Wire-wound Chip Inductors - Open
ctparts.com
CT0805FSF Series
From .12 µH to 8.2 µH
Part
Number
CT0805FSF-121_
CT0805FSF-151_
CT0805FSF-181_
CT0805FSF-221_
CT0805FSF-271_
CT0805FSF-331_
CT0805FSF-391_
CT0805FSF-471_
CT0805FSF-561_
CT0805FSF-681_
CT0805FSF-821_
CT0805FSF-102_
CT0805FSF-122_
CT0805FSF-152_
CT0805FSF-182_
CT0805FSF-222_
CT0805FSF-272_
CT0805FSF-332_
CT0805FSF-392_
CT0805FSF-472_
CT0805FSF-562_
CT0805FSF-682_
CT0805FSF-822_
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CT0805FSF-151_
J = ±5%, K = ±10%
L Test
Freq.
(MHz)
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
Q
Fact.
Min.
20
20
20
20
20
20
20
20
20
20
20
15
15
15
15
15
15
15
15
15
15
15
15
Q Test
Freq.
(MHz)
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
SRF
Min.
(MHz)
700
900
600
550
550
550
420
350
300
300
300
280
280
250
120
110
70
60
55
45
40
36
33
DCR
Max.
Ω
(Ω)
0.18
0.18
0.20
0.25
0.30
0.35
0.35
0.45
0.45
0.60
0.55
0.80
0.90
1.05
0.90
1.10
1.20
1.50
1.60
2.10
2.30
2.70
3.30
Rated
DC
(mA)
1100
1100
800
700
700
650
600
600
550
500
500
450
400
350
350
320
320
300
300
200
250
200
180
Inductance
(µH)
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.00
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
Compliant
RoHS
CHARACTERISTICS
Description:
SMD ferrite core wire-wound chip inductor
Applications:
LC resonant circuits such as oscillator and signal
generators, impedance matching, circuit isolation, RF filters, disk
drives and computer peripherals, audio and video equipment, TV,
radio and telecommunication equipment
Operating Temperature:
-40°C to +85°C
Inductance Tolerance:
±5%, ±10%
Testing:
Inductance and Q tested on an HP4287A at specified
frequency.
Packaging:
Tape & Reel
Marking:
Reel label indicates inductance code and tolerance
Miscellaneous:
RoHS Compliant.
Miscellaneous:
Additional values available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
2.29
0.090
B
Max.
1.73
0.068
C
Max.
1.45
0.057
D
Ref.
0.51
0.020
E
Max.
1.27
0.050
F
0.51
0.020
G
1.27
0.050
B
C
F
A
G
F
E
D
PAD LAYOUT
1.78 Max
1.02 Max
(0.040)
0.76
(0.030)
1.02 Max
(0.040)
