TERMINALS
Material:
Insulating housing: Polyamide 6 ivory
Hardness test at 125 °C
Glow-wire test with 850 °C
Tracking test PTI 250
Clamping body: nickel-plated brass
Wire protection: phosphor bronze
Clamping screws: steel, zinc-plated and
dichromated
These terminal strips are designed for use
under extreme conditions according to
EN 60335-1/ DIN VDE 0700 T1.
Terminals with wire protection DS are fitted
with a wire protection guard inside the
clamping body, which prevents damage to
the connected wire.
The clamping screws are secured against
loosening and provide vibration-proof
connections.
Unbreakable terminal strips for compact spaces,
Type
KL 16 PA
M3
5.5
Type KL 16 PA 2.5 mm
2
without wire protection
DIN VDE 0110 (fixed position)
UL ratings
CSA ratings
EN 60335-1/DIN VDE 0700 T1
Approvals
Poles
G
T
Type KL 16 PA 2.5 mm
2
with wire protection (DS)
500 V/6 kV/3
No. 22-12 AWG
No. 22-12 AWG
AC 400 V; 10 A;
250 V 20 A
300 V 25 A
1 – 1.5 mm
2
/1 – 2.5 mm
2
Std. Pack
500 V/6 kV/3
No. 22-12 AWG
No. 22-12 AWG
AC 400 V; 10 A;
xqw
Type
250 V 20 A
300 V 25 A
1 – 1.5 mm
2
/1 – 2.5 mm
2
Std. Pack
Part No.
xqw
Type
Part No.
4
6
8
12
16
20
33.4
44.2
55
76.6
98.2
119.8
27
37.8
48.6
70
91.8
113.4
KL 16/4 PA
KL 16/6 PA
KL 16/8 PA
KL 16/12 PA
KL 16/16 PA
KL 16/20 PA
29.400.0453.0
29.400.0653.0
29.400.0853.0
29.400.1253.0
29.400.1653.0
29.400.2053.0
65
50
40
30
20
20
KL 16/4 PA DS
KL 16/6 PA DS
KL 16/8 PA DS
KL 16/12 PA DS
KL 16/16 PA DS
KL 16/20 PA DS
29.401.0453.0
29.401.0653.0
29.401.0853.0
29.401.1253.0
29.401.1653.0
29.401.2053.0
65
50
40
30
20
20
Accessories
Marking plate, white PVC,
marking surface on both sides
and four plastic pins polyamide
to fasten the marking plate
4
6
8
12
16
20
Fastening pins
Marked marking plates,
4 to 20 pole
4
to
20
Jumper bars of E-Cu
80
2
428.6
7.4
BZKL 16/4 ZB
to
BZKL 16/20 ZB
33.4
44.2
55
76.6
98.2
119.8
27
37.8
48.6
70
91.8
113.4
BZKL 16/4 Z
BZKL 16/6 Z
BZKL 16/8 Z
BZKL 16/12 Z
BZKL 16/16 Z
BZKL 16/20 Z
Z4.102.0480.0
Z4.102.0680.0
Z4.102.0880.0
Z4.102.1280.0
Z4.102.1680.0
Z4.102.2080.0
05.592.1152.0
Z4.802.0480.0
to
Z4.802.2080.0
07.250.1627.0
07.250.0027.0
100
10
10
100
100
100
100
100
100
400
100
BZKL 16/4 ZB
to
BZKL 16/20 ZB
BZKL 16/4 Z
BZKL 16/6 Z
BZKL 16/8 Z
BZKL 16/12 Z
BZKL 16/16 Z
BZKL 16/20 Z
Z4.102.0480.0
Z4.102.0680.0
Z4.102.0880.0
Z4.102.1280.0
Z4.102.1680.0
Z4.102.2080.0
05.592.1152.0
Z4.802.0480.0
to
Z4.802.2080.0
07.250.1627.0
07.250.0027.0
100
10
10
100
100
100
100
100
100
400
100
1386
Subject to change without further notice
