1N3909 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> 1N3909

1N3909: Description30 A, 50 V, SILICON, RECTIFIER DIODE, DO-5; CategoryDiscrete semiconductor diode; File Size92KB，2 Pages; ManufacturerDigitron; Websitehttp://www.digitroncorp.com

Download Datasheet Parametric Compare View All

1N3909 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1N3909	-	-	View	Buy Now

1N3909 Overview

30 A, 50 V, SILICON, RECTIFIER DIODE, DO-5

1N3909 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Digitron
package instruction	O-MUPM-D1
Reach Compliance Code	unknow
application	FAST RECOVERY
Shell connection	CATHODE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.4 V
JEDEC-95 code	DO-5
JESD-30 code	O-MUPM-D1
JESD-609 code	e0
Maximum non-repetitive peak forward current	300 A
Number of components	1
Phase	1
Number of terminals	1
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Maximum output current	50 A
Package body material	METAL
Package shape	ROUND
Package form	POST/STUD MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum repetitive peak reverse voltage	50 V
Maximum reverse current	15 µA
Maximum reverse recovery time	0.2 µs
surface mount	NO
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	SOLDER LUG
Terminal location	UPPER
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

DIGITRON SEMICONDUCTORS

1N3909-1N3913

MAXIMUM RATINGS

Parameter

Working peak reverse voltage

Operating temperature range

Storage temperature range

Maximum thermal resistance

Mounting torque

Weight

Add “R” to part numbers for reverse polarity.

FAST RECOVERY RECTIFIER

Symbol

stg

θJC

1N3909

50V

1N3910

100V

1N3911

200V

-65 to +150°C

-65 to +175°C

0.8°C/W junction to case

25-30 inch pounds

.54 ounces (15.3 grams) typical

1N3912

300V

1N3913

400V

ELECTRICAL CHARACTERISTICS

Parameter

Average forward current

Maximum surge current

Maximum peak forward voltage

Maximum peak reverse current

Maximum reverse recovery time

Typical junction capacitance

•

Pulse test: pulse width 300µsec. Duty cycle 2%

Symbol

F(AV)

FSM

Value

30 Amps

300 Amps

1.40 Volts

15 µA

6.0 mA

200ns

130pF

Test Conditions

= 100°C, square wave, R

θJC

= 0.8°C/W

8.3ms, half-sine, T

= 100°C

= 50A: T

= 25°C*

RRM

, T

= 25°C

RRM

, T

= 150°C

= 1A dc, V

= 30V, di/dt = 25A/µs

= 10V, f = 1Mhz, T

= 25°C

MECHANICAL CHARACTERISTICS

Case

Marking

Normal polarity

Reverse polarity

DO-5(R)

Alpha-numeric

Cathode is stud

Anode is stud (add “R” suffix)

DO-5(R)

Inches

Millimeters

Min

Max

Min

Max

¼-28 UNF2A threads

0.669 0.688 16.990 17.480

0.794

20.160

1.000

25.400

0.422 0.453 10.720 11.510

0115 0.200 2.920

5.080

0.450

11.430

0.220 0.249 5.580

6.320

0.250 0.375 6.350

9.530

0.156

3.960

0.667

16.940

0.030 0.080 0.760

2.030

0.140 0.175 3.560

4.450

Available Non-RoHS (standard) or RoHS compliant (add PBF suffix).

Available as “HR” (high reliability) screened per MIL-PRF-19500, JANTX level. Add “HR” suffix to base part number.

144 Market Street

Kenilworth NJ 07033 USA

phone +1.908.245-7200

fax +1.908.245-0555

sales@digitroncorp.com

www.digitroncorp.com

Rev. 20121119
