Continental Device India Limited
An ISO/TS 16949, ISO 9001 and ISO 14001 Certified Company
PLASTIC POWER TRANSISTORS
BD 905, 907, 909, 911
NPN
BD906,
908, 910, 912
PNP
TO-220
Plastic Package
Power Linear and Switching Applications
ABSOLUTE MAXIMUM RATINGS (Ta=25ºC unless specified otherwise )
DESCRIPTION
SYMBOL
Collector -Emitter Voltage
Collector -Base Voltage
Emitter -Base Voltage
Emitter and Collector Current
Base Current
Total Power Dissipation up to Tc=25
o
C
Junction Temperature
Temperature Range
V
CEO
V
CBO
V
EBO
I
E
, I
C
I
B
P
tot
T
j
T
stg
905
906
45
45
907
908
60
60
909
911
910
912
80
100
80
100
5.0
15
5.0
90
150
-65 to +150
UNIT
V
V
V
A
A
W
ºC
ºC
ELECTRICAL CHARACTERISTICS (Tc=25ºC Unless Otherwise Specified)
DESCRIPTION
SYMBOL
Breakdown (sus) Voltage
Collector-Cut off Current
V
CEO(sus)
* I
C
=50mA, I
B
=0
I
CEO
V
CE
=30V, I
B
=0
V
CE
=40V, I
B
=0
V
CE
=50V, I
B
=0
I
E
=0,V
CB
=Rated
V
CBO
,
I
E
=0,V
CB
=Rated
V
CBO
,
T
c
=150°C
V
EB
=5V, I
C
=O
I
C
=5A, I
B
=0.5A
I
C
=10A, I
B
=2.5A
I
C
=10A, I
B
=2.5A
905
906
45
1.0
907
908
60
1.0
909
910
80
911
912
100
UNIT
V
mA
mA
mA
mA
mA
1.0
1.0
0.5
5
I
CBO
Emitter-Cut off Current
Saturation Voltages
I
EBO
V
CE(Sat)
*
V
BE(sat)
*
1.0
1.0
3.0
2.5
mA
V
V
V
Continental Device India Limited
Data Sheet
Page 1 of 4
Notes
BD 905, 907, 909, 911
BD906, 908, 910, 912
TO-220
Plastic Package
Component Disposal Instructions
1. CDIL Semiconductor Devices are RoHS compliant, customers are requested to please
dispose as per prevailing Environmental Legislation of their Country.
2.
In Europe, please dispose as per EU Directive 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE).
Disclaimer
The product information and the selection guides facilitate selection of the CDIL's Discrete Semiconductor Device(s) best suited
for application in your product(s) as per your requirement. It is recommended that you completely review our Data Sheet(s) so as
to confirm that the Device(s) meet functionality parameters for your application. The information furnished in the Data Sheet and
on the CDIL Web Site/CD is believed to be accurate and reliable. CDIL however, does not assume responsibility for inaccuracies
or incomplete information. Furthermore, CDIL does not assume liability whatsoever, arising out of the application or use of any
CDIL product; neither does it convey any license under its patent rights nor rights of others. These products are not designed for
use in life saving/support appliances or systems. CDIL customers selling these products (either as individual Discrete
Semiconductor Devices or incorporated in their end products), in any life saving/support appliances or systems or applications do
so at their own risk and CDIL will not be responsible for any damages resulting from such sale(s).
CDIL strives for continuous improvement and reserves the right to change the specifications of its products without prior notice.
CDIL is a registered Trademark of
Continental Device India Limited
C-120 Naraina Industrial Area, New Delhi 110 028, India.
Telephone + 91-11-2579 6150,
4141112
Fax + 91-11-2579 5290,
4141 1119
email cdil.com
@
www.cdilsemi.com
BD905_912 Rev170701
Continental Device India Limited
Data Sheet
Page 4 of 4
