Low Cost, Low Jitter, Fast Delivery
HCMOS 5x3.2mm 3.3V Oscillator
Model: FXO-HC53 SERIES
Page 1 of 2
RoHS Compliant / Pb Free
Rev. 9/6/2006 Preliminary
http://www.foxonline.com/need_a_sample.htm
1-888-XpressO
Part Number
767-Frequency-xxxxx
MODEl SElECTION GuIDE
F X O - H C 5 3 0 R - 106.250000
H = HCMOS
C = Ceramic
5 = 5x3.2mm
3 = 3.3V
Frequency
Blank = -20~+70ºC
R = -40~+85ºC
0 = ±100PPM
5 = ±50PPM
6 = ±25PPM
8 = ±20PPM (-20~+70ºC only)
1.2
Pin 1 Designator
(FOX Head or Dot)
#1
#2
#3
5.15 Max
#6
#5
#4
X
PRESS
O
3.35 Max
1.4 Max
2.54
• ElECTRICAl CHARACTERISTICS
PARAMETERS
MAX
(unless otherwise noted)
1.000 ~ 250.000 MHz
See above table
-55ºC ~ +125ºC
3.3V ± 5%
40mA
60mA
45% ~ 55%
3nS
3nS
Frequency Range (F
o
)
Frequency Stability
1
Storage Temperature Range (T
stg
)
Supply Voltage (V
dd
)
1.000 ~ 50.000
Input Current
(I
dd
)
50.000+ ~ 250.000
Output Symmetry (50% V
dd
Level)
Rise Time (T
r
) (10% ~ 90% V
dd
) 1.000 ~ 150.000
(20% ~ 80% V
dd
) 150.000+ ~ 250.000
Fall Time (T
f
) (90% ~ 10% V
dd
) 1.000 ~ 150.000
(80% ~ 20% V
dd
) 150.000+ ~ 250.000
Output Voltage
(V
ol
)
1.000 ~ 150.000
150.000+ ~ 250.000
(V
oh
)
1.000 ~ 150.000
150.000+ ~ 250.000
0.64 Typ.
Recommended
Solder Pad Layout
2.54
2.1
1.27
10% V
dd
20% V
dd
90% V
dd
M
in
80% V
dd
M
in
0.8
Actual Marking Depicted
All dimensions are in millimeters.
Output Load
(HCMOS)
Start-up Time
(T
s
)
Output Enable / Disable Time
2
Maximum Soldering Temp / Time
Moisture Sensitivity Level (MSL)
Termination Finish
1
15pF
10mS
100nS
260ºC / 10 Seconds
1
Au
Pin Connections
#1) E/D
#2) NC
#3) GND
#4) Out
#5) NC
3
#6) V
dd
Recommended Cirucit
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load
change, aging, shock, and vibration.
2
An internal pullup resistor from pin 1 to pin 6 allows active output if pin 1 is left open.
3
A complementary output version with output 2 on pin 5 is available.
Note: A 0.01µF bypass capacitor should be placed between
V
dd
(Pin 6) and GND
(Pin 3) to minimize power supply line noise.
- If you have specific jitter or phase noise requirements please contact Fox Technical
Support for availability.
- The above specifications, having been carefully prepared and checked, is believed
to be accurate at the time of publication; however, no responsibility is assumed by Fox
Electronics for inaccuracies.
Patent Numbers:
US 6,664,860, US 5,960,403, US 5,952,890; US 5,960,405; US 6,188,290;
Foreign Patents: R.S.A. 98/0866, R.O.C. 120851; Singapore 67081, 67082; EP 0958652
China ZL 98802217.6, Malaysia MY-118540-A, Philippines 1-1998-000245
US and Foreign Patents Pending
X
PRESS
O® Fox Electronics
• ENAblE / DISAblE FuNCTION
2
OUTPUT (Pin 4)
(Pin 1)
ACTIVE
OPEN
'1' Level V
ih
≥
70%
V
dd
ACTIVE
'0' Level V
il
≤
30%
V
dd
High Z
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
http://www.foxonline.com
© 2006 FOX ELECTRONICS | ISO9001:2000 Certified
EMEA
Tel/Fax: +44 .1767.312632 |
Asia
Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282 |
Taiwan
Tel: +886.2.22073427 Fax +886.2.22073486
|
Japan
Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
HCMOS 5x3.2mm 3.3V Oscillator
Model: FXO-HC53 SERIES
Page 2 of 2
RoHS Compliant / Pb Free
Rev. 9/6/2006 Preliminary
http://www.foxonline.com/need_a_sample.htm
Low Cost, Low Jitter, Fast Delivery
1-888-XpressO
• TAPE SPECIFICATIONS
(millimeters)
MODEl
FXO-HC53
• REEl SPECIFICATIONS
(millimeters)
G H
I
J
K
l M
2.0
∅13 ∅21 ∅80 ∅255
17.5 2.0
b C D E
F
STD Reel QTY
MODEl
A
FXO-HC53
2,000
∅1.5
4.0 8.0 7.5 16.0 2.15
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
http://www.foxonline.com
© 2006 FOX ELECTRONICS | ISO9001:2000 Certified
EMEA
Tel/Fax: +44 .1767.312632 |
Asia
Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282 |
Taiwan
Tel: +886.2.22073427 Fax +886.2.22073486
|
Japan
Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
