B07B333BC1 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Mechanical and electronic products> relay> B07B333BC1

B07B333BC1: DescriptionPOWER/SIGNAL RELAY, DPDT, MOMENTARY, 0.088A (COIL), 26.5VDC (COIL), 2341mW (COIL), 10A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT; CategoryMechanical and electronic products relay; File Size99KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

B07B333BC1 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	B07B333BC1	-	-	View	Buy Now

B07B333BC1 Overview

POWER/SIGNAL RELAY, DPDT, MOMENTARY, 0.088A (COIL), 26.5VDC (COIL), 2341mW (COIL), 10A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT

B07B333BC1 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	TE Connectivity
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	25 weeks
body width	13.46 mm
body height	25.65 mm
Body length or diameter	26.03 mm
Maximum coil current (DC)	0.088 A
Coil operating voltage (DC)	13 V
Coil power	2341 mW
Coil release voltage (DC)	1.8 V
Coil resistance	300 Ω
Maximum coil voltage (DC)	26.5 V
Nominal coil voltage	26.5 V
Coil/Input Power Type	DC
Maximum contact current (AC)	10 A
Maximum contact current (DC)	10 A
Contact (DC) maximum rated R load	10A@28VDC
Maximum contact voltage (DC)	28 V
Electrical life	100000 Cycle(s)
End contact material	Silver Cadmium Oxide
Input switching control type	Random
Installation features	THROUGH HOLE-STRAIGHT MOUNT
Number of terminals	8
operating hours	10 ms
Maximum operating temperature	125 °C
Minimum operating temperature	-65 °C
PCB hole count	8
physical size	26.03mm x 13.46mm x 25.65mm
Relay action	MOMENTARY
Relay style	2 FORM C
Relay function	DPDT
Relay type	POWER/SIGNAL RELAY
release time	10 ms
seal	HERMETICALLY SEALED
surface mount	NO
Terminal length	0.0076 inch
Termination type	SOLDER

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se a rch by Ke yword or Pa rt #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Relays

Product Feature Selector

> Product Details

B07B333BC1 Product Details

Military/Aerospace High Performance Relays

Not EU R oHS or ELV C om plia nt

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

B07B333BC1

(2-1617560-7)

T E I nternal N umber: 2 - 1 6 1 7 5 6 0 - 7

Product Highlights:

07 Full Size Relay Series

Input Voltage = 26.5 VDC

C ontact Arrangement = 2 Form C , DPDT, 2 C /O

C ontact C urrent Rating = 10 Amps.

Non Polarized, Monostable C oil Magnetic System

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

RELAY

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Termination Type = PC Pins

Electrical Characteristics:

Input Voltage (VDC ) = 26.5

C ontact C urrent Rating (Amps.) = 10

C oil Polarity Protection Diode = Without

Transistor Driver = Without

C oil Resistance (?) = 300

MOSFET Driver = Without

C oil Power Measurement = Milliwatts

C oil Power, Nominal (mW) = 2341

Actuating System = DC

Shock = 50G's, 11ms

Vibration = 20G's, 10 to 2000Hz

Body Related Features:

Series

= 07 Full Size Relay

Contact Related Features:

Mounting Options = Panel Mount

Enclosure = Hermetically Sealed

Configuration Related Features:

C ontact Arrangement

= 2 Form C , DPDT, 2 C /O

C oil Magnetic System = Non Polarized, Monostable

C oil Suppression Diode = Without

Industry Standards:

Government/Industry Qualification = No

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Not suitable for lead free processing

Conditions for Usage:

Temperature Range (?C ) = -65 – +125

Other:

Brand = C II

Additional Information:

Product Line Information

B07B333BC1 Related Products

	B07B333BC1	ATS-14F-19-C2-R0
Description	POWER/SIGNAL RELAY, DPDT, MOMENTARY, 0.088A (COIL), 26.5VDC (COIL), 2341mW (COIL), 10A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT	pushPIN™ HS ASMBLY,FINE-PITCH,XCUT, HOLE PATTERN:4-CORNER,BLUE,T766

Recommended Resources
