ZB8PD-622N+

Description
Splitter And Combiner, 3200MHz Min, 6200MHz Max, 1.8dB Insertion Loss-Max, ROHS COMPLIANT, Z41
CategoryWireless rf/communication    Radio frequency and microwave
File Size492KB,5 Pages
ManufacturerMini-Circuits
Websitehttps://www.minicircuits.com
Environmental Compliance
Download Datasheet Parametric View All

ZB8PD-622N+ Overview

Splitter And Combiner, 3200MHz Min, 6200MHz Max, 1.8dB Insertion Loss-Max, ROHS COMPLIANT, Z41

ZB8PD-622N+ Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerMini-Circuits
package instructionROHS COMPLIANT, Z41
Reach Compliance Codenot_compliant
ECCN codeEAR99
Other featuresN, ISOLATION-MIN (DB):16
Characteristic impedance50 Ω
structureCOAXIAL
Maximum input power (CW)40 dBm
Maximum insertion loss1.8 dB
Maximum operating frequency6200 MHz
Minimum operating frequency3200 MHz
Maximum operating temperature100 °C
Minimum operating temperature-55 °C
RF/Microwave Device TypesSPLITTER AND COMBINER
Maximum voltage standing wave ratio1.9
Power Splitter/Combiner
8 Way-0°
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
DC Current
DC Pass
ZB8PD-622N+
50Ω
-55°C to 100°C
-55°C to 100°C
3200 to 6200 MHz
Features
• wideband
• good isolation, 26 dB typ.
• good output VSWR, 1.22:1 typ.
CASE STYLE: Z41
Connectors Model
N-Type
ZB8PD-622N+
Price
Qty.
$174.95 ea. (1-9)
Maximum Ratings
10W max.
0.875W max.
1.6A(200mA for each port)
Applications
• ISM applications
• SATCOM
• WIMAX
• radar
Parameter
Frequency Range
Insertion Loss
(above theoretical 9.0 dB)
3200-6200
+RoHS Compliant
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications
Permanent damage may occur if any of these limits are exceeded.
Coaxial Connections
SUM PORT
PORT 1,2,3,4,5,6,7,8
S
1,2,3,4,5,6,7,8
Electrical Specifications at 25°C
Frequency (MHz)
Min.
3200
0.8
Typ.
Max.
6200
1.8
Unit
MHz
dB
Outline Drawing
Isolation
3200-6200
16
26
dB
Phase Unbalance
3200-6200
5
10
Degree
Amplitude Unbalance
3200-6200
0.4
0.7
dB
VSWR (Port S)
3200-6200
1.5
1.9
:1
VSWR (Port 1-8)
3200-6200
1.22
1.6
:1
Outline Dimensions (
inch
)
mm
A
B
C
7.06
3.13
.88
179.32 79.50 22.35
J
2.875
73.03
D
E
F
G
.250 1.750 5.310 6.810
6.35 44.45 134.87 172.97
H
.250
6.35
wt
grams
800
Typical Performance Data
Freq.
(MHz)
S-1
3200.00
3400.00
3600.00
3800.00
4000.00
4200.00
4400.00
4600.00
4800.00
5000.00
5200.00
5400.00
5600.00
6000.00
6200.00
9.45
9.50
9.43
9.34
9.36
9.50
9.53
9.48
9.47
9.53
9.50
9.60
9.76
9.88
9.92
S-2
9.50
9.55
9.47
9.37
9.39
9.52
9.63
9.59
9.63
9.67
9.73
9.75
9.63
9.89
9.95
Total Loss
1
(dB)
S-3
S-4
S-6
S-8
9.45
9.49
9.42
9.33
9.35
9.49
9.48
9.44
9.50
9.49
9.40
9.47
9.57
9.71
9.86
Amplitude
Unbalance
(dB)
1-2
0.15
0.13
0.09
0.10
0.26
0.37
0.32
0.24
0.27
0.18
0.39
0.41
0.29
0.38
0.29
20.00
20.17
21.30
22.84
22.75
23.51
28.89
30.74
22.81
22.24
25.50
25.91
27.25
28.34
24.25
Isolation
(dB)
2-3
34.95
43.51
42.20
32.77
29.23
28.78
30.93
40.51
34.14
26.02
24.93
25.38
25.10
24.46
25.90
3-4
20.83
20.71
21.42
22.86
23.70
25.03
29.55
36.15
24.40
22.12
23.18
25.61
27.47
26.18
23.13
5-6
20.64
20.63
21.46
22.61
22.36
23.27
28.10
31.90
22.92
22.25
25.72
25.28
25.47
27.00
23.93
Phase
Unbalance
(deg.)
3.02
3.12
3.24
3.63
4.15
4.75
5.90
2.15
2.66
3.70
3.38
3.06
4.27
5.31
5.58
S
VSWR
1
8
K
L
M
N
P
.144
3.53
.44
.415
.89
3.66 89.66 11.18 10.54 22.61
Electrical Schematic
(DC THROUGH)
PORT 1 RF+DC
PORT S
RF+DC
PORT N RF+DC
PORT 2 RF+DC
9.39
9.37 9.41
9.46
9.45 9.47
9.38
9.42 9.41
9.39
9.43 9.42
9.52
9.61 9.55
9.84
9.86 9.85
9.78
9.79 9.76
9.67
9.62 9.68
9.71
9.56 9.74
9.59
9.53 9.59
9.54
9.45 9.52
9.56
9.45 9.57
9.59
9.51 9.65
9.88 10.09 9.95
9.97 10.15 10.05
1.34
1.46
1.32
1.07
1.16
1.26
1.17
1.16
1.17
1.29
1.12
1.16
1.25
1.36
1.29
1.13
1.10
1.05
1.03
1.04
1.07
1.15
1.19
1.16
1.15
1.14
1.16
1.17
1.14
1.09
1.11
1.08
1.04
1.03
1.05
1.07
1.16
1.21
1.18
1.14
1.11
1.14
1.14
1.09
1.20
1. Total Loss = Insertion Loss + 9dB splitter loss.
10.6
10.4
TOTAL LOSS (dB)
10.2
10.0
9.8
9.6
9.4
9.2
at RF level of -10 dBm
ZB8PD-622N+
TOTAL LOSS
S-1 (dB)
S-8 (dB)
ISOLATION (dB)
9.0
3200
3700
Notes
A.
Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document.
B.
Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
C.
The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled
to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp
4200
4700
5200
FREQUENCY (MHz)
5700
6200
50
45
40
35
30
25
20
15
10
5
0
3200
at RF level of -10 dBm
ZB8PD-622N+
ISOLATION
1.8
1.6
VSWR
1.4
1.2
at RF level of -10 dBm
ZB8PD-622N+
VSWR
1-VSWR
8-VSWR
S-VSWR
1-2 (dB)
3700
3-4 (dB)
2-3 (dB)
5700
6200
4200
4700
5200
FREQUENCY (MHz)
1.0
3200
3700
4200
4700
5200
FREQUENCY (MHz)
5700
6200
www.minicircuits.com
P.O. Box 350166, Brooklyn, NY 11235-0003 (718) 934-4500 sales@minicircuits.com
Mini-Circuits
®
REV. A
M149580
ED-14784/4
ZB8PD-622N+
SZ/CP/AM
150107
Page 1 of 1
