1N5246B datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> 1N5246B

1N5246B: Description16 V, 0.5 W, SILICON, UNIDIRECTIONAL VOLTAGE REGULATOR DIODE, DO-35; CategoryDiscrete semiconductor diode; File Size200KB，3 Pages; ManufacturerLGE; Websitehttp://www.luguang.cn/web_en/index.html

Download Datasheet Parametric View All

1N5246B Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1N5246B	-	-	View	Buy Now

1N5246B Overview

16 V, 0.5 W, SILICON, UNIDIRECTIONAL VOLTAGE REGULATOR DIODE, DO-35

1N5246B Parametric

Parameter Name	Attribute value
Parts packaging code	DO-35
Manufacturer packaging code	DO-35

Preview

Download Datasheet

View All

1N5221B-1N5279B

Zener Diodes

POWER DISSIPATION: 500 mW

DO-35(GLASS)

Features

Silicon planar power zener diodes

Standard Zener voltage tolerance is ±5%. With a "B"

suffix. Other tolerances are available upon request.

Mechanical Data

Case:DO-35, Glass Case

Terminals: Solderable per MIL-STD-202, Method 208

Polarity: Cathode Band

Marking: Type Number

Approx. Weight: 0.13 grams.

Dimensions in millimeters

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25

ambient temperature unless otherwise specified.

Single phase,half wave,60 Hz,resistive or inductive load. For capacitive load,derate by 20%.

SYMBOL

Zener current (see Table "Characteristics")

VALUE

UNIT

Pow er dissipation at T

amb

=25

tot

500

175

-55---+175

Junction temperature

Storage temperature

range

SYMBOL

Thermal resistance junction to ambient

MIN

TYP

MAX

300

1.2

UNIT

Forw ard voltage at I

=200mA

NOTES:

(1) Valid provided that leads at a distance of 10 mm from case are kept at ambient temperature.

http://www.luguang.cn

mail:lge@luguang.cn
