IDTQS52805ATQ8: DescriptionLow Skew Clock Driver, 5 True Output(s), 0 Inverted Output(s), CMOS, PDSO20, QSOP-20; Categorylogic logic; File Size94KB，6 Pages; ManufacturerIDT (Integrated Device Technology)

Download Datasheet Parametric Compare View All

IDTQS52805ATQ8 Overview

Low Skew Clock Driver, 5 True Output(s), 0 Inverted Output(s), CMOS, PDSO20, QSOP-20

IDTQS52805ATQ8 Parametric

Parameter Name	Attribute value
Maker	IDT (Integrated Device Technology)
Parts packaging code	QSOP
package instruction	SSOP,
Contacts	20
Reach Compliance Code	unknown
Input adjustment	SCHMITT TRIGGER
JESD-30 code	R-PDSO-G20
JESD-609 code	e0
length	8.6614 mm
Logic integrated circuit type	LOW SKEW CLOCK DRIVER
Number of functions	2
Number of inverted outputs
Number of terminals	20
Actual output times	5
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Output characteristics	3-STATE WITH SERIES RESISTOR
Package body material	PLASTIC/EPOXY
encapsulated code	SSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH
propagation delay (tpd)	5.8 ns
Certification status	Not Qualified
Same Edge Skew-Max（tskwd）	0.9 ns
Maximum seat height	1.7272 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal pitch	0.635 mm
Terminal location	DUAL
width	3.9116 mm

Preview

Download Datasheet

View All

QS52805T/AT

GUARANTEED LOW SKEW CMOS CLOCK DRIVER/BUFFER

INDUSTRIAL TEMPERATURE RANGE

GUARANTEED LOW SKEW

CMOS CLOCK

DRIVER/BUFFER

FEATURES:

−

10 output, low skew signal buffer

Guaranteed low skew:

•

0.7ns output skew (same bank)

•

0.9ns output skew (different bank)

•

1ns part-to-part skew

25Ω on-chip resistors available for low noise

Input hysteresis for better noise margin

Monitor output

Undershoot clamp diodes on all inputs

Std. and A speed grades

Available in QSOP and SOIC packages

QS52805T/AT

ADVANCE

INFORMATION

DESCRIPTION

The QS52805T clock buffer/driver circuits can be used for clock buffering

schemes where low skew is a key parameter. This device offers two banks

of five non-inverting outputs. This device provides low propagation delay

buffering with on-chip skew of 0.7ns for same-transition, same-bank signals.

The QS52805T has on-chip series termination resistors for lower noise

clock signals. The QS52805T series resistor version is recommended for

driving unterminated lines with capacitive loading and other noise sensitive

clock distribution circuits. These clock buffer products are designed for use

in high-performance workstations and in embedded and personal comput-

ing systems. Several devices can be used in parallel or scattered throughout

a system for guaranteed low skew, system-wide clock distribution networks.

The QS52805T is characterized for operation at -40°C to +85°C.

−

FUNCTIONAL BLOCK DIAGRAM

MON

NOTE:

This device has 25Ω series termination resistors on each clock output including monitor.

INDUSTRIAL TEMPERATURE RANGE

1999

Integrated Device Technology, Inc.

AUGUST 2000

DSC-5480/-
