SMD Multi-layer Chip Beads
SPECIFICATIONS
See page 70 for physical dimensions.
Parts are available in ±25% tolerance only.
Part
Number
CTCB0402-060H
CTCB0402-100H
CTCB0402-400H
CTCB0402-800H
CTCB0402-121H
CTCB0603-060H
CTCB0603-100H
CTCB0603-400H
CTCB0603-600H
CTCB0603-800H
CTCB0603-121H
CTCB0603-241H
CTCB0603-301H
CTCB0603-481H
CTCB0603-601H
CTCB0603-102H
CTCB0805-060H
CTCB0805-110H
CTCB0805-260H
CTCB0805-320H
CTCB0805-600H
CTCB0805-750H
CTCB0805-900H
CTCB0805-121H
CTCB0805-151H
CTCB0805-171H
CTCB0805-221H
CTCB0805-301H
CTCB0805-401H
CTCB0805-501H
CTCB0805-601H
CTCB0805-102H
CTCB0805-122H
CTCB0805-152H
CTCB0805-222H
CTCB1206-320H
CTCB1206-600H
CTCB1206-800H
CTCB1206-900H
CTCB1206-121H
CTCB1206-151H
CTCB1206-201H
CTCB1206-221H
CTCB1206-351H
CTCB1206-401H
CTCB1206-601H
CTCB1206-122H
CTCB1206-152H
Impedance
Ω
(Ω±25%)
6
10
40
80
120
6
10
40
60
80
120
240
300
480
600
1000
6
11
26
32
60
75
90
120
150
170
220
300
400
500
600
1000
1200
1500
2200
32
60
80
90
120
150
200
220
350
400
600
1200
1500
Test
Freq.
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR
Max.
Ω
(Ω)
.10
.20
.40
.60
.80
.05
.07
.30
.30
.40
.40
.40
.50
.60
.60
.70
.70
.10
.20
.20
.30
.30
.30
.40
.40
.50
.50
.50
.50
.50
.50
.60
.70
.70
.75
.20
.30
.30
.30
.40
.40
.50
.50
.60
.60
.80
1.0
1.2
ctparts.com
CTCB Series
High Speed
From 6
Ω
to 2,200
Ω
IDC
(mA)
300
200
150
100
50
500
400
300
300
300
300
200
200
150
100
100
800
700
600
600
500
500
500
400
400
400
300
300
300
200
200
100
100
100
100
600
500
500
500
400
400
300
300
300
300
300
200
150
Not shown at actual size.
CHARACTERISTICS
Description:
High Speed multi-layer ferrite chip beads
Applications:
Noise suppression in computer peripherals,
telecommunication equipment, data communication equipment and
other consumer electronics
Operating Temperature:
-55°C to +125°C
Impedance Range:
CTCB0402: 6-120
Ω
CTCB0603: 6-1000
Ω
CTCB0805: 6-2200
Ω
CTCB1206: 32-1500
Testing:
Impedance is tested on an HP4287A at 100 MHz
Packaging:
Tape & Reel
Marking:
Reels marked with part number
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
Volume Manufacturer of Inductive Components
800-684-5322
Inside US
949-453-1811
Outside US
7.12.14.01
Copyright © 2002 by CT Magnetics. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice.
