TL072IP datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> TL072IP

TL072IP: DescriptionIC,OP-AMP,DUAL,BIPOLAR/JFET,DIP,8PIN,PLASTIC; CategoryAnalog mixed-signal IC Amplifier circuit; File Size471KB，8 Pages; ManufacturerSTMicroelectronics; Websitehttp://www.st.com/

Download Datasheet Parametric Compare View All

TL072IP Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	TL072IP	-	-	View	Buy Now

TL072IP Overview

IC,OP-AMP,DUAL,BIPOLAR/JFET,DIP,8PIN,PLASTIC

TL072IP Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	STMicroelectronics
Reach Compliance Code	unknown
Amplifier type	OPERATIONAL AMPLIFIER
Architecture	VOLTAGE-FEEDBACK
Maximum bias current (IIB) at 25C	0.0002 µA
frequency compensation	YES
Maximum input offset current (IIO)	0.01 µA
Maximum input offset voltage	9000 µV
JESD-30 code	R-PDIP-T8
low-bias	YES
low-dissonance	NO
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of functions	2
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-25 °C
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Encapsulate equivalent code	DIP8,.3
Package shape	RECTANGULAR
Package form	IN-LINE
power supply	+-15 V
Certification status	Not Qualified
Maximum slew rate	5 mA
Supply voltage upper limit	18 V
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Temperature level	OTHER
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Nominal Uniform Gain Bandwidth	3000 kHz
Minimum voltage gain	25000

Preview

Download Datasheet

View All

TL072IP Related Products

	TL072IP	TL072CJG	TL072IJG	TL072CP	TL072ACJG	TL072ACP	TL072BCP	TL072BCJG	TL072MJ
Description	IC,OP-AMP,DUAL,BIPOLAR/JFET,DIP,8PIN,PLASTIC	IC,OP-AMP,DUAL,BIPOLAR/JFET,DIP,8PIN,CERAMIC	IC,OP-AMP,DUAL,BIPOLAR/JFET,DIP,8PIN,CERAMIC	IC,OP-AMP,DUAL,BIPOLAR/JFET,DIP,8PIN,PLASTIC	IC,OP-AMP,DUAL,BIPOLAR/JFET,DIP,8PIN,CERAMIC	IC,OP-AMP,DUAL,BIPOLAR/JFET,DIP,8PIN,PLASTIC	IC,OP-AMP,DUAL,BIPOLAR/JFET,DIP,8PIN,PLASTIC	IC,OP-AMP,DUAL,BIPOLAR/JFET,DIP,8PIN,CERAMIC	IC,OP-AMP,DUAL,BIPOLAR/JFET,DIP,8PIN,CERAMIC
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible
Reach Compliance Code	unknown	not_compliant	not_compliant	not_compliant	not_compliant	unknown	unknown	unknown	not_compliant
Amplifier type	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER
Architecture	VOLTAGE-FEEDBACK	VOLTAGE-FEEDBACK	VOLTAGE-FEEDBACK	VOLTAGE-FEEDBACK	VOLTAGE-FEEDBACK	VOLTAGE-FEEDBACK	VOLTAGE-FEEDBACK	VOLTAGE-FEEDBACK	VOLTAGE-FEEDBACK
Maximum bias current (IIB) at 25C	0.0002 µA	0.0002 µA	0.0002 µA	0.0002 µA	0.0002 µA	0.0002 µA	0.0002 µA	0.0002 µA	0.0002 µA
frequency compensation	YES	YES	YES	YES	YES	YES	YES	YES	YES
Maximum input offset current (IIO)	0.01 µA	0.002 µA	0.01 µA	0.01 µA	0.002 µA	0.002 µA	0.002 µA	0.002 µA	0.004 µA
Maximum input offset voltage	9000 µV	13000 µV	9000 µV	13000 µV	7500 µV	7500 µV	5000 µV	5000 µV	8000 µV
JESD-30 code	R-PDIP-T8	R-XDIP-T8	R-XDIP-T8	R-PDIP-T8	R-XDIP-T8	R-PDIP-T8	R-PDIP-T8	R-XDIP-T8	R-XDIP-T8
low-bias	YES	YES	YES	YES	YES	YES	YES	YES	YES
low-dissonance	NO	NO	NO	NO	NO	NO	NO	NO	NO
Nominal Negative Supply Voltage (Vsup)	-15 V	-15 V	-15 V	-15 V	-15 V	-15 V	-15 V	-15 V	-15 V
Number of functions	2	2	2	2	2	2	2	2	2
Number of terminals	8	8	8	8	8	8	8	8	8
Maximum operating temperature	85 °C	70 °C	85 °C	70 °C	70 °C	70 °C	70 °C	70 °C	125 °C
Package body material	PLASTIC/EPOXY	CERAMIC	CERAMIC	PLASTIC/EPOXY	CERAMIC	PLASTIC/EPOXY	PLASTIC/EPOXY	CERAMIC	CERAMIC
encapsulated code	DIP	DIP	DIP	DIP	DIP	DIP	DIP	DIP	DIP
Encapsulate equivalent code	DIP8,.3	DIP8,.3	DIP8,.3	DIP8,.3	DIP8,.3	DIP8,.3	DIP8,.3	DIP8,.3	DIP8,.3
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE
power supply	+-15 V	+-15 V	+-15 V	+-15 V	+-15 V	+-15 V	+-15 V	+-15 V	+-15 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum slew rate	5 mA	5 mA	5 mA	5 mA	5 mA	5 mA	5 mA	5 mA	5 mA
Supply voltage upper limit	18 V	18 V	18 V	18 V	18 V	18 V	18 V	18 V	18 V
Nominal supply voltage (Vsup)	15 V	15 V	15 V	15 V	15 V	15 V	15 V	15 V	15 V
surface mount	NO	NO	NO	NO	NO	NO	NO	NO	NO
Temperature level	OTHER	COMMERCIAL	OTHER	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	MILITARY
Terminal form	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE
Terminal pitch	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
Nominal Uniform Gain Bandwidth	3000 kHz	3000 kHz	3000 kHz	3000 kHz	3000 kHz	3000 kHz	3000 kHz	3000 kHz	4000 kHz
Minimum voltage gain	25000	15000	25000	15000	25000	25000	25000	25000	25000
Maker	STMicroelectronics	-	-	-	STMicroelectronics	STMicroelectronics	STMicroelectronics	STMicroelectronics	STMicroelectronics
