AM29C823ASC datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> AM29C823ASC

AM29C823ASC: DescriptionCMOS SERIES, 9-BIT DRIVER, TRUE OUTPUT, PDSO24, PLASTIC, SOIC-24; Categorylogic logic; File Size877KB，11 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

AM29C823ASC Overview

CMOS SERIES, 9-BIT DRIVER, TRUE OUTPUT, PDSO24, PLASTIC, SOIC-24

AM29C823ASC Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	SOIC
package instruction	SOP,
Contacts	24
Reach Compliance Code	unknown
Other features	WITH CLEAR AND CLOCK ENABLE
series	CMOS
JESD-30 code	R-PDSO-G24
length	15.4 mm
Logic integrated circuit type	BUS DRIVER
Humidity sensitivity level	NOT SPECIFIED
Number of digits	9
Number of functions	1
Number of ports	2
Number of terminals	24
Maximum operating temperature	70 °C
Minimum operating temperature
Output characteristics	3-STATE
Output polarity	TRUE
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
propagation delay (tpd)	15.5 ns
Certification status	COMMERCIAL
Maximum seat height	3 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	NOT SPECIFIED
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	7.5 mm
