Ferrules
INSULATED
(INDUSTRIAL STANDARD)
DIN Code <Polypropylene insulated and tin-plated electrolytic copper>
DIN 46228, part 4
Applicable wire
Model No.
mm2
DWE0.5-8
DWE0.75-8
DWE1-8
DWE1.5-8
DWE2.5-8
DWE4-10
DWE6-12
DWE10-12
DWE16-12
DWE25-16
DWE35-16
DWE50-20
0.50
0.75
1.00
1.50
2.50
4.00
6.00
10.0
16.0
25.0
35.0
50.0
AWG
20
18
18
16
14
12
10
8
6
4
2
1
II
II
II
I
I
I
I
I
II
I
I
I
White
Grey
Red
Black
Blue
Grey
Yellow
Red
Blue
Yellow
Red
Blue
Style
Colour Code
L1
14
14
14
14
14
17
20
22
24
30
30
36
L2
8
8
8
8
8
10
12
12
12
16
16
20
Dimensions (mm)
D1
1
1.2
1.4
1.7
2.2
2.8
3.5
4.5
5.8
7.3
8.3
10.3
S1
0.15
0.15
0.15
0.15
0.15
0.2
0.2
0.2
0.2
0.2
0.2
0.3
D2
2.6
2.8
3
3.5
4.2
4.8
6.3
7.6
8.8
11.2
12.7
15
Note: 1) Style I - Suitable for Tri-rated cable, Style II - Standard
2) Maximum operating temperature: + 105°
c
3) Delivery lead times may vary depending on the product. These products are
ONLY
available from the following JST affiliates;
J.S.T. (U.K.) Ltd, J.S.T. Belgium N.V., J.S.T. India Liaison Office, and JST-SouthAfrica.com.
Twin Cable ferrules <Polypropylene insulated and tin-plated electrolytic copper>
DIN Colour Code
Applicable Wire
Model No.
2 x mm2
TWE0.5-8
TWE0.75-8
TWE1-8
TWE1.5-8
TWE1.5-12
TWE2.5-10
TWE4-12
TWE6-14
TWE10-12
TWE16-16
Note: 1)
2)
3)
4)
Dimensions
Style
Colour Code
L1
II
II
II
II
II
II
II
II
II
II
White
Grey
Red
Black
Black
Blue
Grey
Yellow
Red
Blue
16
16
16
16
20
18
23
26
24
29
L2
8
8
8
8
12
9
12
14
12
16
D1
1.5
1.8
2.3
2.3
2.3
2.9
3.8
4.9
5.8
8.3
S1
0.15
0.15
0.15
0.15
0.15
0.15
0.20
0.20
0.20
0.22
D2
4.9
5.2
5.8
6.5
6.5
7.5
9
10
14.5
18.3
E
2.5
2.6
3.2
3.6
3.6
4.3
5.2
7.2
7.5
9.3
2 x AWG
20
18
18
16
16
14
12
10
8
6
0.50
0.75
1.00
1.50
1.50
2.50
4.00
6.00
10.0
16.0
Style I - Suitable for Tri-rated cable, Style II - Standard
Maximum operating temperature: + 105°
c
Do not twist the strands
Delivery lead times may vary depending on the product. These products are
ONLY
available from the following JST affiliates;
J.S.T. (U.K.) Ltd, J.S.T. Belgium N.V., J.S.T. India Liaison Office, and JST-SouthAfrica.com.
TSSC003.00(Ferrules-Insulated)
