Jones
DURA-CON
®
Plugs/Sockets
High Reliability
Series 300
All-Plastic
300 Series Deep Bracket (DB)
No. of
Contacts
2
3
4
6
8
10
12
15
18
21
24
27
30
33
Catalog No.
Plug
P-302-DB
P-303-DB
P-304-DB
P-306-DB
N/A
N/A
P-312-DB
P-315-DB
P-318-DB
P-321-DB
P-324-DB
P-327-DB
P-330-DB
P-333-DB
[.050” (1.27mm) Density
Multiple Density
Solder Cup/Wire
Solder Eyelet
D-Microminiature]
Deep Bracket
2
Catalog No.
Socket
S-302-DB
S-303-DB
S-304-DB
S-306-DB
N/A
N/A
N/A
S-315-DB
S-318-DB
S-321-DB
S-324-DB
S-327-DB
S-330-DB
S-333-DB
Dimensions
No. of
Contacts
15
18
21
24
27
30
33
L
±.063 (1.60mm)
in
mm
2.813
71.44
3.125
79.38
3.437
87.31
3.750
95.25
4.063 103.19
4.375 111.13
4.688 119.06
M
±.031 (.79mm)
in
mm
2.375
60.33
2.688
68.28
3.000
76.20
3.313
84.15
3.625
92.08
3.938
100.03
4.250
107.95
Y = length of plug or socket tails.
Polarizing
Pin
NO
NO
NO
14
14
14
17
Panel Cutout Dimensions
A
Reference
302-DB thru
312-DB
315-DB
318-DB
321-DB
324-DB
327-DB
330-DB
333-DB
in
1.453
2.000
2.313
2.625
2.938
3.250
3.562
3.875
mm
36.91
50.80
58.75
66.68
74.63
82.55
90.47
98.43
in
1.125
1.438
1.438
1.438
1.438
1.438
1.438
1.438
B
mm
28.58
36.53
36.53
36.53
36.53
36.53
36.53
36.53
in
1.750
2.376
2.688
3.000
3.312
3.626
3.938
4.250
C
mm
38.10
60.35
68.28
76.20
84.12
92.10
100.03
107.95
Marketed exclusively through distribution.
Call Toll Free: 1 (800) 323-9612
2-44
