TD1N5224D: DescriptionZener Diode, 2.8V V(Z), 1%, 0.5W, Silicon, Unidirectional, DO-35, HERMETIC SEALED, GLASS PACKAGE-2; CategoryDiscrete semiconductor diode; File Size180KB，7 Pages; ManufacturerTak Cheong; Websitehttp://www.takcheong.com/

Download Datasheet Parametric View All

TD1N5224D Overview

Zener Diode, 2.8V V(Z), 1%, 0.5W, Silicon, Unidirectional, DO-35, HERMETIC SEALED, GLASS PACKAGE-2

TD1N5224D Parametric

Parameter Name	Attribute value
Maker	Tak Cheong
Parts packaging code	DO-35
package instruction	HERMETIC SEALED, GLASS PACKAGE-2
Contacts	2
Reach Compliance Code	unknown
ECCN code	EAR99
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
JEDEC-95 code	DO-35
JESD-30 code	O-LALF-W2
Number of components	1
Number of terminals	2
Maximum operating temperature	200 °C
Package body material	GLASS
Package shape	ROUND
Package form	LONG FORM
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.5 W
Certification status	Not Qualified
Nominal reference voltage	2.8 V
surface mount	NO
technology	ZENER
Terminal form	WIRE
Terminal location	AXIAL
Maximum voltage tolerance	1%
Working test current	20 mA

Preview

Download Datasheet

View All

TAK CHEONG

SE M I CO N DU CTO R

500 mW DO-35 Hermetically

Sealed Glass Zener Voltage

Regulators

Absolute Maximum Ratings

Parameter

Power Dissipation

Storage Temperature Range

Operating Junction Temperature

Lead Temperature (1/16” from case for 10 seconds)

= 25°C unless otherwise noted

Value

500

-65 to +200

+200

+230

Units

°C

AXIAL LEAD

DO35

DEVICE MARKING DIAGRAM

: Logo

Device Code : TC1N52xxT

Tolerance (T) : A =

10%

B = 5%

C = 2%

D = 1%

These ratings are limiting values above which the serviceability of the diode may be impaired.

Specification Features:

Zener Voltage Range 2.4 to 56 Volts

DO-35 Package (JEDEC)

Through-Hole Device Type Mounting

Hermetically Sealed Glass

Compression Bonded Construction

All external surfaces are corrosion resistant and leads are readily solderable

Cathode indicated by polarity band

Cathode

Anode

ELECTRICAL SYMBOL

Electrical Characteristics

Device Type

TC1N5221B

TC1N5222B

TC1N5223B

TC1N5224B

TC1N5225B

TC1N5226B

TC1N5227B

TC1N5228B

TC1N5229B

TC1N5230B

TC1N5231B

TC1N5232B

TC1N5233B

TC1N5234B

TC1N5235B

TC1N5236B

TC1N5237B

TC1N5238B

TC1N5239B

TC1N5240B

TC1N5241B

TC1N5242B

TC1N5243B

TC1N5244B

@ I

(Volts)

Nominal

2.4

2.5

2.7

2.8

3.3

3.6

3.9

4.3

4.7

5.1

5.6

6.2

6.8

7.5

8.2

8.7

9.1

= 25°C unless otherwise noted

(mA)

9.5

@ I

(Ω)

Max

@ I

= 0.25mA

(Ω)

Max

1200

1250

1300

1400

1600

1700

1900

2000

1900

1600

1000

750

500

600

@ V

(µA)

Max

100

0.5

0.1

(Volts)

3.5

6.5

8.4

9.1

9.9

June 2004 / C

Page 1

TC1N5221B through TC1N5263B Series
