ASA1-1.000MHZ-E-K datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Passive components> oscillator> ASA1-1.000MHZ-E-K

Preview

ASA1-1.000MHZ-E-K: DescriptionHCMOS/TTL Output Clock Oscillator, 1MHz Min, 80MHz Max, 1MHz Nom, ROHS COMPLIANT, ULTRA MINIATURE, HERMETIC SEALED PACKAGE-4; CategoryPassive components oscillator; File Size1MB，2 Pages; ManufacturerAbracon; Websitehttp://www.abracon.com/index.htm; Environmental Compliance

Download Datasheet Parametric View All

ASA1-1.000MHZ-E-K Overview

HCMOS/TTL Output Clock Oscillator, 1MHz Min, 80MHz Max, 1MHz Nom, ROHS COMPLIANT, ULTRA MINIATURE, HERMETIC SEALED PACKAGE-4

ASA1-1.000MHZ-E-K Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Abracon
package instruction	ROHS COMPLIANT, ULTRA MINIATURE, HERMETIC SEALED PACKAGE-4
Reach Compliance Code	compliant
Other features	TRI-STATE; STANDBY; BULK
maximum descent time	10 ns
Frequency Adjustment - Mechanical	NO
frequency stability	30%
Manufacturer's serial number	ASA
Installation features	SURFACE MOUNT
Number of terminals	4
Maximum operating frequency	80 MHz
Minimum operating frequency	1 MHz
Nominal operating frequency	1 MHz
Maximum operating temperature	70 °C
Minimum operating temperature	-20 °C
Oscillator type	HCMOS/TTL
Output load	2 TTL, 15 pF
Package body material	METAL
Encapsulate equivalent code	SOLCC4,.06
physical size	2.0mm x 1.6mm x 0.7mm
power supply	2.5 V
Certification status	Not Qualified
longest rise time	10 ns
Maximum supply voltage	2.75 V
Minimum supply voltage	2.25 V
Nominal supply voltage	2.5 V
surface mount	YES
maximum symmetry	40/60 %

Preview

Download Datasheet

View All

HCMOS SURFACE-MOUNT CRYSTAL CLOCK OSCILLATOR

ASA SERIES

FEATURES:

• Ultra miniature package,

2.0 x 1.6 x 0.7mm

•

Tri-state function

• Suitable for high density SMT

Parameters

Frequency Range

Operating Temperature

Storage Temperature

Overall Frequency Stability*

Supply Voltage (Vdd)

Vdd = 3.3 V

Moisture Sensitivity Level (MSL) – This product is

Hermetically Sealed and not Moisture Sensitive -

MSL = N/A: Not Applicable

Pb

RoHS/RoHS II Compliant

2.0 x 1.6 x 0.7m m

| | | | | | | | | | | | |

| |

APPLICATIONS:

• Suitable for RoHS compliant

reflow process

• Seam sealed package assures

high reliability

Minimum

1.0

-10

-40

-50

2.97

2.25

1.62

Typical

• CCD clock for

VTR camera

• Computers and peripherals

• Portable electronics

• Mobile communication, PDA

Maximum

80

+60

+85

+50

3.66

2.75

1.98

5.0

10.0

15.0

5.0

10.0

5.0

10.0

15

2

0.1*Vdd

0.4

+3.0

60

55

10.0

ppm

%

ms

ns

Units

MHz

°C

ppm

V

Notes

See options

Standard

Option 1 (CMOS )

Option 2 (CMOS)

STANDARD SPECIFICATIONS:

Supply Current (I

dd

)

into 15pF Load

Vdd = 2.5 V

Vdd = 1.8 V

3.3

2.5

1.8

2.0

4.0

7.0

2.0

3.0

5.0

1.5

2.5

4.0

mA

Output Load

Output Voltage

Tri-state function

Aging

Symmetry @1/2Vdd

Start-up Time

Rise/Fall Time (Tr/Tf)

V

OH

V

OL

V

OH

V

OL

0.9*Vdd

2.4

pF

TTL

V

1MHz

<

F

<

20 MHz

<

F

<

50 MHz

<

F

<

80 MHz

1MHz

<

F

<

20 MHz

<

F

<

50 MHz

<

F

<

80 MHz

1MHz

<

F

<

20 MHz

<

F

<

50 MHz

<

F

<

80 MHz

"1" (VIH≥0.7*Vdd) or Open : Oscillation

"0" (VIH<0.3*Vdd) :

Hi

Z

CMOS

TTL

@+25°C First year

Standard

Option S

-3.0

40

45

50

*Overall frequency stability includes initial frequency tolerance @+25°C and stability over the operating temperature.

OPTIONS AND PART IDENTIFICATION:

(Left blank if standard)

ASA

-

MHz -

-

Packaging

Blank: Bulk

T: Tape & Reel (1kpcs)

T3: Tape & Reel (3kpcs)

Supply Voltage

Blank: 3.3V±10%

1: 2.5 V±10%

2: 1.8 V±10%

Frequency in MHz

Please

specify the

frequency in MHz.

e.g. 14.31818MHz

Operating Temp.

Blank: -10°C ~ +60°C

E: -20°C ~ +70°C

L: -40°C ~ +85°C

Overall Freq. Stability

Blank: ±50ppm

R**: ±25ppm

K***: ±30 ppm

Blank: 40/60% @1/2Vdd

S: 45/55% @1/2Vdd

Symmetry

**Available for -10 to +60°C only

***Available for -10 to +60°C, option E only

Contact Abracon for tighter frequency stability options

ABRACON IS

ISO9001:2008

CE RTIFIED

Revised: 01.24.14

30332 Esperanza, Rancho Santa Margarita, California 92688

tel 949-546-8000

|

fax 949-546-8001

| www.abracon.com

Visit

www.abracon.com

for Terms & Conditions of Sale
