Cross Reference Guide
BR5338 / SBR5338*
* Part number for additional environmental screening.
Performance Data
Frequency
Gain
Noise Figure
P
1dB
3
rd
Order Intercept
2
nd
Order Intercept
VSWR
Reverse Isolation
Power Supply
Operating Temperature
5.0 - 150.0 MHz
15.0 dB Typical
14.0 dB Min
2.7 dB Typical
3.5 dB Max
25.0 dBm Typical
23.0 dBm Min
36.0 dBm Typical
44.0 dBm Typical
1.5/2.0 Input Typ/Max
1.2/2.0 Output Typ/Max
-20.0 dB Typical
-19.0 dB Min
12.0 Volts
88.0 mA
-55.0 - 85.0 °C
Package Drawing
Gain
dB
Frequency (MHz)
Noise Figure
dB
Frequency (MHz)
P
1dB
Compression Point
dBm
Frequency (MHz)
Reverse Isolation
dB
Frequency (MHz)
Input VSWR
Frequency (MHz)
Output VSWR
Frequency (MHz)
S-Parameters
Frequency S11 Mag S11 Ang S21 Mag S21 Ang S12 Mag S12 Ang S22 Mag S22 Ang
5.0
25.0
50.0
100.0
150.0
0.160
0.060
0.070
0.090
0.170
-96.00
-140.00
-153.00
-162.00
-169.00
5.810
5.850
5.830
5.780
5.800
-164.00
169.00
154.00
125.00
94.00
0.090
0.100
0.100
0.100
0.100
-171.00
167.00
151.00
120.00
89.00
0.090
0.020
0.020
0.040
0.090
-42.00
-90.00
-105.00
-152.00
149.00
Absolute Maximum Conditions
Maximum Operating Temperature
Maximum Case Temperature
Continuous RF Input Power
Maximum Peak Power
(3 µsec max)
-55.0 - 100.0 °C
125.0 °C
18.0 dBm
0.5 W
Maximum Storage Temperature
Maximum Supply Voltage
Short Term RF Input Power
(1 minute max)
-62.0 - 125.0 °C
18.0 Volts
50.0 mW
Amplifonix | 2707 Black Lake Place | Philadelphia, PA 19154
Tel: 215.464.4000 | FAX: 215.464.4001 | Email:
