FAST RECOVERY HIGH VOLTAGE PHOTO FLASH RECTIFIER
FR05-10G THRU FR05-20G
FEATURES
FAST RECOVERY TIMES
UL 94V0 FLAME RETARDANT EPOXY MOLDING COMPOUND
LOW COST
DESIGNED FOR PHOTO FLASH APPLICATION
BEVELED ROUND CHIP
GLASS PASSIVATED CHIP JUNCTION
MECHANICAL DATA
CASE: TRANSFER MOLDED, DO41, DIMENSIONS
IN INCHES AND (MILLIMETERS)
LEADS: SOLDERABLE PER MIL-STD-202, METHOD 208
POLARITY: CATHODE INDICATED BY COLOR BAND
WEIGHT: 0.34 GRAMS
1.0(25.4)
MIN
.034(0.9)
.028(0.7)
.205(5.2)
.166(4.2)
.107(2.7)
.080(2.0)
1.0(25.4)
MIN
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS RATINGS AT 25°C AMBIENT TEMPERATURE UNLESS OTHERWISE SPECIFIED
SINGLE PHASE, HALF WAVE, 60 HZ, RESISTIVE OR INDUCTIVE LOAD. FOR CAPACITIVE LOAD, DERATE CURRENT BY 20%
RATINGS
MAXIMUM RECURRENT PEAK REVERSE VOLTAGE
MAXIMUM RMS VOLTAGE
MAXIMUM DC BLOCKING VOLTAGE
AVERAGE FORWARD RECTIFIED CURRENT
AT L=10mm T
A
=55°C
NOM-REPETITIVE PEAK FORWARD SURGE CURRENT,
8.3ms HALF SINE-WAVE
TYPICAL JUNCTION CAPACITANCE AT VR=4V,
FREQUENCY=1MHZ (NOTE 1)
TYPICAL THERMAL RESISTANCE
STORAGE TEMPERATURE RANGE
OPERATING TEMPERATURE RANGE
SYMBOL
V
RRM
V
RMS
V
DC
I
O
I
FSM
C
J
R
θja
T
STG
T
OP
FR05-10G
1000
700
1000
FR05-15G
1500
1050
1500
FR05-16G
1600
1120
1600
0.5
30
15
50
-55 TO + 150
-55 TO + 150
FR05-18G
1800
1260
1800
FR05-20G
2000
1400
2000
UNITS
V
V
V
A
A
PF
℃/W
℃
℃
ELECTRICAL CHARACTERISTICS (A
T
T
A
=25°C UNLESS OTHERWISE NOTED)
CHARACTERISTICS
MAXIMUM FORWARD VOLTAGE AT Io DC
MAXIMUM REVERSE CURRENT AT 25℃
MAXIMUM REVERSE CURRENT AT 100℃
SYMBOL
V
F
I
R
I
R
FR05-10G
FR05-15G
2.0
5
50
500
FR05-16G
FR05-18G
FR05-20G
3.0
UNITS
V
μA
μA
nS
TYPICAL REVERSE RECOVERY TIME
T
RR
NOTE: 1. MEASURED AT 1MHZ AND APPLIED REVERSE VOLTAGE OF 4.0 VOLTS
2. BOTH LEADS ATTACHED TO HEAT SINK 20×20×1t(mm) COPPER PLATE AT LEAD LENGTH 5mm
FR05-10G THRU FR05-20G
Page: 1
RATINGS AND CHARACTERISTICS CURES FR05-10G THRU FR05-20G
FORWARD SURGE CURRENT,
AMPERES PK (HALF SINE-WAVE)
FIG. 1-MAXIMUM CURRENT RATING
EFFECT OF COPPER AREA.
RESISTIVE/INDUCTIVE LOAD
I
O
-PERCENT OF AVERAGE
RECTIFIED CURRENT (%)
A=20
□
FIG. 5-MAXIMUM FORWARD SURGE
VS NUMBER OF CYCLES
30
24
18
12
6
0
1
10
NO. OF CYCLES AT 60H
Z
100
100
A=10
□
mm
80
60
40
20
0
0
COPPER AREA
5.5 mm
PC
BOARD
10mm
10m
A=5 5
□
mm
20
40
60
80
100 120 140 160
T
A
-AMBIENT TEMPERATURE (℃)
FIG. 2-MAXIMUM CURRENT RATING
CAPACITIVE LOAD,
10mm LEAD LENGTHS
I
O
-PERCENT OF AVERAGE
RECTIFIED CURRENT (%)
PK
AV RESISTIVE/INDUCTIVE LOADS
100
80
60
10mm
5
10
20
CAPACITIVE
LOADS
FIG. 6-TYPICAL JUNCTION CAPACITANCE
C
J
-JUNCTION CAPACITANCE
(PF)
100
10m
COPPER AREA
5.5 mm
PC
BOARD
40
20
0
0
20
40
60
80
100 120 140 160
10
FIG. 3-MAXIMUM CURRENT RATING
EFFECT OF COPPER AREA.
RESISTIVE/INDUCTIVE LOAD
L=5mm
1
1
10
100
1000
V
R
-REVERSE VOLTAGE (V)
I
O
-PERCENT OF AVERAGE
RECTIFIED CURRENT (%)
100
80
60
40
20
0
0
COPPER AREA
5.5 mm
10mm
10mm
L=10mm
L=20mm
PC
BOARD
20
40
60
80
100 120 140 160
1.0
I
F
-FORWARD CURRENT (A)
FIG. 7 TYPICAL FORWARD
CHARACTERISTICS
T
A
-AMBIENT TEMPERATURE (℃)
FIG. 4-TYPICAL REVERSE CHARACTERISTICS
AT T
J
=25℃
10
INSTANTANEOUS REVERSE CURRENT
MICROAMPERES
0.1
1.0
0.01
0.1
0.001
0
0.5
1.0
1.5 2.0 2.5
3.0 3.5 4.0
V
F
-FORWARD VOLAGE (V)
0
20
40
60
80
100
120
140
.01
PERCENT OF RATED PEAK REVERSE VOLTAGE
FR05-10G THRU FR05-20G
Page: 2
