RURD440S: DescriptionRectifier Diode, Avalanche, 1 Phase, 1 Element, 4A, 400V V(RRM), Silicon, TO-252; CategoryDiscrete semiconductor diode; File Size31KB，2 Pages; ManufacturerHarris; Websitehttp://www.harris.com/

Download Datasheet Parametric View All

RURD440S Overview

Rectifier Diode, Avalanche, 1 Phase, 1 Element, 4A, 400V V(RRM), Silicon, TO-252

RURD440S Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Harris
package instruction	R-PSSO-G2
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	FREE WHEELING DIODE
application	ULTRA FAST SOFT RECOVERY
Shell connection	CATHODE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.5 V
JEDEC-95 code	TO-252
JESD-30 code	R-PSSO-G2
JESD-609 code	e0
Maximum non-repetitive peak forward current	40 A
Number of components	1
Phase	1
Number of terminals	2
Maximum operating temperature	175 °C
Minimum operating temperature	-65 °C
Maximum output current	4 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum power dissipation	50 W
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	400 V
Maximum reverse current	100 µA
Maximum reverse recovery time	0.06 µs
surface mount	YES
technology	AVALANCHE
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal location	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

HARRIS ULTRAFAST RECOVERY RECTIFIER PRODUCT LINE

TO-251

TO-252

TO-220AC

I

F(AVG)

8A

MUR810

MUR1510

RURP3010

RURG3010

RURP810

RURP1510

0.975V 35ns† 1.05V

35ns 1.0V

50ns 1.0V

50ns

MUR815

MUR1515

RURP3015

RURG3015

RURP815

RURP1515

0.975V 35ns† 1.05V

35ns 1.0V

50ns 1.0V

50ns

MUR820

MUR1520

RURP3020

RURG3020

RURP820

RURP1520

1.0V

35ns† 1.05V

35ns 1.0V

50ns 1.0V

50ns

NOTE: The TO-252 is designated by

"S" sufﬁx.

2 LEAD TO-247

I

F(AVG)

30A

50A

75A/80A

50A

SINGLE LEAD TO-218

I

F(AVG)

75A/80A

100A

150A

I

F(AVG)

8A

15A

V

RRM

4A

6A

100V

RURD410

RURD610

RURD410S

RURD610S

1.0V

35ns 1.0V

35ns

150V

RURD415

RURD615

RURD415S

RURD615S

1.0V

35ns 1.0V

35ns

200V

RURD420

RURD620

RURD420S

RURD620S

1.0V

35ns 1.0V

35ns

400V

RURD440

RURD640

RURD840

MUR840

MUR1540

RURP3040

RURG3040

RURG5040

RURG8040

RURU5040

RURU8040

RURU10040

RURU15040

RURD440S

RURD640S

RURD840S

RURP840

RURP1540

1.5V

60ns 1.5V

70ns 1.3V

60ns† 1.25V

60ns 1.5V

60ns 1.6V

75ns 1.6V

85ns 1.6V

75ns 1.6V

85ns 1.6V

100ns 1.6V

100ns

500V

RURD450

RURD650

RURD850

MUR850

MUR1550

RURP3050

RURG3050

RURG5050

RURG8050

RURU5050

RURU8050

RURU10050

RURU15050

RURD450S

RURD650S

RURD850S

RURP850

RURP1550

1.5V

60ns 1.5V

70ns 1.5V

60ns† 1.5V

60ns 1.5V

60ns 1.6V

75ns 1.6V

85ns 1.6V

75ns 1.6V

85ns 1.6V

100ns 1.6V

100ns

600V

RURD460

RURD660

RURD860

MUR860

MUR1560

RURP3060

RURG3060

RURG5060

RURG8060

RURU5060

RURU8060

RURU10060

RURU15060

RURD460S

RURD660S

RURD860S

RURP860

RURP1560

1.5V

60ns 1.5V

70ns 1.5V

60ns† 1.5V

60ns 1.5V

60ns 1.6V

75ns 1.6V

85ns 1.6V

75ns 1.6V

85ns 1.6V

100ns 1.6V

100ns

MUR870E

RURP1570

RURP3070

RURG3070

RURG5070

RURG8070

RURU5070

RURU8070

RURP870

1.8V

110ns 1.8V

125ns 1.8V

150ns 1.8V

150ns 1.9V

200ns 1.9V

200ns

MUR880E

RURP1580

RURP3080

RURG3080

RURG5080

RURG8080

RURU5080

RURU8080

RURP880

1.8V

110ns 1.8V

125ns 1.8V

150ns 1.8V

150ns 1.9V

200ns 1.9V

200ns

MUR890E

RURP1590

RURP3090

RURG3090

RURG5090

RURG8090

RURU5090

RURU8090

RURP890

1.8V

110ns 1.8V

125ns 1.8V

150ns 1.8V

150ns 1.9V

200ns 1.9V

200ns

MUR8100E RURP15100 RURP30100 RURG30100 RURG50100 RURG80100 RURU50100 RURU80100

RURP8100

1.8V

110ns 1.8V

125ns 1.8V

150ns 1.8V

150ns 1.9V

200ns 1.9V

200ns

RURU15070

1.9V

200ns

RURU15080

1.9V

200ns

RURU15090

1.9V

200ns

RURU150100

1.9V

200ns

700V

800V

900V

1000V

1200V

RURD4120

RURD6120

RURD4120S RURD6120S

2.1V

90ns 2.1V

90ns

RURP8120

RURP15120 RURP30120 RURG30120 RURG50120 RURG75120 RURU50120 RURU75120 RURU100120

RURU150120

2.1V

110ns 2.1V

130ns 2.1V

150ns 2.1V

150ns 2.1

200ns 2.1V

200ns

NOTE: V

F

at I

F(AVG)

, T

J

= 25

o

C; t

rr

at I

F(AVG)

, dI

F

/dt = 100A/µs or 200A/µs, T

J

= 25

o

C;

†

t

rr

at I

F

= 1A.

S E M I C O N D U C TO R

LC-1462.6
