NAND FLASH MEMORY
e
•MMC
TM
Cost Effective Mass Storage
eMMC™
is a family of advanced and highly
efficient NAND flash memory with an integrated
controller and enhanced memory management.
Based on an interface standardized by JEDEC,
Toshiba’s
eMMC™
offers the optimal solution for
applications where higher data volume needs to be
stored in a cost efficient way. It is fully compliant with
the Multimedia Card Association (MMCA) high speed
memory interface standard.
APPLICATIONS
•
•
•
•
Industrial Applications
Consumer Electronics
Multimedia Applications
Smart Metering & Intelligent Lighting
FEATURES
•
•
•
•
•
ADVANTAGES
•
BENEFITS
•
•
•
4GByte – 64GByte
19nm and new advanced A19nm
Multi level cell architecture
Conforms to the latest JEDEC
Version 4.5 and 5.0
Integrated memory management
•
Error correction code
•
Bad block management
•
Wear-leveling
•
Garbage collection
Standard and extended temperature
range
FBGA package
•
•
•
•
Higher Interface speed according to
JEDEC 5.0
•
Read Speed up to 275MB/s
•
Write Speed up to 90MB/s
Managed memory
Package, interface, features,
commands etc. are standard
Utilizing high quality Toshiba MLC
NAND flash memory in combination
with a Toshiba origin developed
controller
Produced in the world’s largest,
leading edge technology flash
factory
•
•
•
•
Easy to integrate storage
solution due to established
standards
Cost efficient design in
Optimal relation between
price, density and
performance
Reliable storage solution
based on high quality MLC
memory and optimized
controller
Extended production capacity
to fulfil customers demand
SPECIFICATIONS
Product / Features
Density
Technology
JEDEC Version
Temperature
Package
eMMC™
4GByte – 64GByte
A19nm
5.0
-25°C to +85°C
FBGA
Extended Temp.
eMMC™
4GByte – 32GByte
19nm
4.5
-40°C to +85°C
www.toshiba-components.com
www.toshiba-components.com
e•
MMC
TM
– PRODUCT LIST
Density
4GByte
8GByte
16GByte
32GByte
64GByte
*Valid Q22014
Item Name
THGBMBG5D1KBAIT
THGBMAG5A1JBAWR
THGBMBG6D1KBAIL
THGBMAG6A2JBAWR
THGBMBG7D2KBAIL
THGBMAG7B2JBAWM
THGBMBG8D4KBAIR
THGBMAG8B4JBAWM
THGBMBG9D8KBAIG
Technology
A19nm
19nm
A19nm
19nm
A19nm
19nm
A19nm
19nm
A19nm
JEDEC Standard
JEDEC 5.0
JEDEC 4.5
JEDEC 5.0
JEDEC 4.5
JEDEC 5.0
JEDEC 4.5
JEDEC 5.0
JEDEC 4.5
JEDEC 5.0
Temperature
-25°C to 85°C
-40°C to 85°C
-25°C to 85°C
-40°C to 85°C
-25°C to 85°C
-40°C to 85°C
-25°C to 85°C
-40°C to 85°C
-25°C to 85°C
Package
153FBGA 11x10
153FBGA 11.5x13
153FBGA 11.5x13
153FBGA 11.5x13
153FBGA 11.5x13
169FBGA 12x16
153FBGA 11.5x13
169FBGA 12x16
153FBGA 11.5x13
e
•MMC
TM
– ENHANCED USER DATA AREA
Toshiba eMMC™ products support the JEDEC compliant “Enhanced User Data Area”, also called “Pseudo-SLC”.
For applications requiring a part of the memory to perform with higher write/erase cycles than MLC NAND, eMMC™
provides the option to build a partition which offers “pseudo-SLC“ performance. The normal MLC mode can be
changed to the more reliable “pseudo SLC” mode.
INNOVATION IS OUR TRADITION: FLASH MEMORY AND MORE
In 1984, Toshiba developed a new type of semiconductor memory called flash memory, leading the industry into the
next generation ahead of its competitors.
Some time later in 1987, NAND flash memory was developed, and this has since been used in a variety of memory
cards and electronic equipments. The NAND flash market has grown rapidly, with flash memory becoming an
internationally standardized memory device. Toshiba, the inventor of flash memory, has carved out a path to a new
era in which we are all able to carry videos, music and data with us wherever we go.
e
MMC™ is the trademark of JEDEC/MMCA
Copyright 2014 TOSHIBA corporation.
