OP14Z datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> OP14Z

OP14Z: DescriptionDUAL OP-AMP, 3000uV OFFSET-MAX, 1.3MHz BAND WIDTH, CDIP8, HERMETIC SEALED, CERAMIC, DIP-8; CategoryAnalog mixed-signal IC Amplifier circuit; File Size1MB，9 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

OP14Z Overview

DUAL OP-AMP, 3000uV OFFSET-MAX, 1.3MHz BAND WIDTH, CDIP8, HERMETIC SEALED, CERAMIC, DIP-8

OP14Z Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Objectid	1358209238
Parts packaging code	DIP
package instruction	DIP,
Contacts	8
Reach Compliance Code	unknown
compound_id	157454025
Amplifier type	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	0.1 µA
Nominal Common Mode Rejection Ratio	95 dB
Maximum input offset voltage	3000 µV
JESD-30 code	R-GDIP-T8
Negative supply voltage upper limit	-22 V
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of functions	2
Number of terminals	8
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum seat height	5.08 mm
Nominal slew rate	0.5 V/us
Supply voltage upper limit	22 V
Nominal supply voltage (Vsup)	15 V
surface mount	NO
technology	BIPOLAR
Temperature level	MILITARY
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Nominal Uniform Gain Bandwidth	1300 kHz
width	7.62 mm
