5876BK005 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> Connector bracket> 5876BK005

5876BK005: DescriptionWire And Cable, 19 Conductor(s), 20AWG, 1000V, Flexible Cord And Fixture Wire, ROHS AND REACH COMPLIANT; CategoryThe connector Connector bracket; File Size241KB，3 Pages; ManufacturerAlpha Wire; Websitehttp://www.alphawire.com/zh-CN/; Environmental Compliance

Download Datasheet Parametric Compare View All

5876BK005 Overview

Wire And Cable, 19 Conductor(s), 20AWG, 1000V, Flexible Cord And Fixture Wire, ROHS AND REACH COMPLIANT

5876BK005 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	ROHS AND REACH COMPLIANT
Reach Compliance Code	compli
Other features	STANDARD: MIL-W-16878/5
Certification	MIL, UL
Conductor surface treatment	SILVER
conductor material	COPPER
Connector bracket type	WIRE AND CABLE
structure	STRANDED
diameter	1.73 mm
insulator material	PTFE
length	30.48 mm
Number of conductors	19
Maximum operating temperature	200 °C
Minimum operating temperature	-60 °C
Rated voltage	1000 V
resistance	0.029 Ω
shield	NO
stay	19X32
Wire gauge	20 AWG
Wire and Cable Names	FLEXIBLE CORD AND FIXTURE WIRE
Base Number Matches	1

Preview

Download Datasheet

View All

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com

Customer Specification

PART NO. 5876

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

(1) Color(s)

1 X 1 HOOKUP

20 (19/32) AWG SPC

0.014" Wall, Nom. PTFE

0.040

0.068+/- 0.004

WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN

ORANGE, SLATE, VIOLET

Applicable Specifications

1) UL

2) Military

3) Other

AWM/STYLE 1180

MIL-W-16878/5 (Type EE)

NEMA HP3-EEXBGE

200°C / 300 VRMS

200°C / 1000 VRMS

Environmental

1) EU Directive 2011/65/EU(RoHS2):

All materials used in the manufacture of this part are in compliance with European Directive

2011/65/EU regarding the restriction of use of certain hazardous substances in electrical and

electronic equipment. Consult Alpha Wire's web site for RoHS C of C.

2) REACH Regulation (EC 1907/2006):

This product does not contain Substances of Very High Concern (SVHC) listed on the European

Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information,

please see Alpha's REACH SVHC Declaration.

3) California Proposition 65:

The outer surface materials used in the manufacture of this part meet the requirements of

California Proposition 65.

Properties

Physical & Mechanical Properties

1) Temperature Range

2) Bend Radius

3) Pull Tension

Electrical Properties

1) Voltage Rating

2) Inductance

3) Conductor DCR

-60 to 200°C

10X Cable Diameter

9.6 Lbs, Maximum

(For Engineering purposes only)

1000 V

RMS

0.05 µH/ft, Nominal

8.7 Ω/1000ft @20°C, Nominal

Other

Packaging

a) 1000 FT

b) 100 FT

Flange x Traverse x Barrel (inches)

6.5 x 4 x 2.5 Max. 3 separate pieces; Min length/piece 100 FT.

2.75 x 2 x 1.125 Continuous length

[Spool dimensions may vary slightly]

Notes:

a) Certain colors and put-up combinations may only be available by special order, minimums may apply.

www.alphawire.com

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742)

Although Alpha Wire (“Alpha”) makes every reasonable effort to ensure their accuracy at the time of publication, information and specifications

described herein are subject to errors or omissions and to changes without notice, and the listing of such information and specifications does not

ensure product availability.

Alpha provides the information and specifications herein on an “AS IS” basis, with no representations or warranties, whether express, statutory or

implied. In no event will Alpha be liable for any damages (including consequential, indirect, incidental, special, punitive, or exemplary) whatsoever,

even if Alpha had been advised of the possibility of such damages, whether in an action under contract, negligence or any other theory, arising out

of or in connection with the use, or inability to use, the information or specifications described herein.

ALPHA WIRE - CONFIDENTIAL AND PROPRIETARY

Notice to persons receiving this document and/or technical information. This document is confidential and is the exclusive property of ALPHA WIRE,

and is merely on loan and subject to recall by ALPHA WIRE at any time. By taking possession of this document, the recipient acknowledges and

agrees that this document cannot be used in any manner adverse to the interests of ALPHA WIRE, and that no portion of this document may be

copied or otherwise reproduced without the prior written consent of ALPHA WIRE. In the case of conflicting contractual provisions, this notice shall

