 TO 0.15
3.0 TO 3.8
10
10
100
FREQUENCY (MHz)
1000
+ 0.01
0.079 _ 0.008
2.00 + 0.3
_ 0.2
PAD LAYOUT
All dimensions are in/mm.
GLW SERIES — HIGH CURRENT MOLDED BOBBIN WOUND 1008 SIZE
Induct- Standard
ance Inductance
L (µH) Tolerance
1.0
1.5
2.2
3.3
4.7
6.8
10.0
12.0
15.0
22.0
33.0
±
±
±
±
±
±
±
±
±
±
±
20%
20%
20%
20%
20%
10%
10%
10%
10%
10%
10%
Model
No.
GLW1R020
GLW1R520
GLW2R220
GLW3R320
GLW4R720
GLW6R810
GLW10010
GLW12010
GLW15010
GLW22010
GLW33010
SRF
Q/L Test Rated DCR
(MHz) Q
Freq. Current (Ω)
min min (MHz)
(mA) max
95
85
65
55
43
39
32
25
21
18
16
10
10
10
8
8
8
20
20
20
20
20
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
475
435
390
340
285
275
210
195
175
160
120
0.45
0.55
0.65
0.85
1.2
1.3
2.2
2.7
3.2
4.0
6.5
GLU and GLW Series Outline Drawing
MARKING
(inductance & tolerance)
0.079
±
0.008
2.0
±
0.2
0.047
±
0.004
1.2
±
0.1
0.098
±
0.012
2.5
±
0.3
0.055
±
0.008
1.4
±
0.2
0.063
±
0.008
1.6
±
0.2
0.055
±
0.008
1.4
±
0.2
PAD LAYOUT
0.055
±
0.004
1.4
±
0.1
Carrier and reel specifications on page 12.
4
0.016
±
0.008
TYP
0.4
±
0.2
TERMINALS APPROX. FLUSH
TO MOUNTING SURFACE
All dimensions are in/mm.
SPRAGUE-GOODMAN ELECTRONICS, INC., 1700 SHAMES DRIVE, WESTBURY, NY 11590 • TEL: 516-334-8700 • FAX: 516-334-8771 • E-MAIL: info@ spraguegoodman.com
SURFCOIL
®
SMT INDUCTORS
SG-800H
GLU SERIES — MOLDED BOBBIN WOUND 1008 SIZE
Inductance
L (µH)
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.00
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100.0
Standard Inductance
Tolerance*
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
Model
No.
GLUR2210M
GLUR2710M
GLUR3310M
GLUR3910M
GLUR4710M
GLUR5610M
GLUR6810M
GLUR8210M
GLU1R010
GLU1R210
GLU1R510
GLU1R810
GLU2R210
GLU2R710
GLU3R310
GLU3R910
GLU4R710
GLU5R610
GLU6R810
GLU8R210
GLU10005
GLU12005
GLU15005
GLU18005
GLU22005
GLU27005
GLU33005
GLU39005
GLU47005
GLU56005
GLU68005
GLU82005
GLU10105
SRF (MHz)
min
230
210
190
175
160
150
135
125
115
100
90
85
80
75
65
60
55
50
45
40
32
30
28
25
22
21
20
18
17
16
15
13
12
Q
min
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
20
20
20
20
20
20
20
15
Q/L Test
Freq. (MHz)
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
Rated Current
(mA)
190
180
170
160
155
150
140
130
195
180
170
160
155
145
135
130
125
120
115
105
80
75
70
65
60
115
110
90
80
75
70
65
60
DCR (Ω)
max
0.70
0.75
0.85
0.95
1.00
1.10
1.25
1.40
0.65
0.75
0.85
0.95
1.05
1.20
1.30
1.40
1.55
1.75
1.95
2.20
3.5
3.8
4.4
5.0
5.8
6.3
7.1
9.5
11.0
12.1
16.6
19.0
21.0
± 5%
± 5%
± 5%
* ± 5% Inductance tolerance is available for inductance values up to 8.2
µH.
Carrier and reel specifications on page 12.
GLU SERIES — NONMAGNETIC HIGH FREQUENCY MOLDED BOBBIN WOUND 1008 SIZE
Inductance
L (µH)
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
Standard Inductance
Tolerance*
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
Model
No.
GLU10N10
GLU12N10
GLU15N10
GLU18N10
GLU22N10
GLU27N10
GLU33N10
GLU39N10
GLU47N10
GLU56N10
GLU68N10
GLU82N10
GLUR1010
GLUR1210
GLUR1510
GLUR1810
GLUR2210
GLUR2710
GLUR3310
GLUR3910
GLUR4710
GLUR5610
GLUR6810
GLUR8210
SRF (MHz)
min
2500
2200
1800
1550
1350
1150
1000
890
770
670
590
520
460
400
340
300
260
230
200
180
160
145
130
100
Q
min
10
10
10
10
15
15
15
15
15
15
15
15
10
10
10
10
10
10
10
10
10
10
10
10
Q/L Test
Freq. (MHz)
100
100
100
100
100
100
100
100
100.
100.
100.
100.
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
Rated Current
(mA)
280
270
255
250
240
230
220
215
205
200
190
185
175
170
160
155
145
140
135
130
125
120
110
100
DCR (Ω)
max
0.32
0.34
0.38
0.40
0.43
0.47
0.51
0.55
0.59
0.63
0.68
0.73
0.80
0.87
0.98
1.05
1.15
1.25
1.37
1.47
1.58
1.70
1.85
2.10
*±5% Inductance tolerance is available for inductance values of 0.033 µH and up. Carrier and reel specifications on page 12.
SPRAGUE-GOODMAN ELECTRONICS, INC., 1700 SHAMES DRIVE, WESTBURY, NY 11590 • TEL: 516-334-8700 • FAX: 516-334-8771 • E-MAIL: info@ spraguegoodman.com
5
DIY/Open Source Hardware
京公网安备 11010802033920号
EEWORLD
