AP13P15GH-HF Overview

Lower On-resistance, Simple Drive Requirement

AP13P15GH-HF Parametric

Parameter Name	Attribute value
Maker	APEC
Parts packaging code	TO-252
package instruction	SMALL OUTLINE, R-PSSO-G2
Contacts	4
Reach Compliance Code	compli
ECCN code	EAR99
Configuration	SINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage	150 V
Maximum drain current (ID)	13 A
Maximum drain-source on-resistance	0.3 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR
JEDEC-95 code	TO-252
JESD-30 code	R-PSSO-G2
Number of components	1
Number of terminals	2
Operating mode	ENHANCEMENT MODE
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Polarity/channel type	P-CHANNEL
Maximum pulsed drain current (IDM)	52 A
Certification status	Not Qualified
surface mount	YES
Terminal form	GULL WING
Terminal location	SINGLE
transistor applications	SWITCHING
Transistor component materials	SILICON

Preview

Download Datasheet

View All

AP13P15GH/J-HF

Halogen-Free Product

Advanced Power

Electronics Corp.

▼

Lower On-resistance

▼

Simple Drive Requirement

▼

Fast Switching Characteristic

▼

RoHS Compliant & Halogen-Free

P-CHANNEL ENHANCEMENT MODE

POWER MOSFET

DSS

DS(ON)

-150V

300mΩ

-13A

Description

The TO-252 package is widely preferred for all commercial-industrial

surface mount applications and suited for low voltage applications

such as high efficiency switching DC/DC converters and DC motor

control. The through-hole version (AP13P15GJ) is available for low-

profile applications.

D S

TO-252(H)

TO-251(J)

Absolute Maximum Ratings

Symbol

=25℃

=100℃

=25℃

STG

Parameter

Drain-Source Voltage

Gate-Source Voltage

Continuous Drain Current, V

@ 10V

Continuous Drain Current, V

@ 10V

Pulsed Drain Current

Total Power Dissipation

Linear Derating Factor

Total Power Dissipation

Rating

-150

+20

-13

-8.2

-52

0.77

-55 to 150

Units

W/℃

℃

Storage Temperature Range

Operating Junction Temperature Range

Thermal Data

Symbol

Rthj-c

Rthj-a

Parameter

Maximum Thermal Resistance, Junction-case

Maximum Thermal Resistance, Junction-ambient (PCB mount)

Value

1.3

62.5

110

Units

℃/W

201006242

Maximum Thermal Resistance, Junction-ambient

Data and specifications subject to change without notice

AP13P15GH-HF Related Products

	AP13P15GH-HF	AP13P15GJ-HF
Description	Lower On-resistance, Simple Drive Requirement	Lower On-resistance, Simple Drive Requirement
Maker	APEC	APEC
Parts packaging code	TO-252	TO-251
package instruction	SMALL OUTLINE, R-PSSO-G2	IN-LINE, R-PSIP-T3
Contacts	4	3
Reach Compliance Code	compli	compli
ECCN code	EAR99	EAR99
Configuration	SINGLE WITH BUILT-IN DIODE	SINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage	150 V	150 V
Maximum drain current (ID)	13 A	13 A
Maximum drain-source on-resistance	0.3 Ω	0.3 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR	METAL-OXIDE SEMICONDUCTOR
JEDEC-95 code	TO-252	TO-251
JESD-30 code	R-PSSO-G2	R-PSIP-T3
Number of components	1	1
Number of terminals	2	3
Operating mode	ENHANCEMENT MODE	ENHANCEMENT MODE
Maximum operating temperature	150 °C	150 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	IN-LINE
Polarity/channel type	P-CHANNEL	P-CHANNEL
Maximum pulsed drain current (IDM)	52 A	52 A
Certification status	Not Qualified	Not Qualified
surface mount	YES	NO
Terminal form	GULL WING	THROUGH-HOLE
Terminal location	SINGLE	SINGLE
transistor applications	SWITCHING	SWITCHING
Transistor component materials	SILICON	SILICON
