Document 284-1
SMT Power Inductors - DO5010H Series
•
Irms
ratings up to 15 A; saturation currents up to 30 A
• Heavy gauge wire for low DC resistance
Designer’s Kit C355
contains 3 of each part
Core material
Ferrite
Core and winding loss
See www.coilcraft.com/coreloss
Terminations
RoHS compliant tin-silver over copper. Other
terminations available at additional cost.
Weight
3.2 – 4.0 g
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+125°C with derated current
Storage temperature
Component: –40°C to +125°C.
Packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Mean Time Between Failures (MTBF)
26,315,789 hours
Packaging
250 per 13″ reel Plastic tape: 32 mm wide,
0.38 mm thick, 24 mm pocket spacing, 7.8 mm pocket depth
PCB washing
Only pure water or alcohol recommended
DCR
max
(mOhm)
2.6
4.0
6.1
8.6
10
14
17
18
26
28
32
47
66
86
130
190
250
380
560
850
1100
1800
SRF
typ
3
(MHz)
156
100
75
60
55
40
35
35
28
26
20
20
15
9
8
7
6
5
4
3
2.5
2.0
1. When ordering, please specify
termination
and
packaging
codes:
Part Number
1
DO5010H-781ML_
DO5010H-152ML_
DO5010H-222ML_
DO5010H-332ML_
DO5010H-392ML_
DO5010H-472ML_
DO5010H-602ML_
DO5010H-782ML_
DO5010H-103ML_
DO5010H-123ML_
DO5010H-153ML_
DO5010H-223ML_
DO5010H-333ML_
DO5010H-473ML_
DO5010H-683ML_
DO5010H-104ML_
DO5010H-154ML_
DO5010H-224ML_
DO5010H-334ML_
DO5010H-474ML_
DO5010H-684ML_
DO5010H-105ML_
Inductance
2
±20% (µH)
0.78
1.5
2.2
3.3
3.9
4.7
6.0
7.8
10
12
15
22
33
47
68
100
150
220
330
470
680
1000
Isat
4
(A)
30
25
20
17
15
13
12
11
10
8.5
8.0
7.0
5.5
4.5
3.5
3.0
2.6
2.4
1.9
1.4
1.2
1.0
Irms
5
(A)
15
15
12
10
9.0
8.4
7.5
7.5
6.0
5.2
4.4
3.5
3.0
2.6
2.3
1.8
1.5
1.2
1.0
0.82
0.72
0.56
DO5010H-105MLD
Termination: L
= RoHS compliant tin-silver over copper.
Special order: T
= RoHS tin-silver-copper (95.5/4/0.5) or
S
= non-RoHS tin-lead (63/37).
Packaging: D
= 13″ machine-ready reel. EIA-481 embossed plastic
tape.
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter D instead.
2. Inductance tested at 100 kHz, 0.1 Vrms using an Agilent/HP 4284A
LCR meter or equivalent.
3. SRF measured using Agilent/HP 8753D network analyzer.
4. DC current at which the inductance drops 10% (typ) from its value
without current.
5. Current that causes a 40°C temperature rise from 25°C ambient.
6. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Specifications subject to change without notice.
Please check our website for latest information.
Document 284-1
Revised 10/14/08
© Coilcraft, Inc. 2009
Document 284-2
SMT Power Inductors - DO5010H Series
Typical L vs Frequency
10000
Typical L vs Current
10000
1000
1000 µH
1000 µH
1000
Inductance (µH)
Inductance (µH)
100
100 µH
100
100 µH
10
10 µH
10
10 µH
1
0.78 µH
1
0.78 µH
0.1
0.01
0.1
1
10
0.1
0.1
1
10
100
Frequency (MHz)
Current (A)
Irms Derating
120
110
100
Note
0.500
12,70
Note:
Maximum height: 0.315
for -781 to -153
8,00
0.300
for -223 to -683
7,62
0.280
for -104 to -105
7,11
Percent of rated
I
rms
90
80
70
60
50
40
0.600
max
15,24
0.730
max
18,54
0.561
min
14,25
0.075
1,90
0.250
6,35
0.200
max
5,08
0.626
15,90
25°C
30
20
10
0
-40
-20
0
20
0.065
max
1,65
0.710
max
18,03
Recommended
Land Pattern
Dash number
Internal code
40
60
80
100
120 140
Ambient temperature (°C)
XXX
Part Marking
Part marking since Feb. 2005. Parts manufactured
prior to that date may have color dots.
Visit www.coilcraft.com/colrpowr.cfm for details.
X
Dimensions are in
inches
mm
Specifications subject to change without notice.
Please check our website for latest information.
Document 284-2
Revised 10/14/08
© Coilcraft, Inc. 2009
