ZMM5239B: DescriptionZener Diode, 9.1V V(Z), 5%, 0.5W, Silicon, Unidirectional, SIMILAR TO DO-213AA, MELF-2; CategoryDiscrete semiconductor diode; File Size76KB，3 Pages; ManufacturerDiodes Incorporated; Environmental Compliance

Download Datasheet Parametric Compare View All

ZMM5239B Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ZMM5239B	-	-	View	Buy Now

ZMM5239B Overview

Zener Diode, 9.1V V(Z), 5%, 0.5W, Silicon, Unidirectional, SIMILAR TO DO-213AA, MELF-2

ZMM5239B Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Diodes Incorporated
package instruction	SIMILAR TO DO-213AA, MELF-2
Reach Compliance Code	compliant
ECCN code	EAR99
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
Maximum dynamic impedance	10 Ω
JESD-30 code	O-LELF-R2
Humidity sensitivity level	1
Number of components	1
Number of terminals	2
Maximum operating temperature	175 °C
Minimum operating temperature	-65 °C
Package body material	GLASS
Package shape	ROUND
Package form	LONG FORM
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.5 W
Nominal reference voltage	9.1 V
surface mount	YES
technology	ZENER
Terminal form	WRAP AROUND
Terminal location	END
Maximum voltage tolerance	5%
Working test current	20 mA

Preview

Download Datasheet

View All

ZMM5221B - ZMM5267B

500mW SURFACE MOUNT ZENER DIODE

Features

·

500mW Power Dissipation

Outline Similar to JEDEC DO-213AA

Hemetic Glass Package

C

B

A

Mechanical Data

·

Case: MiniMELF

Terminals: Solderable per MIL-STD-202,

Method 208

Polarity: Cathode Band

Marking: Cathode Band Only

Weight: 0.034 grams (approx.)

MiniMELF

Dim

A

B

C

Min

3.30

1.30

0.28

Max

3.70

1.60

0.50

All Dimensions in mm

Maximum Ratings and Electrical Characteristics

Characteristic

Power Dissipation

Thermal Resistance, Junction to Ambient Air

Forward Voltage

(Note 1)

P

d

R

qJA

V

F

@ T

A

= 25°C unless otherwise specified

Value

500

300

1.5

-65 to +175

Unit

mW

°C /W

V

o

C

Symbol

@ I

F

= 200mA

Operating and Storage Temperature Range

T

j,

T

STG

Notes:

1. Valid provided that electrodes are kept at ambient temperature.

2. Tested with pulses, T

p

£

100ms.

DS30024 Rev. C-2

1 of 3

ZMM5221B-ZMM5267B
