RoHS
Shielded Power Chip Inductor
Dimensions:
Inches
(mm)
PCSD054
0.307±0.014
(7.8±0.35)
0.118±0.016
0.276±0.014
(7.0±0.35)
(4.5±0.40)
XXX
7.5
UNIT: mm
Allied
Part
Number
Inductance
(µh)
Tolerance
(%)
Test
Freq.
KHz, 0.1V
RDC
(Ω)
Max.
Rated
Current
(A)
Features
• SMD Power Inductor
• Magnetically shielded
• Low DC resistance
• High Current
• Ideal for DC-DC converter applications
Electrical
PCSD054-100M-RC
PCSD054-120M-RC
PCSD054-150M-RC
PCSD054-180M-RC
PCSD054-220M-RC
PCSD054-270M-RC
PCSD054-330L-RC
PCSD054-390L-RC
PCSD054-470L-RC
PCSD054-560K-RC
PCSD054-680L-RC
PCSD054-820L-RC
PCSD054-101K-RC
PCSD054-121K-RC
PCSD054-151K-RC
PCSD054-181K-RC
PCSD054-221K-RC
PCSD054-271K-RC
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
20
20
20
20
20
20
15
15
15
10
15
15
10
10
10
10
10
10
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
0.07
0.07
0.08
0.10
0.13
0.16
0.18
0.18
0.27
0.29
0.33
0.43
0.49
0.68
0.94
1.00
1.18
1.30
1.65
1.57
1.39
1.29
1.12
1.06
0.97
0.91
0.80
0.76
0.68
Inductance Range:
10µh to 270µh,
Available in additional values
Tolerance:
As shown in the table.
Also, available in tighter tolerances
Operating Temp:
-40ºC ~ +100ºC
Rated Current:
Current at which inductance
drop by no more than 10% of intial value or the
temperature has risen by 40ºC which ever occurs first
Test Equipment
0.62
0.55
0.49
0.44
0.40
0.36
0.33
Physical
Packaging:
800 pieces per 13 inch reel.
Marking:
EIA Inductance Code
(L):
HP4284 A LCR Meter
(RDC): CH502BC or equal
Tolerance: also available in: K=10% and M=20%
All specifications subject to change wtihout notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
15
07/03/11
www.alliedcomponents.com
