ESETTABLE
R
ESETTABLE
F
USES
WICKMANN
LP30 / No. 364
Radial Leaded, 30V
Approvals (pending)
UL Recognized
Specifications
Packaging
600: Tape (Details on Request
1
)
611: Bulk (500 pcs.)
Features
Low voltage overcurrent protection
Low resistance and power dissipation
Self-resetting; no need for replacement after
fault condition
Materials
Body:
Yellow Epoxy Polymer, UL 94V0
Round Pins: Copper alloy, tin plated
Temperature
Operating Temperature
-40ºC to +85ºC (consider de-rating)
WebLinks
Data Sheet
www.wickmann.com/products/364.pdf
Test
Humidity Aging Test
85ºC/85% RH/1000 hrs.
Stock Conditions
+10ºC to +60ºC
relative humidity
≤
75% yearly average,
without dew, maximum value for 30 days-95%
Dimensions (mm)
900mA - 2.50A
3,0
Packaging
3.00A - 9.00A
3,0
Page 119
www.wickmann.com/pack
FaxBack Document # 601
Solderability
260ºC,
≤
3 sec. (MIL-STD-202, Method 208E)
Wave only
Marking
7,6
7,6
Logo, Part Code
D
∅
0,51
D
Unit Weight (approx.)
0.6g (900mA - 2.50A)
0.8g (3.00A - 9.00A)
Type
364-900mA
364-1.10A
364-1.35A
364-1.60A
364-1.85A
364-2.50A
364-3.00A
364-4.00A
364-5.00A
364-6.00A
364-7.00A
364-8.00A
364-9.00A
A (max)
8.7
8.7
8.9
10.7
10.7
11.7
11.7
14.0
14.0
16.5
19.1
21.6
24.1
B (max)
13.5
14.2
13.5
15.5
15.7
18.3
17.3
20.1
24.9
24.9
26.7
29.2
29.7
∅
0,81
C (typ)
5.1
5.1
5.1
5.1
5.1
5.1
5.1
5.1
10.2
10.2
10.2
10.2
10.2
D (typ)
0.9
0.9
0.9
0.9
0.9
0.9
1.2
1.2
1.2
1.2
1.2
1.2
1.2
Preliminary Data
Resistance
Initial R
I
Initial R
I
max. (
Ω
)
min. (
Ω
)
0.07
0.05
0.04
0.03
0.03
0.02
0.02
0.01
0.01
0.005
0.005
0.005
0.005
0.12
0.10
0.08
0.07
0.06
0.04
0.05
0.03
0.03
0.02
0.02
0.02
0.01
100%
25 (77
77ºF).
Permissible continuous operating current is
≤
100% at ambient temperature of 25ºC (77ºF).
Rated
Amp
Voltage Fault Current Trip Current Trip Time @
Power
Rating
I
Fault
I
Trip
5 x I
C
Dissipation P
V
Current I
C
Code
max. (A)
(A)
max. (s)
max. (W)
900mA
1.10A
1.35A
1.60A
1.85A
2.50A
3.00A
4.00A
5.00A
6.00A
7.00A
8.00A
9.00A
I
C
:
I
F
:
I
Trip
:
P
V
:
R
I
:
P:
1:
Approvals
UR
0900
1110
1135
1160
1185
1250
1300
1400
1500
1600
1700
1800
1900
30V
30V
30V
30V
30V
30V
30V
30V
30V
30V
30V
30V
30V
40
40
40
40
40
40
40
40
40
40
40
40
40
1.80
2.20
2.70
3.20
3.70
5.00
6.00
8.00
10.00
12.00
14.00
16.00
18.00
7.1
6.6
7.3
8.0
8.7
10.3
10.8
12.7
14.5
16.0
17.5
18.8
20.0 1
0.91
1.00
1.11
1.20
1.27
1.34
2.01
2.51
3.01
3.51
3.80
4.00
4.21
b
b
b
b
b
b
b
b
b
b
b
b
b
Max. continuous current at which the fuse will not trip at 25
º
C ambient.
Max. fault current the fuse can withstand at 25
º
C ambient without being damaged; fuse may withstand higher currents at lower voltages - test accordingly.
Min. current at which the fuse will trip at 25
º
C ambient, max. fuse temperature in tripped state is 125
º
C.
Power dissipated by the fuse when tripped at 25
º
C ambient.
Min. and max. resistance at 2
º
C prior to tripping.
Pending
Device tested at 40 A
Order
Information
001005
Qty.
Order-
Number
Series
364
Amp Code
Packaging
WebSite:
www.wickmann.com
FaxBack: +1 (404) 699-6176
• Europe
Tel: +49 (2302) 662-107
• Americas
Tel: +1 (404) 699-7820
• Asia
Tel: +852 26 14-1108
E-mail: sales@wickmann.com
E-mail: service@wickmannusa.com E-mail: sales@wickmann.com.hk
