0213.200MXEP: DescriptionTIME LAG BLOW ELECTRIC FUSE, 1A, 250VAC, 250VDC, 250A (IR), THROUGH HOLE; CategoryCircuit protection Circuit protection; File Size872KB，3 Pages; ManufacturerLittelfuse; Websitehttp://www.littelfuse.com; Environmental Compliance

Download Datasheet Parametric View All

0213.200MXEP Overview

TIME LAG BLOW ELECTRIC FUSE, 1A, 250VAC, 250VDC, 250A (IR), THROUGH HOLE

0213.200MXEP Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknow
ECCN code	EAR99
Fusing characteristics	TIME LAG
body height	22.5 mm
Body length or diameter	5.8 mm
Circuit protection type	ELECTRIC FUSE
Fuse size	5x20mm
JESD-609 code	e3
Joule integral nominal
Installation features	THROUGH HOLE
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
method of packing	BULK
physical size	5.8mm x 22.5mm
Pre-discharge rating	0.225 A2/s
Rated breaking capacity	35 A
Rated current	0.2 A
Rated voltage	250 V
Rated voltage (AC)	250 V
Rated voltage (DC)	250 V
Guideline	CCC; CE; CSA; IEC; SEMKO; UL; VDE
surface mount	NO
Terminal surface	Tin (Sn)
Terminal shape	PIN WIRE
Base Number Matches	1

Preview

Download Datasheet

View All

Axial Lead & Cartridge Fuses

5×20 mm > Time-Lag > 213 Series

213 Series, 5×20 mm, Time-Lag Fuse

RoHS

Pb

PS

E

Description

5×20mm time-Lag surge withstand glass body cartridge

fuse designed to IEC specification.

Features

• Designed to International

(IEC ) Standards for use

globally

• Available in cartridge and

axial lead form

• Meets the IEC 60127-2,

Sheet 3 specification for

time-Lag fuses

• RoHS compliant and

lead-free.

Applications

Agency Approvals

Agency

PS

E

Used as supplementary protection in appliance or utilization

equipment to provide individual protection for components

or internal circuits.

Ampere Range

Agency File Number

Cartridge: NBK090205-E10480A

NBK120802-E10480C

Leaded: NBK090205-E10480B

NBK120802-E10480D

2003010207045592

E10480

029862

1718680

40015638

KM41462

SU05001-12002

SU05001-12001

N/A

1A-5A

6.3A

1A-5A

6.3A

0.200A – 6.3A

Electrical Characteristic for Series

% of Ampere

Rating

150%

210%

275%

All Ratings

400%

1000%

Ampere Rating

Opening Time

60 minutes, Minimum

2 minutes, Maximum

0.6 sec., Min.; 10 sec. Max.

.15 sec., Min.; 3 sec. Max.

0.02 sec., Min.; 0.3 sec. Max.

0.200A – 6.3A

3.15A-5A

6.3A

0.200A – 6.3A

Additional Information

Datasheet

Resources

Samples

Electrical Characteristic Specifications by Item

Voltage

Amp Ampere

Rating

Code Rating

(V)

.200

.250

.315

.400

.500

.630

.800

001.

1.25

01.6

002.

02.5

3.15

004.

005.

06.3

0.2

0.25

0.315

0.4

0.5

0.63

0.8

1

1.25

1.6

2

2.5

3.15

4

5

6.3

250

Interrupting

Rating

Maximum

Nominal

Voltage

Power

Nominal

Cold

Melting Drop at Rated Dissipation

Resistance

2

Current

at 1.5ln

I t (A

2

sec)

(Ohms)

(mV)

(W)

1.6000

0.22500

1500

1.6

1.0495

0.55500

1300

1.6

0.8475

1.14000

1100

1.6

0.5350

1.36000

1000

1.6

0.3700

2.90500

900

1.6

0.2750

4.80000

300

1.6

0.1635

9.42000

250

1.6

0.1165

19.20000

150

1.6

0.0817

27

.15000

150

1.6

0.0551

44.20000

150

1.6

0.0452

92.70500

150

1.6

0.0305

138.00000

120

1.6

0.0231

202.00000

100

1.6

0.0170

226.50500

100

1.6

0.0116

314.00000

100

1.6

0.0095

600.00000

100

1.6

Agency Approvals

PS

E

35A@250Vac

40A@250Vac

50A@250Vac

63A@250Vac

x

Specifications are subject to change without notice. Application testing is strongly recommended.

Revised: 12/14/17
