Surface Mount Aluminum Electrolytic Capacitors
FEATURES
• CYLINDRICAL V-CHIP CONSTRUCTION
• VERY LOW IMPEDANCE AT 100KHz
• WIDE TEMPERATURE RANGE (-55 +105
O
C)
• MAXIMUM 5.5mm HEIGHT
• ANTI-SOLVENT (2 MINUTES)
• DESIGNED FOR REFLOW SOLDERING
• MEETS THE REQUIREMENTS OF AEC-Q200*
*Contact NIC for supporting test data
CHARACTERISTICS
Rated Voltage Range
Rated Capacitance Range
Operating Temperature Range
Capacitance Tolerance
Max. Leakage Current After 2 Minutes at 20°C
W.V. (Vdc)
Surge Voltage and Max. Tan
δ
S.V.(Vdc)
Tan
δ
Z-25°C/Z+20°C
Low Temperature Stability
(Impedance Ratio @ 120Hz)
Z-55°C/Z+20°C
Capacitance Change
High Temperature Load Life at
Tan
δ
105°C and Rated Working Voltage
1,000 hours
Leakage Current
6.3 ~ 63V
1.0 ~ 150μF
-55 ~ +105°C
±20% (M), ±10% (K)*
0.01CV or 3μA whichever is greater
6.3
10
16
25
35
50
63
8
13
20
32
44
63
79
0.24 0.20 0.16 0.14 0.12 0.12 0.12
3
2
2
2
2
2
2
5
4
4
3
3
3
3
Within ±25% of initial measured value
Less than 200% of specified value
Less than the specified value
NACX Series
includes all homogeneous materials
RoHS
Compliant
P N b S
f D il
*See Part Number System for Details
* Optional ± 10% (K) Tolerance available on most values. Contact factory for availability.
STANDARD PRODUCT AND SIZE DφxL (mm)
Cap.
(μF)
1.0
2.2
3.3
4.7
10
22
33
47
100
220
Code
1R0
2R2
3R3
4R7
100
220
330
470
101
221
Working Voltage (Vdc)
6.3
10
16
25
35
50
63
-
-
-
-
4x5.5
4x5.5
4x5.5
-
-
-
-
4x5.5
4x5.5
4x5.5
5x5.5
-
-
-
-
4x5.5
4x5.5
5x5.5
-
-
-
4x5.5
4x5.5
5x5.5
-
-
4x5.5
5x5.5
5x5.5 6.3x5.5 6.3x5.5
4x5.5
5x5.5
5x5.5 6.3x5.5 6.3x5.5
-
-
5x5.5
5x5.5 6.3x5.5 6.3x5.5
-
-
-
5x5.5 6.3x5.5 6.3x5.5 6.3x5.5
-
-
-
6.3x5.5 6.3x5.5 6.3x5.5
-
-
-
-
6.3x5.5
-
-
-
-
-
-
Dφ
0.3mm max.
L
+
W
I
I
-
DIMENSIONS (mm)
Case Size Dφ±0.5 L max. A/B±0.2 I ± 0.2
W
4x5.5
4.0
5.5
4.3
1.8 0.5 ~ 0.8
5x5.5
5.0
5.5
5.3
2.1 0.5 ~ 0.8
6.3x5.5
6.3
5.5
6.6
2.5 0.5 ~ 0.8
P±0.2
1.0
1.4
2.2
P
B
A
PART NUMBER SYSTEM
NACX 100 M 25V 5x5.5 TR 13 Y F
RoHS Compliant
97% Sn (min.), 3% Bi (max.)
Series
330mm (13”) Reel
Tape & Reel
Size in mm
Working Voltage
Tolerance Code M=20%
Capacitance Code in
μF,
fi
rst 2 digits are significant
Third digit is no. of zeros, “R” indicates decimal for
values under 10μF
Optional: Suitable for automotive equipment, sourced to special
production and inspection at TS-16949 certified production site
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
SPECIFICATIONS ARE SUBJECT TO CHANGE
1
Surface Mount Aluminum Electrolytic Capacitors
STANDARD VALUES, CASE SIZES AND SPECIFICATIONS
Cap. W.V.
