RLS Series
Load Life of 5,000 Hours at 105°C
Ultra Low Impedance
Excellent Ripple Current Capability
SPECIFICATIONS
Operating Temperature Range
Rated Voltage Range
Capacitance Tolerance
Leakage Current
Dissipation Factor
(At 20°C, 120Hz)
Temperature Characteristics
(Impedance Ratio at 120Hz)
-55~+105°C
6.3 ~ 100V
0.47 ~18000uF
±20% (at 20°C, 120Hz)
I < 0.01CV or 3 uA whichever is greater (at 20°C, after 2 minutes)
I: Leakage Current (uA)
C: Nominal Capacitance (uF)
V: Rated Voltage (V)
Rated Voltage (V)
tan
δ
W.V
Z(-55°C)/Z(+20°C)
6.3
0.22
6.3
8
10
0.19
10
6
16
0.16
16
4
25
0.14
25
4
35
0.12
35
4
50
0.10
50
3
63
0.09
63
3
100
0.08
100
3
Time
Load Life (+105°C)
Capacitance Change
Dissipation Factor
Leakage Current
5,000 hours after an application of DC bias voltage plus the rated
ripple current (Ø5~6.3: 2000Hrs; Ø=8: 3000Hrs; Ø10: 4000Hrs;
Ø>10: 5000Hrs) The peak voltage shall not exceed rated DC
voltage
Within ±20% of the initial value
200% of the initial specified value or less
The specified value or less
Shelf Life (+105°C)
After leaving the capacitor under on load at 105°C for 1000 hours, they meet the specified value for
load life characteristics listed above.
DIMENSION
MULTIPLIER FOR RIPPLE CURRENT
Frequency Coefficient
Freq(Hz)
Rated
Voltage(V)
0.47 ~ 4.7
5.6 ~ 47
56~270
330 ~ 1000
1200 ~ 18000
120
0.30
0.30
0.55
0.60
0.65
1K
0.68
0.75
0.80
0.85
0.90
10K
0.75
0.85
0.90
0.90
0.90
100K
1.0
1.0
1.0
1.0
1.0
ØD
F
Ød
a
5
2.0
6.3
2.5
0.5
1.0
8
3.5
10
5.0
0.6
12.5
2.0
16
7.5
0.8
18
update on 00/11/07
