P6KE47AG-Z15-B: DescriptionTrans Voltage Suppressor Diode, 600W, 40.2V V(RWM), Unidirectional, 1 Element, Silicon, DO-15,; CategoryDiscrete semiconductor diode; File Size173KB，6 Pages; ManufacturerUNISONIC TECHNOLOGIES CO.,LTD; Websitehttp://www.unisonic.com.tw/; Environmental Compliance

Download Datasheet Parametric View All

P6KE47AG-Z15-B Overview

Trans Voltage Suppressor Diode, 600W, 40.2V V(RWM), Unidirectional, 1 Element, Silicon, DO-15,

P6KE47AG-Z15-B Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	UNISONIC TECHNOLOGIES CO.,LTD
package instruction	O-PALF-W2
Reach Compliance Code	compliant
ECCN code	EAR99
Maximum breakdown voltage	49.35 V
Minimum breakdown voltage	44.65 V
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
JEDEC-95 code	DO-15
JESD-30 code	O-PALF-W2
Maximum non-repetitive peak reverse power dissipation	600 W
Number of components	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	UNIDIRECTIONAL
Maximum power dissipation	5 W
Maximum repetitive peak reverse voltage	40.2 V
surface mount	NO
technology	AVALANCHE
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

UNISONIC TECHNOLOGIES CO., LTD

P6KE

TRANSIENT VOLTAGE

SUPPRESSORS



DESCRIPTION

TVS

The UTC

P6KE

is Transient Voltage Suppressors. it uses UTC’s

advanced technology to provide customers with low leakage current,

ultra-low response time and perfect clamping capability, etc



FEATURES

DO-15

* Low leakage current

* Ultra-low response time

* Perfect clamping capability



ORDERING INFORMATION

Package

DO-15

Pin Assignment

Packing

Tape Box

Ordering Number

Lead Free

Halogen Free

P6KEXXXXXL-Z15-B

P6KEXXXXXG-Z15-B

Note: Pin Assignment: A: Anode

K: Cathode

P6KEXXXXXL-Z15-B

(1)Packing Type

(2)Package Type

(3)Halogen Free

(4)Category

(5)Output Voltage

(1) B: Tape Box

(2) Z15: DO-15

(3) L: Lead Free, G: Halogen Free

(4) Blank: 10% uni-directional, A: 5% uni-directional,

C : 10% Bi-directional, CA: 5% Bi-directional

(5) xxx: refer to ELECTRICAL CHARACTERISTICS



MARKING

UTC

P6KEXXXXX

Cathode Band for

uni-directional Only

Date Code