(μF) (Vdc)
NACX220M6.3V4x5.5TR13F
22
NACX330M6.3V5x5.5TR13F
33
NACX470M6.3V5x5.5TR13F
47
6.3
NACX101M6.3V6.3x5.5TR13F
100
NACX221M6.3V6.3x5.5TR13F
220
NACX220M10V5x5.5TR13F
22
NACX330M10V5x5.5TR13F
33
10
NACX470M10V6.3x5.5TR13F
47
NACX101M10V6.3x5.5TR13F
100
NACX100M16V4x5.5TR13F
10
NACX220M16V5x5.5TR13F
22
NACX330M16V6.3x5.5TR13F
33
16
NACX470M16V6.3x5.5TR13F
47
NACX101M16V6.3x5.5TR13F
100
NACX4R7M25V4x5.5TR13F
4.7
NACX100M25V5x5.5TR13F
10
NACX220M25V6.3x5.5TR13F
22
25
NACX330M25V6.3x5.5TR13F
33
NACX470M25V6.3x5.5TR13F
47
NACX1R0M35V4x5.5TR13F
1.0
NACX2R2M35V4x5.5TR13F
2.2
NACX3R3M35V4x5.5TR13F
3.3
35
NACX4R7M35V4x5.5TR13F
4.7
NACX100M35V5x5.5TR13F
10
NACX220M35V6.3x5.5TR13F
22
NACX1R0M50V4x5.5TR13F
1.0
NACX2R2M50V4x5.5TR13F
2.2
NACX3R3M50V4x5.5TR13F
3.3
50
NACX4R7M50V5x5.5TR13F
4.7
NACX100M50V6.3x5.5TR13F
10
NACX1R0M63V4x5.5TR13F
1.0
NACX2R2M63V4x5.5TR13F
2.2
NACX3R3M63V5x5.5TR13F
3.3
63
NACX4R7M63V5x5.5TR13F
4.7
NACX100M63V6.3x5.5TR13F
10
For Automotive Equipment, see part number system
NIC Part Number
Case Size
4
φ
5
φ
6.3
φ
a
1.0
1.4
2.1
b
2.6
3.0
3.5
c
1.8
1.8
1.8
b
c
Dissipaton Factor
(Tan
δ)
0.24
0.24
0.24
0.24
0.24
0.20
0.20
0.20
0.20
0.16
0.16
0.16
0.16
0.16
0.14
0.14
0.14
0.14
0.14
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
Max. Ripple Current (mA)
+105°C/100kHz
68
105
105
155
155
105
105
155
155
68
105
155
155
155
68
105
155
155
155
68
68
68
68
105
155
37
45
52
75
120
20
24
40
40
65
Max. Z (Ω)
+20°C/100kHz
2.3
1.1
1.1
0.6
0.6
1.1
1.1
0.6
0.6
2.3
1.1
0.6
0.6
0.6
2.3
1.1
0.6
0.6
0.6
3.1
2.9
2.7
2.3
1.1
0.6
7.4
6.6
5.4
2.9
1.3
8.0
8.0
3.5
3.5
1.6
NACX Series
Load Life Hours
@ +105°C
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
RECOMMENDED LAND PATTERN DIMENSIONS (mm)
a
Please review the notes on correct use, safety and precautions found on
pages T10
&
T11
of NIC’s
Electrolytic Capacitor catalog.
Also found at
www.niccomp.com/precautions
If in doubt or uncertainty, please review your specific application - process
details with NIC’s technical support personnel:
tpmg@niccomp.com
PRECAUTIONS
Review & Compare Reflow Soldering Heat Limits
V-chip SMT Aluminum Electrolytic Capacitors
www.niccomp.com/RSL
2
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
SPECIFICATIONS ARE SUBJECT TO CHANGE
