DESD5V0S1BLD
LOW CAPACITANCE BIDIRECTIONAL TVS DIODE
Features
•
•
•
•
•
•
•
•
Provides ESD Protection per IEC 61000-4-2 Standard:
Air
±30kV,
Contact
±30kV
Ultra Low Profile (0.4mm), Ideal for Thin Portable Electronics
1 Channel of ESD Protection
High Peak Pulse Current per IEC 61000-4-5 Standard
Low Channel Input Capacitance
Typically Used in Cellular Handsets, Portable Electronics,
Communication Systems, Computers and Peripherals
Lead Free/RoHS Compliant (Note 1)
Halogen and Antimony Free "Green" Device (Notes 2 & 3)
Mechanical Data
•
•
•
•
•
Case: X2-DFN1006-2
Case Material: Molded Plastic, “Green” Molding Compound. UL
Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: NiPdAu over Copper leadframe. Solderable per MIL-
STD-202, Method 208
Weight: 0.001 grams (approximate)
NEW PRODUCT
X2-DFN1006-2
Pin 1
Pin 2
Bottom View
Device Schematic
Ordering Information
(Note 4)
Part Number
DESD5V0S1BLD-7B
Notes:
Case
X2-DFN1006-2
Packaging
10,000/Tape & Reel
1. EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. No purposely added lead.
2. Halogen and Antimony free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
3. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com.
4. For packaging details, go to our website at http://www.diodes.com.
Marking Information
R8 = Product Type Marking Code
Line Denotes Pin 1
DESD5V0S1BLD
Document number: DS35650 Rev. 4 - 2
1 of 4
www.diodes.com
March 2012
© Diodes Incorporated
DESD5V0S1BLD
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Peak Pulse Power Dissipation
Peak Pulse Current
ESD Protection – Contact Discharge
ESD Protection – Air Discharge
Symbol
P
PP
I
PP
Value
130
12
±30
±30
Unit
W
A
kV
kV
Conditions
8/20μs, Per Fig. 1
8/20μs, Per Fig. 1
IEC 61000-4-2 Standard
IEC 61000-4-2 Standard
NEW PRODUCT
V
ESD_Contact
V
ESD_Air
Thermal Characteristics
Characteristic
Package Power Dissipation (Note 5)
Thermal Resistance, Junction to Ambient (Note 5)
Operating and Storage Temperature Range
Symbol
P
D
R
θ
JA
T
J
, T
STG
Value
250
500
-65 to +150
Unit
mW
°C/W
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Reverse Standoff Voltage
Channel Leakage Current (Note 6)
Clamping Voltage
Breakdown Voltage
Differential Resistance
Channel Input Capacitance
Notes:
Symbol
V
RWM
I
RM
V
CL
V
BR
R
DIF
C
T
Min
-
-
-
-
5.5
-
-
Typ
-
5
-
-
-
0.4
35
Max
5
100
10
14
9.5
-
45
Unit
V
nA
V
V
Ω
pF
Test Conditions
-
V
RWM
= 5V
I
PP
= 1A, t
p
= 8/20μS
I
PP
= 12A, t
p
= 8/20μS
I
R
= 1mA
I
R
= 10A, t
p
= 8/20μS
V
R
= 0V, f = 1MHz
5. Device mounted on FR-4 PCB pad layout (2oz copper) as shown on Diodes, Inc. suggested pad layout AP02001, which can be found on our website at
http://www.diodes.com.
6. Short duration pulse test used to minimize self-heating effect.
35
f = 1 MHz
I
PP
, PEAK PULSE CURRENT (%I
pp
)
C
T
, TOTAL CAPACITANCE (pF)
100
30
50
25
0
0
20
40
t, TIME (
μ
s)
Fig. 1 Pulse Waveform
60
20
2
3
4
5
6
V
R
, REVERSE VOLTAGE (V)
Fig. 2 Typical Total Capacitance vs. Reverse Voltage
0
1
DESD5V0S1BLD
Document number: DS35650 Rev. 4 - 2
2 of 4
www.diodes.com
March 2012
© Diodes Incorporated
