HVRS42T122171% datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> HVRS42T122171%

HVRS42T122171%: DescriptionRESISTOR, 2W, 1%, 100ppm, 2210000000ohm, THROUGH HOLE MOUNT, RADIAL LEADED; CategoryPassive components The resistor; File Size218KB，2 Pages; ManufacturerSEI(Stackpole Electronics Inc.); Websitehttps://www.seielect.com/

Download Datasheet Parametric View All

HVRS42T122171% Overview

RESISTOR, 2W, 1%, 100ppm, 2210000000ohm, THROUGH HOLE MOUNT, RADIAL LEADED

HVRS42T122171% Parametric

Parameter Name	Attribute value
Maker	SEI(Stackpole Electronics Inc.)
package instruction	RADIAL LEADED
Reach Compliance Code	unknown
ECCN code	EAR99
JESD-609 code	e3
Manufacturer's serial number	HVR
Installation features	THROUGH HOLE MOUNT
Number of terminals	2
Package shape	RECTANGULAR PACKAGE
Rated power dissipation(P)	2 W
Rated temperature	25 °C
resistance	2210000000 Ω
Resistor type	FIXED RESISTOR
surface mount	NO
Temperature Coefficient	100 ppm/°C
Terminal surface	MATTE TIN
Terminal shape	WIRE
Tolerance	1%
Operating Voltage	20000 V

Preview

Download Datasheet

View All

HVR Series — High Voltage Leaded Resistors

Features

• Ohmic values to 2,000G

• Voltage ratings to 40,000 volts

• Ultra high stability

• Tight tolerances to 0.1%

• Low TCR to 10ppm/°C

• Low VCR to 0.05ppm/volt

• Very low noise

• Custom solutions available

Electrical Specifications

HVR

Case

Size

Power

watts @

25°C

Maximum

Voltage

Rating (kv)

Resistance

Temperature

Coefficient

±25ppm/°C

±50ppm/°C

±100ppm/°C

±25ppm/°C

±50ppm/°C

±100ppm/°C

±25ppm/°C

±50ppm/°C

±100ppm/°C

±25ppm/°C

±50ppm/°C

±100ppm/°C

±25ppm/°C

±50ppm/°C

±100ppm/°C

±25ppm/°C

±50ppm/°C

±100ppm/°C

Ohmic Range and Tolerance

0.1%

<30M – 100M

–

<30M – 100M

–

<30M – 100M

–

<30M – 100M

–

<30M – 100M

–

<30M – 100M

–

0.25% & 0.5%

<30M – 100M

>100M – 2G

–

<30M – 100M

>100M – 2G

–

<30M – 100M

>100M – 2G

–

<30M – 100M

>100M – 2G

–

<30M – 100M

>100M – 2G

–

<30M – 100M

>100M – 2G

–

<30M – 100M

>100M – 2G

>2G – 20G

<30M – 100M

>100M – 2G

>2G – 20G

<30M – 100M

>100M – 2G

>2G – 20G

<30M – 100M

>100M – 2G

>2G – 20G

<30M – 100M

>100M – 2G

>2G – 20G

<30M – 100M

>100M – 2G

>2G – 20G

<30M – 100M

>100M – 2G

>2G – 50G

<30M – 100M

>100M – 2G

>2G – 50G

<30M – 100M

>100M – 2G

>2G – 50G

<30M – 100M

>100M – 2G

>2G – 50G

<30M – 100M

>100M – 2G

>2G – 50G

<30M – 100M

>100M – 2G

>2G – 50G

5%, 10% & 20%

<30M – 100M

>100M – 2G

>2G – 100G

<30M – 100M

>100M – 2G

>2G – 100G

<30M – 100M

>100M – 2G

>2G – 100G

<30M – 100M

>100M – 2G

>2G – 100G

<30M – 100M

>100M – 2G

>2G – 100G

<30M – 100M

>100M – 2G

>2G – 100G

0.5

How to Order

HVR

SEI Type

Lead Style

Case Size

TCR Rating

5005

Total R Value

Tolerance

Lead Style

Spade

Wire

Case Size

TCR Rating

±25ppm/°C

±50ppm/°C

±100ppm/°C

±200ppm/°C

Ratio Tolerance

±0.1%

±0.25%

±0.5%

±1%

±2%

±5%

±10%

±20%

Note 1: TCR is measured from 25°C to 75°C

Note 2: Express value as a four digit number; the first three numbers are the significant value and the fourth

number is the number of zeros

Note 3: Tolerance is dependent on case size and value

Toll Free: (888) SEI-SEIS

(888) 734-7347

www.seielect.com
