2SD2449
TOSHIBA Transistor Silicon NPN Triple Diffused Type (Darlington Power Transistor)
2SD2449
Power Amplifier Applications
Unit: mm
•
•
High breakdown voltage: V
CEO
= 160 V (min)
Complementary to 2SB1594
Maximum Ratings
(Ta = 25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
(Tc = 25°C)
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
T
j
T
stg
Rating
160
160
5
10
1
150
150
−55
to 150
Unit
V
V
V
A
A
W
°C
°C
JEDEC
JEITA
―
―
2-21F1A
Equivalent Circuit
COLLECTOR
TOSHIBA
Weight: 9.75 g (typ.)
BASE
≈
10
Ω
EMITTER
1
2004-07-07
2SD2449
Electrical Characteristics
(Ta = 25°C)
Characteristics
Collector cut-off current
Emitter cut-off current
Collector-emitter breakdown voltage
Symbol
I
CBO
I
EBO
V
(BR) CEO
h
FE (1)
DC current gain
(Note)
h
FE (2)
Collector-emitter saturation voltage
Base-emitter voltage
Transition frequency
Collector output capacitance
V
CE (sat)
V
BE
f
T
C
ob
Test Condition
V
CB
= 160 V, I
E
= 0
V
EB
= 5 V, I
C
= 0
I
C
= 50 mA, I
B
= 0
V
CE
= 5 V, I
C
= 8 A
V
CE
= 5 V, I
C
= 12 A
I
C
= 8 A, I
B
= 8 mA
V
CE
= 5 V, I
C
= 8 A
V
CE
= 5 V, I
C
= 1 A
V
CB
= 10 V, I
E
= 0, f = 1 MHz
Min
―
―
160
3000
2000
―
―
―
―
Typ.
―
―
―
―
―
―
―
30
150
Max
5
5
―
20000
―
3.0
3.0
―
―
V
V
MHz
pF
Unit
µA
µA
V
Note: h
FE (1)
classification
A: 3000 to 10000, B: 5000 to 15000, C: 7000 to 20000
Marking
Part No. (or abbreviation code)
TOSHIBA
2SD2449
Lot No.
JAPAN
A line indicates
lead (Pb)-free package or
lead (Pb)-free finish.
2
2004-07-07
2SD2449
RESTRICTIONS ON PRODUCT USE
•
The information contained herein is subject to change without notice.
030619EAA
•
The information contained herein is presented only as a guide for the applications of our products. No
responsibility is assumed by TOSHIBA for any infringements of patents or other rights of the third parties which
may result from its use. No license is granted by implication or otherwise under any patent or patent rights of
TOSHIBA or others.
•
TOSHIBA is continually working to improve the quality and reliability of its products. Nevertheless, semiconductor
devices in general can malfunction or fail due to their inherent electrical sensitivity and vulnerability to physical
stress. It is the responsibility of the buyer, when utilizing TOSHIBA products, to comply with the standards of
safety in making a safe design for the entire system, and to avoid situations in which a malfunction or failure of
such TOSHIBA products could cause loss of human life, bodily injury or damage to property.
In developing your designs, please ensure that TOSHIBA products are used within specified operating ranges as
set forth in the most recent TOSHIBA products specifications. Also, please keep in mind the precautions and
conditions set forth in the “Handling Guide for Semiconductor Devices,” or “TOSHIBA Semiconductor Reliability
Handbook” etc..
•
The TOSHIBA products listed in this document are intended for usage in general electronics applications
(computer, personal equipment, office equipment, measuring equipment, industrial robotics, domestic appliances,
etc.). These TOSHIBA products are neither intended nor warranted for usage in equipment that requires
extraordinarily high quality and/or reliability or a malfunction or failure of which may cause loss of human life or
bodily injury (“Unintended Usage”). Unintended Usage include atomic energy control instruments, airplane or
spaceship instruments, transportation instruments, traffic signal instruments, combustion control instruments,
medical instruments, all types of safety devices, etc.. Unintended Usage of TOSHIBA products listed in this
document shall be made at the customer’s own risk.
•
TOSHIBA products should not be embedded to the downstream products which are prohibited to be produced
and sold, under any law and regulations.
4
2004-07-07
