isc
Silicon PNP Power Transistor
2SA882
DESCRIPTION
·High
Power Dissipation-
: P
C
= 100W(Max.)@T
C
=25℃
·Collector-Emitter
Breakdown Voltage-
: V
(BR)CEO
= -130V(Min.)
·Minimum
Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·Designed
for power and switching applications.
ABSOLUTE MAXIMUM RATINGS(T
a
=25
℃)
SYMBOL
PARAMETER
VALUE
UNIT
V
CBO
Collector-Base Voltage
-130
V
V
CEO
Collector-Emitter Voltage
-130
V
V
EBO
Emitter-Base Voltage
-5
V
I
C
Collector Current-Continuous
Collector Power Dissipation
@T
C
=25℃
Junction Temperature
-7
A
P
C
100
W
T
j
150
℃
T
stg
Storage Temperature
-65~200
℃
isc website
：
www.iscsemi.com
1
isc & iscsemi
is registered trademark
isc
Silicon PNP Power Transistor
ELECTRICAL CHARACTERISTICS
Tj=25℃ unless otherwise specified
SYMBOL
V
(BR)CEO
PARAMETER
Collector-Emitter Breakdown Voltage
CONDITIONS
I
C
= -30mA; I
B
= 0
MIN
-130
TYP.
2SA882
MAX
UNIT
V
V
CE
(sat)-1
Collector-Emitter Saturation Voltage
I
C
= -3A; I
B
= -0.3A
-1.0
V
V
CE
(sat)-2
Collector-Emitter Saturation Voltage
I
C
= -7A; I
B
= -1.5A
-3.0
V
V
BE
(on)
I
CBO
Base-Emitter On Voltage
I
C
= -3A; V
CE
= -4V
-1.6
V
Collector Cutoff Current
V
CB
= -130V; I
E
= 0
-0.1
mA
I
EBO
Emitter Cutoff Current
V
EB
= -5V; I
C
= 0
-0.1
mA
h
FE-1
DC Current Gain
I
C
= -1A; V
CE
= -4V
40
h
FE-2
DC Current Gain
I
C
= -3A; V
CE
= -4V
20
Notice：
ISC reserves the rights to make changes of the content herein the datasheet at any time without
notification. The information contained herein is presented only as a guide for the applications of
our products.
ISC products are intended for usage in general electronic equipment. The products are not
designed for use in equipment which require specialized quality and/or reliability, or in equipment
which could have applications in hazardous environments, aerospace industry, or medical
field. Please contact us if you intend our products to be used in these special applications.
ISC makes no warranty or guarantee regarding the suitability of its products for any particular
purpose, nor does ISC assume any liability arising from the application or use of any products, and
specifically disclaims any and all liability, including without limitation special, consequential or
incidental damages.
isc website
：
www.iscsemi.com
2
isc & iscsemi
is registered trademark
