TSC428C/D: DescriptionBuffer/Inverter Based MOSFET Driver, 1.5A, CMOS, DIE-6; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size170KB，4 Pages; ManufacturerMaxim; Websitehttps://www.maximintegrated.com/en.html

Download Datasheet Parametric Compare View All

TSC428C/D Overview

Buffer/Inverter Based MOSFET Driver, 1.5A, CMOS, DIE-6

TSC428C/D Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Maxim
Parts packaging code	DIE
package instruction	DIE-6
Contacts	6
Reach Compliance Code	not_compliant
ECCN code	EAR99
high side driver	NO
Interface integrated circuit type	BUFFER OR INVERTER BASED MOSFET DRIVER
JESD-30 code	S-XUUC-N6
Number of functions	2
Number of terminals	6
Maximum operating temperature	70 °C
Minimum operating temperature
Nominal output peak current	1.5 A
Package body material	UNSPECIFIED
encapsulated code	DIE
Encapsulate equivalent code	DIE OR CHIP
Package shape	SQUARE
Package form	UNCASED CHIP
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	4.5/18 V
Certification status	Not Qualified
Maximum supply voltage	18 V
Minimum supply voltage	4.5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal form	NO LEAD
Terminal location	UPPER
Maximum time at peak reflow temperature	NOT SPECIFIED
Disconnect time	0.06 µs
connection time	0.12 µs

Preview

Download Datasheet

View All

TSC428C/D Related Products

	TSC428C/D	TSC427CBA-T	TSC426EJA	TSC426EPA	TSC427C/D	TSC427EBA-T	TSC427EJA	TSC427EPA
Description	Buffer/Inverter Based MOSFET Driver, 1.5A, CMOS, DIE-6	Buffer/Inverter Based MOSFET Driver, 1.5A, CMOS, PDSO8, 0.150 INCH, MS-012AA, SOIC-8	Buffer/Inverter Based MOSFET Driver, 1.5A, CMOS, CDIP8, 0.300 INCH, CERAMIC, DIP-8	Buffer/Inverter Based MOSFET Driver, 1.5A, CMOS, PDIP8, 0.300 INCH, PLASTIC, DIP-8	Buffer/Inverter Based MOSFET Driver, 1.5A, CMOS, DIE-6	Buffer/Inverter Based MOSFET Driver, 1.5A, CMOS, PDSO8, 0.150 INCH, MS-012AA, SOIC-8	Buffer/Inverter Based MOSFET Driver, 1.5A, CMOS, CDIP8, 0.300 INCH, CERAMIC, DIP-8	Buffer/Inverter Based MOSFET Driver, 1.5A, CMOS, PDIP8, 0.300 INCH, PLASTIC, DIP-8
Is it lead-free?	Contains lead	Contains lead	Contains lead	Contains lead	Contains lead	Contains lead	Contains lead	Contains lead
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible
Parts packaging code	DIE	SOIC	DIP	DIP	DIE	SOIC	DIP	DIP
package instruction	DIE-6	SOP, SOP8,.25	DIP, DIP8,.3	DIP, DIP8,.3	DIE-6	SOP, SOP8,.25	0.300 INCH, CERAMIC, DIP-8	0.300 INCH, PLASTIC, DIP-8
Contacts	6	8	8	8	6	8	8	8
Reach Compliance Code	not_compliant	not_compliant	not_compliant	not_compliant	not_compliant	not_compliant	not_compliant	not_compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
high side driver	NO	NO	NO	NO	NO	NO	NO	NO
Interface integrated circuit type	BUFFER OR INVERTER BASED MOSFET DRIVER	BUFFER OR INVERTER BASED MOSFET DRIVER	BUFFER OR INVERTER BASED MOSFET DRIVER	BUFFER OR INVERTER BASED MOSFET DRIVER	BUFFER OR INVERTER BASED MOSFET DRIVER	BUFFER OR INVERTER BASED MOSFET DRIVER	BUFFER OR INVERTER BASED MOSFET DRIVER	BUFFER OR INVERTER BASED MOSFET DRIVER
JESD-30 code	S-XUUC-N6	R-PDSO-G8	R-CDIP-T8	R-PDIP-T8	S-XUUC-N6	R-PDSO-G8	R-CDIP-T8	R-PDIP-T8
Number of functions	2	2	2	2	2	2	2	2
Number of terminals	6	8	8	8	6	8	8	8
Maximum operating temperature	70 °C	70 °C	85 °C	85 °C	70 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-	-	-40 °C	-40 °C	-	-40 °C	-40 °C	-40 °C
Nominal output peak current	1.5 A	1.5 A	1.5 A	1.5 A	1.5 A	1.5 A	1.5 A	1.5 A
Package body material	UNSPECIFIED	PLASTIC/EPOXY	CERAMIC, METAL-SEALED COFIRED	PLASTIC/EPOXY	UNSPECIFIED	PLASTIC/EPOXY	CERAMIC, METAL-SEALED COFIRED	PLASTIC/EPOXY
encapsulated code	DIE	SOP	DIP	DIP	DIE	SOP	DIP	DIP
Encapsulate equivalent code	DIE OR CHIP	SOP8,.25	DIP8,.3	DIP8,.3	DIE OR CHIP	SOP8,.25	DIP8,.3	DIP8,.3
Package shape	SQUARE	RECTANGULAR	RECTANGULAR	RECTANGULAR	SQUARE	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	UNCASED CHIP	SMALL OUTLINE	IN-LINE	IN-LINE	UNCASED CHIP	SMALL OUTLINE	IN-LINE	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	245	245	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
power supply	4.5/18 V	4.5/18 V	4.5/18 V	4.5/18 V	4.5/18 V	4.5/18 V	4.5/18 V	4.5/18 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum supply voltage	18 V	18 V	18 V	18 V	18 V	18 V	18 V	18 V
Minimum supply voltage	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V
surface mount	YES	YES	NO	NO	YES	YES	NO	NO
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	COMMERCIAL	COMMERCIAL	INDUSTRIAL	INDUSTRIAL	COMMERCIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal form	NO LEAD	GULL WING	THROUGH-HOLE	THROUGH-HOLE	NO LEAD	GULL WING	THROUGH-HOLE	THROUGH-HOLE
Terminal location	UPPER	DUAL	DUAL	DUAL	UPPER	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Disconnect time	0.06 µs	0.06 µs	0.06 µs	0.06 µs	0.06 µs	0.06 µs	0.06 µs	0.06 µs
connection time	0.12 µs	0.12 µs	0.12 µs	0.12 µs	0.12 µs	0.12 µs	0.12 µs	0.12 µs
Maker	Maxim	-	Maxim	Maxim	Maxim	Maxim	Maxim	Maxim
JESD-609 code	-	e0	e0	e0	-	e0	e0	e0
Maximum seat height	-	1.75 mm	5.08 mm	4.572 mm	-	1.75 mm	5.08 mm	4.572 mm
Terminal surface	-	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	-	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal pitch	-	1.27 mm	2.54 mm	2.54 mm	-	1.27 mm	2.54 mm	2.54 mm
width	-	3.9 mm	7.62 mm	7.62 mm	-	3.9 mm	7.62 mm	7.62 mm
