CN10AZ821JL datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Passive components> capacitor> CN10AZ821JL

Preview

CN10AZ821JL: DescriptionArray/Network Capacitor, 25V, Z5U, 0.00082uF, Through Hole Mount, SIP-10, SIP, ROHS COMPLIANT; CategoryPassive components capacitor; File Size388KB，1 Pages; ManufacturerMeritek Electronics; Websitehttp://www.meritekusa.com; Environmental Compliance

Download Datasheet Parametric View All

CN10AZ821JL Overview

Array/Network Capacitor, 25V, Z5U, 0.00082uF, Through Hole Mount, SIP-10, SIP, ROHS COMPLIANT

CN10AZ821JL Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Meritek Electronics
package instruction	SIP,
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	0.00082 µF
Capacitor type	ARRAY/NETWORK CAPACITOR
length	26.7 mm
Installation features	THROUGH HOLE MOUNT
negative tolerance	5%
Network Type	BUSSED C NETWORK
Number of components	9
Number of functions	1
Number of terminals	10
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
encapsulated code	SIP
Package shape	RECTANGULAR PACKAGE
positive tolerance	5%
Rated (DC) voltage (URdc)	25 V
Maximum seat height	5.6 mm
surface mount	NO
Temperature characteristic code	Z5U
Temperature Coefficient	-56/+22% ppm/°C
Terminal pitch	2.54 mm
Terminal shape	FLAT
width	2.4 mm

Preview

Download Datasheet

View All

Capacitor Networks

CN

Series

(Single-In Line, Low Profile)

MERITEK

A

PPICATIONS

•

Personal Computer

Floppy Disk Drives

OA Machine

V.T.R

Sequential machine

TTL,CMOS,NMOS RMOS Interface circuits

S

PECIFICATIONS

TC

ITEM

Temperature

Coefficient

Capacitance

Test 25

o

C

Dissipation

Factor 25

o

C

Dielectric Strength, 25

o

C

Life Test

(1000 hours)

Insulation Resistance

25

o

C

Rated Voltage

Capacitance Range

Tolerance

NPO

0

±30

ppm /

o

C

-55

o

C

to

+125

o

C

1 Vrms

max.

at 1 KHz

(1MHz for 100pF or less)

0.15%

max. at

1KHz, 1Vrms

(1MHz for 100pF or less)

300% rated voltage for 5

sec.

500mA

max.

<

±3%

at 200% rated

voltage, 125

o

C

X7R

Z5U

±15%

+22%, -56%

-55

o

C

to

+125

o

C

-55

o

C

to

+85

o

C

1 Vrms

max.

at

1 Vrms

max.

at 1KHz

1KHz

2.5%

max.

at 1KHz,

5%

max.

at 1

KHz,

1 Vrms

max.

1 Vrms

max.

250% rated voltage for 5 sec.

with

50mA

max. charging

<

±12.5%

at 200%

<

±30%

at 200%

rated voltage, 125

o

C rated voltage, 85

o

C

10,000 M min.

DC 25V, 50V, 100V

10pF

to

0.15µF

±5%

to

+80 / -20%

P

ART

N

UMBERING

S

YSTEM

CN

Meritek Series

Number of Pins

10

A

X

103

K

L

Dielectric

CODE

N

NPO

X

X7R

Z

25U

Capacitance

Capacitance expressed in

pF.

First two digits are significant

figures.

Third digit denotes number

of

zeros.

EX. 101:100pF 223:22000pF or .022µF 104:100000pF or 0.1µF

Tolerance

CODE

J

±

5%

L

25V

K

±10%

M

50V

M

±

20%

H

100V

Z

+80%, -20%

Voltage

CODE

M

ARKING

Pin No. 1

Indicator

10

No. Of Pins

A

Circuit

X

N: NPO

X: X7R

Z: Z5U

103

Capacitance Code

K

Tolerance

rev: 5b

Specifications are

subject to change without notice.
