CS218I-30BLEADFREE

Description
Silicon Controlled Rectifier, 30A I(T)RMS, 200V V(DRM), 200V V(RRM), 1 Element, TO-218
CategoryAnalog mixed-signal IC    Trigger device
File Size437KB,2 Pages
ManufacturerCentral Semiconductor
Environmental Compliance
Download Datasheet Parametric Compare View All

CS218I-30BLEADFREE Overview

Silicon Controlled Rectifier, 30A I(T)RMS, 200V V(DRM), 200V V(RRM), 1 Element, TO-218

CS218I-30BLEADFREE Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerCentral Semiconductor
package instructionFLANGE MOUNT, R-PSFM-T3
Reach Compliance Codecompliant
ECCN codeEAR99
Shell connectionISOLATED
ConfigurationSINGLE
Maximum DC gate trigger current50 mA
JEDEC-95 codeTO-218
JESD-30 codeR-PSFM-T3
JESD-609 codee3
Number of components1
Number of terminals3
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)260
Certification statusNot Qualified
Maximum rms on-state current30 A
Off-state repetitive peak voltage200 V
Repeated peak reverse voltage200 V
surface mountNO
Terminal surfaceMATTE TIN (315)
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperature10
Trigger device typeSCR
CS218I-30B CS218I-30N
CS218I-30D CS218I-30P
CS218I-30M CS218I-30PB
ISOLATED TAB
SILICON CONTROLLED RECTIFIERS
30 AMP, 200 THRU 1200 VOLT
w w w. c e n t r a l s e m i . c o m
DESCRIPTION:
The CENTRAL SEMICONDUCTOR CS218I-30B series
types are epoxy molded SCRs designed for sensing
circuit and control system applications. This device is
mounted in a TO-218 case with an isolated mounting
tab.
MARKING: FULL PART NUMBER
TO-218 THYRISTOR CASE
MAXIMUM RATINGS:
(TC=25°C unless otherwise noted)
SYMBOL
-30B -30D
Peak Repetitive Off-State Voltage
VDRM, VRRM 200 400
RMS On-State Current (TC=85°C)
IT(RMS)
Peak One Cycle Surge Current, t=10ms
I
2
t Value for Fusing, t=10ms
Peak Gate Power Dissipation, tp=10μs
Average Gate Power Dissipation
Peak Forward Gate Current, tp=10μs
Peak Forward Gate Voltage, tp=10μs
Peak Reverse Gate Voltage
Critical Rate of Rise of On-State Current
Operating Junction Temperature
Storage Temperature
Thermal Resistance
Thermal Resistance
Isolation Voltage
ELECTRICAL
SYMBOL
IDRM, IRRM
IDRM, IRRM
IGT
IH
VGT
VTM
dv/dt
dv/dt
ITSM
I
2
t
PGM
PG(AV)
IFGM
VFGM
VRGM
di/dt
TJ
Tstg
Θ
JA
Θ
JC
VISO
CS218I
-30M -30N -30P -30PB UNITS
600
800 1000 1200
V
30
400
800
50
1.0
4.0
16
5.0
100
-40 to +125
-40 to +150
50
1.1
2500
A
A
A
2
s
W
W
A
V
V
A/μs
°C
°C
°C/W
°C/W
V(RMS)
MAX
20
6.0
50
75
1.5
2.1
500
250
UNITS
μA
mA
mA
mA
V
V
V/μs
V/μs
CHARACTERISTICS:
(TC=25°C unless otherwise noted)
TEST CONDITIONS
MIN
Rated VDRM, VRRM
Rated VDRM, VRRM, TC=125°C
VD=12V, RL=33Ω
IT=500mA
VD=12V, RL=33Ω
ITM=60A, tp=380ms
VD=⅔Rated VDRM,
RGK=
∞,
TC=125°C (200V thru 800V)
VD=⅔Rated VDRM,
RGK=
∞,
TC=125°C (1000V, 1200V)
R2 (4-November 2013)
