S30 SERIES 30 WATT HIGH VOLTAGE DC/DC CONVERTERS

FEATURES

* Customer Selects Output Voltage

Outputs to 1000 Vdc

High Power Density

Single and Dual Outputs

Ultra Wide Input Ranges

1000 Vdc Output Isolation

Continuous Short Circuit Protection

Economical

The S30 Series low profile high voltage DC/DC

converter offers a 1000 Vdc isolated single or dual high

voltage output in a six-sided copper case. Their high

power density, wide input, and excellent regulation

make them ideally suited for applications that demand

a high degree of performance. All models will tolerate a

short circuit indefinitely.

ELECTRICAL SPECIFICATIONS

Voltage Accuracy ...........................................................+/-5%

Line Regulation .............................................................. +/- 1%

Load Regulation .............................. +/- 3% (20% to full load)

Output Ripple ...............................................................< 0.5%

* 20-60Vdc Input add suffix /B

* 36-72Vdc Input add suffix /C

Input Filter ................................................. Low ESR Capacitor

Efficiency ............................................................... 85% (typ.)

Short Circuit Protection ........................................ Continuous

Switching Frequency ................................................. 120 kHz

Isolation .................................................................. 1000 Vdc

GENERAL SPECIFICATIONS

Temp. Stability ................................................... +/-0.02%/°C

Temp. (Operating , Case) ................................... -25 to +70°C

Temp. (Storage) ............................................... -40 to +125°C

EMI/RFI...........................................................Six Sided Shield

Derating ......................................................................... None

Cooling ................................................... Free-Air Convection

* All models designed to meet UL 60950

* For RoHS Compliant part, add suffix /Y

PHYSICAL SPECIFICATIONS

Dimensions ................................................. 2 x 2 x 0.50 inches

Weight ......................................................................... 2.6 Oz

Case Material .......................................... Nickel Plated Copper

(With Non-Conductive Base Plate)
