All specifications are subject to change without notice.
DS 280 Rev 01 | 03/28/07
S1632 Series
1.8V CMOS Low Jitter
Crystal Clock Oscillator (XO)
Electrical Performance
Parameter
Min.
Typ.
Max.
Units
Notes
Output frequency
Supply voltage
1.5440
1.71
1.8
100
1.89
4
7
10
20
MHz
V
As specified
1.5440 to <36 MHz
Supply current, output enabled
mA
36 to <50 MHz
50 to <70 MHz
70 to 100 MHz
Standby current
Frequency stability
Operating temperature
Output logic 0, VOL
Output logic 1, VOH
Output load
Duty cycle
Rise and fall
time
Jitter,
Phase
Jitter,
Accumulated
Jitter,
Total
<36 MHz
36 to 100 MHz
up to 75 MHz
75 to 100 MHz
up to <75 MHz
75 to 100 MHz
up to <75 MHz
75 to 100 MHz
45
90% V
DD
-40
10
100
±25 to ±50
+85
10% V
DD
15 pF (max)
55
4
2.5
1.5
1
5
3
50
30
μA
uA
ppM
°C
V
V
%
ns
ps RMS
(1-σ)
ps RMS
(1-σ)
ps
pk-pk
1.5440 to <36MHz
36 to 100MHz
See Note 1 below
As specified
measured 50%VDD
measured 20/80% of waveform
10kHz to 20 MHz frequency band
20.000 adjacent periods
100.000 random periods
Notes:
1. As specified. Stability includes all combinations of operating temperature, load changes, rated input (supply) voltage changes, initial calibration tolerance (25°C),
aging (1 year at 25°C average effective ambient temperature), shock and vibration.