5876BK005 Related Products

	5876BK005	5876BL005	5876BL001	5876BR001	5876BR005	5876BK001	5876GR005	5876SL001	5876OR001
Description	Wire And Cable, 19 Conductor(s), 20AWG, 1000V, Flexible Cord And Fixture Wire, ROHS AND REACH COMPLIANT	Wire And Cable, 19 Conductor(s), 20AWG, 1000V, Flexible Cord And Fixture Wire, ROHS AND REACH COMPLIANT	Wire And Cable, 19 Conductor(s), 20AWG, 1000V, Flexible Cord And Fixture Wire, ROHS AND REACH COMPLIANT	Wire And Cable, 19 Conductor(s), 20AWG, 1000V, Flexible Cord And Fixture Wire, ROHS AND REACH COMPLIANT	Wire And Cable, 19 Conductor(s), 20AWG, 1000V, Flexible Cord And Fixture Wire, ROHS AND REACH COMPLIANT	Wire And Cable, 19 Conductor(s), 20AWG, 1000V, Flexible Cord And Fixture Wire, ROHS AND REACH COMPLIANT	Wire And Cable, 19 Conductor(s), 20AWG, 1000V, Flexible Cord And Fixture Wire, ROHS AND REACH COMPLIANT	Wire And Cable, 19 Conductor(s), 20AWG, 1000V, Flexible Cord And Fixture Wire, ROHS AND REACH COMPLIANT	Wire And Cable, 19 Conductor(s), 20AWG, 1000V, Flexible Cord And Fixture Wire, ROHS AND REACH COMPLIANT
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to
package instruction	ROHS AND REACH COMPLIANT	ROHS AND REACH COMPLIANT	ROHS AND REACH COMPLIANT	ROHS AND REACH COMPLIANT	ROHS AND REACH COMPLIANT	ROHS AND REACH COMPLIANT	ROHS AND REACH COMPLIANT	ROHS AND REACH COMPLIANT	ROHS AND REACH COMPLIANT
Reach Compliance Code	compli	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant
Other features	STANDARD: MIL-W-16878/5	STANDARD: MIL-W-16878/5	STANDARD: MIL-W-16878/5	STANDARD: MIL-W-16878/5	STANDARD: MIL-W-16878/5	STANDARD: MIL-W-16878/5	STANDARD: MIL-W-16878/5	STANDARD: MIL-W-16878/5	STANDARD: MIL-W-16878/5
Certification	MIL, UL	MIL, UL	MIL, UL	MIL, UL	MIL, UL	MIL, UL	MIL, UL	MIL, UL	MIL, UL
Conductor surface treatment	SILVER	SILVER	SILVER	SILVER	SILVER	SILVER	SILVER	SILVER	SILVER
conductor material	COPPER	COPPER	COPPER	COPPER	COPPER	COPPER	COPPER	COPPER	COPPER
Connector bracket type	WIRE AND CABLE	WIRE AND CABLE	WIRE AND CABLE	WIRE AND CABLE	WIRE AND CABLE	WIRE AND CABLE	WIRE AND CABLE	WIRE AND CABLE	WIRE AND CABLE
structure	STRANDED	STRANDED	STRANDED	STRANDED	STRANDED	STRANDED	STRANDED	STRANDED	STRANDED
diameter	1.73 mm	1.73 mm	1.73 mm	1.73 mm	1.73 mm	1.73 mm	1.73 mm	1.73 mm	1.73 mm
insulator material	PTFE	PTFE	PTFE	PTFE	PTFE	PTFE	PTFE	PTFE	PTFE
length	30.48 mm	30.48 mm	304.8 mm	304.8 mm	30.48 mm	304.8 mm	30.48 mm	304.8 mm	304.8 mm
Number of conductors	19	19	19	19	19	19	19	19	19
Maximum operating temperature	200 °C	200 °C	200 °C	200 °C	200 °C	200 °C	200 °C	200 °C	200 °C
Minimum operating temperature	-60 °C	-60 °C	-60 °C	-60 °C	-60 °C	-60 °C	-60 °C	-60 °C	-60 °C
Rated voltage	1000 V	1000 V	1000 V	1000 V	1000 V	1000 V	1000 V	1000 V	1000 V
resistance	0.029 Ω	0.029 Ω	0.029 Ω	0.029 Ω	0.029 Ω	0.029 Ω	0.029 Ω	0.029 Ω	0.029 Ω
shield	NO	NO	NO	NO	NO	NO	NO	NO	NO
stay	19X32	19X32	19X32	19X32	19X32	19X32	19X32	19X32	19X32
Wire gauge	20 AWG	20 AWG	20 AWG	20 AWG	20 AWG	20 AWG	20 AWG	20 AWG	20 AWG
Wire and Cable Names	FLEXIBLE CORD AND FIXTURE WIRE	FLEXIBLE CORD AND FIXTURE WIRE	FLEXIBLE CORD AND FIXTURE WIRE	FLEXIBLE CORD AND FIXTURE WIRE	FLEXIBLE CORD AND FIXTURE WIRE	FLEXIBLE CORD AND FIXTURE WIRE	FLEXIBLE CORD AND FIXTURE WIRE	FLEXIBLE CORD AND FIXTURE WIRE	FLEXIBLE CORD AND FIXTURE WIRE
Base Number Matches	1	1	1	1	1	1	-	-	-
Maker	-	Alpha Wire	Alpha Wire	Alpha Wire	Alpha Wire	Alpha Wire	Alpha Wire	Alpha Wire	Alpha Wire
Is Samacsys	-	N	N	N	N	N	-	-	-
