42R06-3214-150 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> The connector> 42R06-3214-150

Preview

42R06-3214-150: Description16/20A, 250VAC, MALE, MAINS POWER CONNECTOR, SCREW; CategoryThe connector The connector; File Size35KB，1 Pages; ManufacturerPower Dynamics, Inc.; Websitehttp://www.powerdynamics.com/; Environmental Compliance

Download Datasheet Parametric View All

42R06-3214-150 Overview

16/20A, 250VAC, MALE, MAINS POWER CONNECTOR, SCREW

42R06-3214-150 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Power Dynamics, Inc.
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
Other features	STANDARDS: IEC 60320, UL 94V-0, CSA, VDE
Connector type	MAINS POWER CONNECTOR
Contact to complete cooperation	NICKEL
Contact completed and terminated	Nickel (Ni)
Contact point gender	MALE
Contact material	BRASS
Coupling type	SNAP
DIN compliance	NO
IEC compliance	YES
MIL compliance	NO
Power Connector Ratings	16/20A, 250VAC
Installation type	PANEL
Options	GENERAL PURPOSE
Shell material	POLYCARBONATE
Termination type	SCREW
Total number of contacts	2
Base Number Matches	1

Preview

Download Datasheet

View All

6

5

4

3

2

1

MATERIAL AND FINISH:

Insulator: Polycarbonate, UL-94V-0 rated

Contacts: Brass, Nickel plated

D

L

36.0±0.2

32.4

N

42R06

33.0+0.2

R4.5+0.2 TYP.

28.0±0.2

25.0+0.2

D

C

ORDERING CODE:

42R06-3 __ 1 __ - __ __ __

1

2

3

1) COLOR

1 = BLACK

2 = GRAY

2) ELECTRICAL CIRCUIT

CONFIGURATION

10.0±0.5

REPLACE WITH

CORRESPONDING

PANEL THICKNESS

B

1 = 20A 250V 70°C

2+GROUND

2 = 20A 250V 155°C

2+GROUND

CHNG CHCK APPR

5.0±0.1

21.0+0.5

8.0±0.2

4 = 20A 250V 70°C

2 POLE

3) PANEL THICKNESS

13.0±0.2

29.0+0.5

TOLERANCE

UNLESS OTHERWISE SPECIFIED

X ± 1

X.X ± 0.4

X.XX ± 0.20

REVISIONS

CHANGE

A

DATE

REV

RoHS

COMPLIANT

6

5

4

X.X

21

E

ELECTRICAL SPECIFICATIONS:

V

Current rating: 16 A

D E

Voltage rating: 250 VAC

Current rating: 20 A

Voltage rating: 250 VAC

Insulation resistance: 100 Mohm min. at

500 VDC

Dielectric withstanding voltage: 2000 VAC

for one minute

M3x6.0mm

SCREW TERMINIALS

RECOMMENDED

PANEL CUTOUT

24.4

C

A+0.2

3.0

6.0±0.1

B

3X 2.00±0.05

P/N

A MAX. PANEL THICKNESS

1.5

42R06-3X1X-150 1.5

2.0

42R06-3X1X-200 2.0

2.5

42R06-3X1X-250 2.5

ADDITIONAL PANEL THICKNESS

AVAILABLE ON REQUEST

Phone: 973 560-0019

Whippany, New Jersey

Fax: 973 560-0076

PART: 16/20A IEC 60320 APPL. INLET; SCREW

TERMINALS; SNAP-IN, PANEL MOUNT

PART #:

A

DRAWN

BY

CHECK

BY

APPR

BY

GQ

TD

PB

DATE:

08/21/01

08/28/01

SIZE:

SCALE:

42R06-3X1X-XXX

A

NTS

ALL DIMENSIONS FOR REFERENCE ONLY

DIMENSIONS ARE IN MILLIMETERS

SHEET

1 of 1

REV:

3

2

1
