237-033
Jam Nut Mount Hermetic with Double O-Rings
Plug/Receptacle Bulkhead Feedthrough
for MIL-DTL-38999 Series III Type
MIL-DTL-38999 Type
Hermetic Connectors
B
Connector Material and Finish
Z1
- CRES, Passivated
P
- CRES, Nickel Finish
Connector Series
233
-
D38999 Series III Type
Insert
Arrangement
Per
MIL-DTL-38999
Series III
MIL-STD-1560
Polarization
A, B, C, D, E
(N = Normal)
237
-
033
Connector Type
003
-
Hermetic
Bulkhead Feedthrough
Z1
9
-
35
D
N
Shell Size
(See Table I)
Contact Termination Style
P
- Pin, Solder Cup
S
- Socket, Solder Cup
X
- Pin, Eyelet
Z
- Socket, Eyelet
C
- Pin, PCB
D
- Socket, Feedthrough
L Max
Master
Keyway
90°/85°
ØB
Socket
Face
.889 (22.6) Max
H
Panel
Thickness
J
O-Rings
(Not Supplied)
Solder Cup
Contact (P & S)
Eyelet
Contact (X & Z)
Feed Through
Contact (C & D)
D
Flat
E
Dia
P
(See Table III)
F
Di
a
Pin Face
A Thread
G Thread
Nut
Per D38999/28
M Max
.382 (9.7)
M x
.175/.125 (4.4/3.2)
a
Dimensions in Inches (millimeters) are subject to change without notice.
© 2013 Glenair, Inc.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
B-58
E-Mail: sales@glenair.com
237-033
Jam Nut Mount Hermetic with Double O-Rings
Plug/Receptacle Bulkhead Feedthrough
for MIL-DTL-38999 Series III Type
TABLE I: Shell Size, Thread and Connector Dimensions (Continued Below)
Shell
Size
Code
A
B
C
D
E
F
G
H
J
Shell
Size
9
11
13
15
17
19
21
23
25
A Thread
-0.1P-0.03L-TS
.6250
.7500
.8750
1.0000
1.1875
1.2500
1.3750
1.5000
1.6250
B Dia
1.270/1.260
(32.26/32.00)
1.385/1.375
(35.18/34.93)
1.585/1.575
(40.26/40.01)
1.700/1.690
(43.18/42.93)
1.860/1.850
(47.24/46.99)
1.975/1.965
(50.17/49.91)
2.095/2.085
(53.21/52.96)
2.213/2.203
(56.21/55.96)
2.325/2.315
(59.06/58.80)
D Flat
.654/.645
(16.61/16.38)
.754/.745
(19.15/18.92)
.941/.932
(23.90/23.67)
1.065/1.056
(27.05/26.82)
1.190/1.181
(30.23/30.00)
1.315/1.306
(33.40/33.17)
1.440/1.431
(36.58/36.35)
1.565/1.556
(39.75/39.52)
1.690/1.681
(42.93/42.70)
E Dia
.614/.591
(15.60/15.01)
.736/.713
(18.69/18.11)
.862/.839
(21.89/21.31)
.988/.965
(25.10/24.51)
1.114/1.091
(28.30/27.71)
1.240/1.217
(31.50/30.91)
1.362/1.339
(34.59/34.01)
1.488/1.465
(37.80/37.21)
1.614/1.591
(41.0/40.41)
F Dia
.653/.642
(16.59/16.31)
.775/.764
(19.69/19.41)
.905/.894
(22.99/22.71)
1.031/1.020
(26.19/25.91)
1.153/1.142
(29.29/29.01)
1.278/1.268
(32.46/32.21)
1.405/1.394
(35.69/35.41)
1.531/1.520
(38.89/38.61)
1.653/1.642
(41.99/41.71)
G Thread
ISO Metric
x 1.0-6g
M17
M20
M25
M28
M32
(See Note 2)
M35
M38
M41
M44
K Dia
N
Recommended Panel
Cut-out
TABLE I: (Continued from Above)
Shell
Size
Code
A
B
C
D
E
F
G
H
J
Shell
Size
9
11
13
15
17
19
21
23
25
H
.125/.062
(3.18/1.57)
.125/.062
(3.18/1.57)
.125/.062
(3.18/1.57)
.125/.062
(3.18/1.57)
.125/.062
(3.18/1.57)
.125/.062
(3.18/1.57)
.125/.062
(3.18/1.57)
.125/.062
(3.18/1.57)
.125/.062
(3.18/1.57)
J
.114/.098
(2.90/2.49)
.114/.098
(2.90/2.49)
.114/.098
(2.90/2.49)
.114/.098
(2.90/2.49)
.114/.098
(2.90/2.49)
.146/.130
(3.71/3.30)
.146/.130
(3.71/3.30)
.146/.130
(3.71/3.30)
.146/.130
(3.71/3.30)
K
Dia
.710/.700
(18.03/17.78)
.832/.822
(21.13/20.88)
1.017/1.007
(25.83/25.58)
1.144/1.134
(29.06/28.80)
1.271/1.261
(32.28/32.03)
1.394/1.384
(35.41/35.15)
1.517/1.507
(38.53/28.28)
1.644/1.634
(41.76/41.50)
1.746/1.736
(44.35/44.09)
L
Max
M Max
P and X
S and Z
N
.670/.660
(17.02/16.76)
.769/.759
(19.53/19.28)
.955/.945
(24.26/24.0)
1.149 (29.18) .208 (5.28) .232 (5.89)
1.149 (29.18) .208 (5.28) .232 (5.89)
1.153 (29.29) .200 (5.08) .224 (5.69)
TABLE III:
Contact Size
and Diameter
Contact
Size
22D
20
16
12
10
ØP
.011/.015
(0.28/0.38)
.024/.028
(0.61/0.71)
.0635/.0615
(1.61/1.56)
.095/.093
(2.41/2.36)
.126/.124
(3.20/3.15)
1.084/1.074
1.153 (29.29) .200 (5.08) .224 (5.69)
(27.53/27.28)
1.153 (29.29) .200 (5.08) .224 (5.69)
1.208/1.198
(30.68/30.4)
1.333/1.323
1.185 (30.10) .200 (5.08) .224 (5.69)
(33.86/33.60)
1.185 (30.10) .200 (5.08) .224 (5.69)
1.459/1.449
(37.06/36.80)
1.580/1.570
1.185 (30.10) .200 (5.08) .224 (5.69)
(40.13/39.88)
1.185 (30.10) .200 (5.08) .224 (5.69)
1.709/1.699
(43.41/43.15)
APPLICATION NOTES
1.
2.
3.
Assembly identified with manufacturer's name and P/N, space permitting.
Modified major diameter 31.95-31.80 (1.257-1.252).
Glenair 237-033 receptacle conector is designed to mate with and QPL
manufacturer's MIL-DTL-38999 Series III plug connector having the same insert
arrangement and polarization.
Glenair 237-033 same as D38999/23 except double O-Ring configuration.
5.
Material/finish:
Shell, nut –
CRES/passivated or CRES/nickel per QQ-N-290.
Contacts – Nickel iron alloy 52/gold.
Insulator – fused vitreous glass/N.A.
Seals – fluorosilicone rubber/N.A.
Metric dimensions (mm) are indicated in parentheses.
4.
6.
