SURFACE-MOUNT POWER INDUCTORS
ASPI SERIES
0401, 0602
FEATURES:
•
•
•
•
Current up to 3A
Very Small Foot Print
Flat-top for Pick & Place
Increased Size Selection Guide
OPTIONS:
• Tape & Reel is Standard
Bulk Packaging Available
for Smaller Quantities
• Tolerance: 20% is Standard
• Custom Design Available
COMMON APPLICATIONS:
• Ideal for Palm-Top and Laptop
DC/DC Converters
• PDA’s Flash Memory
• Step-up, Step-down Converters
STANDARD SPECIFICATIONS
Part
Number
# - xxx
2R2
2R7
3R3
3R9
4R7
5R6
6R8
8R2
100
120
150
180
220
270
330
390
470
560
680
820
101
121
151
181
221
271
L (µH)
±20%
1KHz 0.1Vrms
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
DCR (Ω) Max
ASPI
0401
ASPI
0602
0.065
0.075
0.080
0.090
0.100
0.105
0.110
0.120
0.140
0.150
0.170
0.180
0.200
0.300
0.350
0.400
0.600
0.700
0.800
0.900
1.000
1.100
1.200
ASPI
0401
IDC (A) Max
ASPI
0602
3.00
2.60
2.40
2.25
2.10
1.90
1.85
1.70
1.55
1.40
1.32
1.20
1.05
0.97
0.86
0.80
0.70
0.65
0.60
0.54
0.47
0.41
0.35
0.12
0.14
0.15
0.17
0.25
0.28
0.33
0.40
0.45
0.80
0.85
0.95
1.08
1.20
1.35
1.50
2.00
2.20
3.80
4.00
4.50
5.20
0.80
0.75
0.70
0.65
0.60
0.56
0.50
0.48
0.41
0.35
0.32
0.30
0.28
0.26
0.24
0.22
0.20
0.18
0.15
0.14
0.12
0.10
PHYSICAL CHARACTERISTICS
ASPI-0401
Length (L)
Width (W)
Thickness (T)
0.185±0.008
(4.7±0.2)
0.185±0.008
(4.7±0.2)
0.11 Max
(2.8 Max)
ASPI-0602
0.267±0.008
(6.8±0.2)
0.267±0.008
(6.8±0.2)
0.157 Max
(4.0 Max)
Dimensions: Inches (mm)
