TSCD143KCU6 Overview

NPN Digital Transistor

TSCD143KCU6 Parametric

Parameter Name	Attribute value
Maker	Taiwan Semiconductor
package instruction	,
Reach Compliance Code	compli

Preview

Download Datasheet

View All

TSCD143K

NPN Digital Transistor

Pin assignment:

1. TR1 Gnd (Emitter)

2. TR1 Input (Base)

3. TR2 Output (Collector)

4. TR2 Gnd (Emitter)

5. TR2 Input (Base)

6. TR1 Output (Collector)

Vcc = 50V

Vin = - 5V ~ +30V

Io = 100mA(max.)

Features

Build-in bias resistor enable the configuration of an

inverter circuit without connecting external input

resistors (see equivalent circuit)

The bias resistors consist of thin-film resistors with

complete isolation to allow negative biasing of the

input. The also have the advantage of almost

completely eliminating parasitic effects.

Only the on/off conditions need to be set for operation,

making device design easy.

Two TSC143K chips in a SOT-363 package

Transistor elements are independent, eliminating

interference

Complements the TSAD143K

Equivalent Circuit

Ordering Information

Part No.

TSCD143KCU6

Packing

Tape & Reel

Package

SOT-363

Note: the build-in resistor value type, option as

No.

TR 1

TR 2

Re (KΩ)

R (KΩ)

4.7

Marking

Absolute Maximum Rating

(Ta = 25

unless otherwise noted)

Parameter

Supply Voltage

Input Voltage

Output Current

Pulse

Power Dissipation (note)

Operating Junction Temperature

Operating Junction and Storage Temperature Range

Note: 1. Single pulse, Pw = 300uS, Duty <= 2%

2. 150mW per element must not be exceeded.

STG

Symbol

Vcc

Vin

Limit

5 ~ +30

100

200

+150

- 55 to +150

Unit

TSCD143K

1-4

2003/12 rev. C
