Ceramic Y Capacitors
UL/cUL File #E197475
F
EATURES
•
•
•
•
Compact size
Cost effective products
Ideal for across-the-line applications
Safety standard recognized for AC applications
AH/AC
Series
MERITEK
S
PECIFICATIONS
1.
2.
3.
4.
5.
6.
Capacitance Range:
Capacitance Tolerance:
Operating Temperature Range:
Temperature
Coefficient
( C Max):
Voltage Rating:
Dissipation Factor( tan ):
100pF to 10000pF
±10%, ±20%, +80%/-20%
7.
8.
Insulation Resistance:
Dielectric Strength:
-25
o
C to 85
o
C
±10%(Y5P), +30%/-80% (Y5V)
250VAC
- UL/cUL
250VAC (Y1/Y2), 400VAC (X1) - European Standards
o
Y5P=2.5% max @
20 C,
1KHz,
1±0.2Vrms
o
Y5V=5.0% max @
20 C,
1KHz,
1±0.2Vrms
10000M
Ω
at 500VDC for 60 seconds
2600VAC for 60 seconds
AH/AC
are specifically designed for AC
applications and meet the safety requirements of
various safety standard agencies. They are ideal
for across-the-line and line bypass applications
P
ART
N
UMBERING
S
YSTEM
AC
Type Class
Code
Class
AH
X1/Y1
AC
X1/Y2
09
F
102
M
L7
TA
Part Diameter (mm)
Ceramic Dielectric
Code
Ceramic dielectric
B
Y5P
F
Y5V
E
Y5U
Capacitance
Code
Capacitance
( pF )
101
100
102
1000
222
2200
472
4700
103
10000
Tolerance
Code
Tolerance
AH
Type
Lead code
L0
D0
B0
M
± 20%
AC
Type
Lead code
L0
L7
D0
D7
B0
B7
S0
S7
X7
Z
+80%/-20%
K
±10%
Configuration and Dimensions
Kinked
Straight
Straight
Front & back
Front & back
Inside
Inside
Straight
Straight
Outside
Lead
space(F)
10.0mm
7.5mm
10.0 mm
7.5 mm
10.0 mm
7.5 mm
10.0 mm
7.5 mm
7.5 mm
Lead length(L)
25mm min
25mm min
4.0±0.5 min
4.0±0.5 min
4.0±0.5 min
4.0±0.5 min
4.5±1.0 min
4.5±1.0 min
4.0±0.5 min
Lead configuration
Packaging Code
Code
Packaging Code
TA
Tape & Ammo
(BLANK)
Bulk
Specifications are
subject to change without notice.
rev: 6b
