Multi-layer Chip Inductors - Ferrite
SPECIFICATIONS
Please specify tolerance code when ordering.
CTML1206-R10_
J = ±5%, K = ±10%, M = ±20%
Part
Number
CTML1206-R047M
CTML1206-R068M
CTML1206-R082M
CTML1206-R10_
CTML1206-R12_
CTML1206-R15_
CTML1206-R18_
CTML1206-R22_
CTML1206-R27_
CTML1206-R33_
CTML1206-R39_
CTML1206-R47_
CTML1206-R56_
CTML1206-R68_
CTML1206-R82_
CTML1206-1R0_
CTML1206-1R2_
CTML1206-1R5_
CTML1206-1R8_
CTML1206-2R2_
CTML1206-2R7_
CTML1206-3R3_
CTML1206-3R9_
CTML1206-4R7_
CTML1206-5R6_
CTML1206-6R8_
CTML1206-8R2_
Inductance
(µH)
.047
.068
.082
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
L Test
Freq.
(MHz)
50
50
50
25
25
25
25
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
4.0
4.0
4.0
2.0
2.0
1.0
1.0
1.0
1.0
.40
Q
Factor
Min.
25
25
25
30
30
30
30
30
30
30
30
30
30
30
30
45
45
45
45
45
45
45
45
45
45
45
45
45
45
35
35
30
30
30
Q Test
Freq.
(MHz)
50
50
50
25
25
25
25
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
4.0
4.0
4.0
2.0
2.0
1.0
1.0
1.0
1.0
.40
SRF
Min.
(MHz)
320
280
250
235
250
200
185
170
150
145
135
125
115
105
100
75
65
60
55
50
45
41
38
35
32
29
26
24
22
19
18
16
14
13
Ver. 8.3
CTML1206 Series
From .047 µH to 33 µH
ENGINEERING KIT #17
Not shown at actual size.
DCR
Max.
Ω
(Ω)
.15
.25
.25
.25
.30
.30
.40
.50
.50
.60
.50
.60
.70
.80
.90
.40
.50
.50
.50
.60
.60
.70
.80
.90
.70
.90
.90
1.0
1.0
.70
.70
.90
.90
1.0
Rated
DC
(mA)
300
300
300
250
250
250
250
250
250
250
200
200
150
150
150
100
100
50
50
50
50
50
50
50
25
25
25
25
15
5.0
5.0
5.0
5.0
5.0
CHARACTERISTICS
Description:
Ferrite core, multi-layer chip inductor
Applications:
LC resonant circuits such as oscillator and signal
generators, RF filters, disk drives, audio and video equipment, TV,
radio and telecommunication equipment
Operating Temperature:
-55°C to +125°C
Inductance Tolerance:
±5%, ±10%, ±20%
Testing:
Inductance and Q are tested on an HP4285A or
HP4286A at specified frequency
Packaging:
Tape & Reel
Marking:
Reels marked with inductance code and tolerance
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
CTML1206-100_
CTML1206-120_
CTML1206-150_
CTML1206-180_
CTML1206-220_
CTML1206-270_
CTML1206-330_
PHYSICAL DIMENSIONS
Size
mm
inches
A
3.2±0.2
0.13±0.008
B
1.6±0.2
0.06±0.008
Max.
1.3
0.05
C
D
0.5±0.3
0.02±0.3
PAD LAYOUT
3.18.03
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2003 by CT Magnetics, DBA Central Technologies. All rights reserved.
24
CT Magnetics reserves the right to make improvements or change specifications without notice
